Crystal Units
NX3215SA
■
Features
Compact, thin, and light weight tuning fork crystal unit.
●Excellent electric performance optimum for mobile communications,
OA (office automation) and AV (audiovisual) applications are exhibited. (For OA / AV /
Mobile Communication)
●Excellent heat resistance and environmental characteristics. (For Automotives)
●Meet the requirements for re-flow profiling using lead-free solder.
●Conforms to AEC-Q200. (For Automotives)
For OA / AV / Mobile Communication / Automotives
Directive 2011/65/EU
Directive (EU) 2015/863
■
Specifications
Item
Main Application
Nominal Frequency
Operating Temperature Range
Storage Temperature Range
Level of Drive
Frequency Tolerance (25 ±3 °C)
Turning Point
Temperature Coefficient
Load Capacitance
Equivalent Series Resistance
Shunt Capacitance
Insulation Resistance
Specifications Number
STD-MUA-14
STD-MUA-9
6.0pF
9.0pF
−40 to +85°C
−40 to +85°C
0.1µW (Max. 0.5µW )
±20 × 10
−6
+25°C ± 5°C
−0.04 × 10
−6
/°C
2
Max.
12.5pF
Max. 70kΩ
Typ. 1.0pF / Max.1.5pF
Min. 500MΩ
STD-MUA-8
STD-MUS-4
STD-MUS-3
STD-MUS-2
6.0pF
9.0pF
Max. 80kΩ
12.5pF
Model
For OA / AV / Mobile Communication
32.768kHz
−40 to +125°C
−40 to +125°C
NX3215SA
For Automotive
■
Dimensions
3.2±0.1
Terminal land connections
(TOP VIEW)
mm
1.5±0.1
#1
#2
0.8±0.1
Land pattern (Typical)
1.0
1.5
1.0
0.75
1.3
#1
#2
1.7
3.5
Please specify the model name, frequency, and specification number when you order products.
For further questions regarding specifications, please feel free to contact us.
1904C_NX3215SA_e
1.8
