Absolute Maximum Ratings (Ta=25°C, All voltages are with respect to ground)
Parameter
Supply Voltage
Output Current
All Other Input Pins
Operating Temperature
Storage Temperature
Power Dissipation
Junction Temperature
Symbol
V
CC
I
OMAX
V
IN
Topr
Tstg
Pd
Tjmax
Rating
7
0.5
(Note 1)
/ 1.0
(Note 2)
/ 2.0
(Note 3)
-0.3 to V
CC
-40 to +85
-55 to +150
0.68
(Note 4)
/ 1.6
(Note 5)
/ 1.45
(Note 6)
150
Unit
V
A
V
°C
°C
W
°C
Datasheet
(Note 1) BD6210. Do not exceed Pd or ASO.
(Note 2) BD6211. Do not exceed Pd or ASO.
(Note 3) BD6212. Do not exceed Pd or ASO.
(Note 4) SOP8 package. Mounted on a 70mm x 70mm x 1.6mm glass-epoxy board. Derate by 5.5mW/°C for Ta above 25°C.
(Note 5) HRP7 package. Mounted on a 70mm x 70mm x 1.6mm glass-epoxy board. Derate by 12.8mW/°C for Ta above 25°C.
(Note 6) HSOP25 package. Mounted on a 70mm x 70mm x 1.6mm glass-epoxy board. Derate by 11.6mW/°C for Ta above 25°C.
Caution:
Operating the IC over the absolute maximum ratings may damage the IC. The damage can either be a short circuit between pins or an open circuit
between pins and the internal circuitry. Therefore, it is important to consider circuit protection measures, such as adding a fuse, in case the IC is operated over
the absolute maximum ratings.
Recommended Operating Conditions (Ta=25°C)
Parameter
Supply Voltage
VREF Voltage
Symbol
V
CC
V
REF
Rating
3.0 to 5.5
1.5 to 5.5
Unit
V
V
Electrical Characteristics (Unless otherwise specified, Ta=25°C and V
