1-1461387-6: DescriptionPOWER/SIGNAL RELAY, SPDT, MOMENTARY, 0.03A (COIL), 24VDC (COIL), 720mW (COIL), 10A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT, ROHS COMPLIANT; CategoryMechanical and electronic products relay; File Size88KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric View All

1-1461387-6 Overview

POWER/SIGNAL RELAY, SPDT, MOMENTARY, 0.03A (COIL), 24VDC (COIL), 720mW (COIL), 10A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT, ROHS COMPLIANT

1-1461387-6 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	1283417607
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
ECCN code	EAR99
YTEOL	.4
body width	12.8 mm
body height	20.6 mm
Body length or diameter	29.21 mm
Maximum coil current (DC)	0.03 A
Coil power	720 mW
Coil resistance	820 Ω
Maximum coil voltage (DC)	24 V
Coil/Input Power Type	DC
Maximum contact current (AC)	10 A
Maximum contact current (DC)	10 A
Maximum contact voltage (AC)	240 V
Maximum contact voltage (DC)	30 V
Contact/Output Power Type	AC/DC
Dielectric strength between coil and contacts	5000 Vrms
Dielectric strength between breaking contacts	1000 Vrms
End contact material	SILVER TIN ALLOY
Insulation resistance	1000000000 Ω
Installation features	PANEL MOUNT
Maximum operating temperature	60 °C
Minimum operating temperature	50 °C
method of packing	TUBE
physical size	29.2mm x 12.8mm x 20.6mm
Guideline	CSA; SEMKO; SEV; UL; VDE
Relay action	MOMENTARY
Relay style	1 FORM C
Relay function	SPDT
Relay type	POWER/SIGNAL RELAY
surface mount	NO
Termination type	SOLDER/QUICK CONNECT
weight	13 g

Preview

Download Datasheet

View All

OMIT-SH-124D,394 Product Details

Mid-Ran ge PC Board Re lays

Converted to EU RoHS/ELV Compliant

(

Statement of Compliance

)

Previous 1

...

6 7 8 9

[10]

...

20 Next

Quick Links

Check Pricing & Availability

Search for Tooling

Product Feature Selector

Compare Products

Product Highlights:

OMIT Series

Contact Arrangement = 1 Form C, SPDT, 1 C/O

Contact Current Rating = 10 Amps.

Monostable Coil Magnetic System

Without Coil Suppression Diode

View all Features

Find Similar Products

O MIT-SH-124D,394

Active

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

None Available

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

Additional Information:

Product Line Information

Additional Product Images:

Schematic

Wiring Diagram

PCB Layout (Bottom Surface)
