RADIAL LEAD ALUMINUM ELECTROLYTIC CAPACITORS
YXJ
YXJ
SERIES
105℃ Miniaturized, Long Life
・
Load Life : 105℃ 4000∼10000 hours.
RoHS
compliance
◆SPECIFICATIONS
Items
Category Temperature Range
Rated Voltage Range
Capacitance Tolerance
Characteristics
−40∼＋105℃
6.3∼100Vdc
±20％
（20℃，
120Hz）
I＝0.01CV
or 3μA whichever is greater.(After 2 minutes)
Leakage Current(MAX)
I＝
Leakage Current
(μA) C＝
Capacitance
(μF) V＝
Rated Voltage
(Vdc)
Rated Voltage
6.3 10 16 25 35 50 63 100
(Vdc)
tanδ
0.22 0.19 0.16 0.14 0.12 0.10 0.09 0.08
（20℃，
120Hz）
Dissipation Factor(MAX)
(tanδ)
When capacitance is over 1000μF, tanδ shall be added 0.02 to the listed value with increase of every 1000μF.
After applying rated voltage with rated ripple current for specified time at 105℃,
the capacitors shall meet the following requirements.
Endurance
Capacitance Change
Dissipation Factor
Leakage Current
Rated Voltage
6.3
(Vdc)
Z
（−25℃） （20℃） 4
/Z
Z
（−40℃） （20℃） 8
/Z
Within ±25％ of the initial value.(6.3V:±30％)
Not more than 200％ of the specified value.
Not more than the specified value.
Case Size
φD=5
φD=6.3,8
φD≧10
Life Time(hrs)
6.3∼10Vdc 16∼100Vdc
4000
5000
6000
7000
8000
10000
Low Temperature Stability
Impedance Ratio(MAX)
10
3
6
16
2
4
25
2
3
35
2
3
50
2
3
63 100
2
3
2
3
（120Hz）
◆MULTIPLIER FOR RIPPLE CURRENT
(6.3Vdc∼50Vdc)
Frequency
（Hz）
◆DIMENSIONS
SLEEVE(PET)
（mm）
±0.5
φD＋0.5MAX
φd
120
0.35
0.42
0.55
0.70
0.75
0.80
1k
0.60
0.60
0.75
0.85
0.90
0.95
10k
0.80
0.80
0.90
0.95
0.98
1.00
100k≦
1.00
1.00
1.00
1.00
1.00
1.00
L＋
αMAX
15MIN
1uF
2.2∼10uF
Coefficient
22∼47uF
100∼330uF
470∼1000uF
2200∼15000uF
4MIN
φD
φd
F
α
5
2.0
6.3
0.5
2.5
8
3.5
10
0.6
12.5
F
16
0.8
7.5
5.0
L≦16 : α=1.5 L≧20 : α=2.0
(63Vdc∼100Vdc)
Frequency
（Hz）
Coefficient
◆OPTION
120
0.42
1k
0.60
10k
0.80
100k≦
1.00
PET Sleeve
Code
Blank
◆PART NUMBER
□□□
Rated Voltage
YXJ
Series
□□□□□
Capacitance
M
Capacitance Tolerance
□□□
Option
□□
Lead Forming
D×L
Case Size
RADIAL LEAD ALUMINUM ELECTROLYTIC CAPACITORS
YXJ
◆STANDARD SIZE
Impedance
Rated
Capacitance
Rated ripple current
Size
(Ω MAX)
Voltage
(μF)
φD×L(mm) (mA r.m.s./105℃, 100kHz)
(Vdc)
20℃, 100kHz −10℃, 100kHz
100
220
330
470
1000
2200
3300
4700
6800
10000
15000
100
220
330
470
1000
2200
3300
4700
6800
10000
47
100
220
330
470
1000
2200
3300
4700
6800
33
47
100
220
330
470
1000
2200
3300
4700
33
47
100
220
330
470
1000
2200
3300
5×11
5×11
6.3×11
6.3×11
8×11.5
10×16
10×20
12.5×25
12.5×25
16×25
16×35.5
5×11
5×11
6.3×11
6.3×11
10×12.5
10×20
12.5×20
12.5×25
16×25
16×31.5
5×11
5×11
6.3×11
6.3×11
8×11.5
10×16
12.5×20
12.5×25
16×25
16×31.5
5×11
5×11
5×11
6.3×11
8×11.5
10×12.5
10×20
12.5×25
16×25
16×31.5
5×11
5×11
6.3×11
8×11.5
10×12.5
10×16
12.5×20
16×25
16×31.5
150
250
340
400
640
1300
1400
2230
2230
2930
3610
150
250
400
400
865
1400
1900
2230
2930
3450
250
250
400
400
640
1210
1900
2230
2930
3450
250
250
250
400
640
865
1400
2230
2930
3450
250
250
400
640
865
1210
1900
2930
3450
0.90
0.40
0.22
0.22
0.13
0.062
0.046
0.032
0.032
0.021
0.015
0.90
0.40
0.22
0.22
0.080
0.046
0.041
0.032
0.021
0.019
0.40
0.40
0.22
0.22
0.13
0.062
0.041
0.032
0.021
0.019
0.40
0.40
0.40
0.22
0.13
0.080
0.046
0.032
0.021
0.019
0.40
0.40
0.22
0.13
0.080
0.062
0.041
0.021
0.019
3.6
1.2
0.87
0.87
0.52
0.25
0.18
0.11
0.11
0.060
0.044
3.6
1.2
0.87
0.87
0.32
0.18
0.14
0.11
0.060
0.056
1.2
1.2
0.87
0.87
0.52
0.25
0.14
0.11
0.060
0.056
1.2
1.2
1.2
0.87
0.52
0.32
0.18
0.11
0.060
0.056
1.2
1.2
0.87
0.52
0.32
0.25
0.14
0.060
0.056
Impedance
Rated
Capacitance
Rated ripple current
Size
(Ω MAX)
Voltage
(μF)
φD×L(mm) (mA r.m.s./105℃, 100kHz)
(Vdc)
20℃, 100kHz −10℃, 100kHz
1
2.2
3.3
4.7
10
22
33
47
100
220
330
470
1000
2200
10
22
33
47
100
220
330
470
1000
1
2.2
3.3
4.7
10
22
33
47
100
220
330
5×11
5×11
5×11
5×11
5×11
5×11
5×11
6.3×11
8×11.5
10×16
10×20
12.5×20
16×25
16×35.5
5×11
5×11
6.3×11
6.3×11
10×12.5
10×20
12.5×20
12.5×25
16×25
5×11
5×11
5×11
5×11
6.3×11
6.3×11
8×11.5
8×16
10×20
12.5×25
16×25
30
43
53
88
100
180
250
295
555
1050
1220
1660
2730
3150
173
173
278
278
725
1200
1570
1990
2730
20
30
40
65
267
267
462
585
1040
1620
2210
4.0
2.5
2.2
1.9
1.5
0.70
0.70
0.30
0.17
0.084
0.060
0.045
0.032
0.019
0.88
0.88
0.35
0.35
0.15
0.078
0.060
0.043
0.032
4.5
3.0
2.7
2.5
0.57
0.57
0.36
0.25
0.12
0.060
0.044
8.0
6.0
5.6
5.0
4.0
2.8
2.8
1.2
0.68
0.34
0.24
0.15
0.096
0.057
3.5
3.5
1.4
1.4
0.60
0.31
0.19
0.14
0.096
15.0
13.0
11.0
10.0
2.3
2.3
1.4
1.0
0.52
0.23
0.16
6.3
50
10
63
16
100
25
35
