CHIP ALUMINUM ELECTROLYTIC CAPACITORS
SLV
SLV
RoHS
SERIES
105℃ 5000
Load Life : 105℃ 5000 hours
compliance
◆
／SPECIFICATIONS
Items
Characteristics
−40∼＋105℃
φD＋0.5MAX
◆
／DIMENSIONS
L MAX
A
1±0.2
(mm)
B
1±0.2
Rated Voltage Range
Capacitance Tolerance
6.3∼50Vdc
±20％
（20℃，
120Hz）
I＝0.01CV
3μA
0.3MAX
W
1
φD
L
A
1
B
1
C
W
1
C
0.5MAX
P
C
Category Temperature Range
P
I＝0.01CV
or 3μA whichever is greater. (After 2 minutes application of rated voltage)
Leakage
Current(MAX)
4 6.1 4.3 4.3 1.8 0.5∼0.8 1.0
5 6.1 5.3 5.3 2.2 0.5∼0.8 1.3
6.3 6.1 6.6 6.6 2.7 0.5∼0.8 1.8
I＝
(μA) C＝
(μF) V＝
(Vdc)
Leakage Current Capacitance Rated Voltage
(Vdc)
Rated Voltage
tanδ
6.3
10
16
25
35
50
◆
AA
47
CSL
／MARKING
Lot No.
Capacitance
（20℃，
120Hz）
Dissipation Factor(MAX)
(tanδ)
0.30 0.24 0.20 0.16 0.14 0.14
※
Voltage Code
After applying rated voltage with rated ripple current for 5000 hours at 105℃,
the capacitors shall meet the following requirements.
Endurance
Capacitance Change
Dissipation Factor
Leakage Current
Low Temperature
Stability
Impedance Ratio(MAX)
(Vdc)
6.3
Rated Voltage
Z
（−25℃） （20℃） 4
/Z
Z
（−40℃） （20℃）14
/Z
±30％
Within ±30％ of the initial value.
300％
Not more than 300％ of the specified value.
Not more than the specified value.
10
3
12
16
2
8
25
2
6
35
2
4
50
（120Hz）
2
3
105℃
5000
Series
(Vdc)
6.3 10 16 25 35 50
Rated Voltage
※
Rated voltage code
Negative
Rated Voltage code
j
A C E V H
◆
／
MULTIPLIER FOR RIPPLE CURRENT
60
（50）120
0.47∼1μF 0.50 1.00
2.2∼4.7μF 0.65 1.00
Coefficient
10∼47μF 0.80 1.00
100μF 0.80 1.00
Frequency
（Hz）
500 1k 10k≦
1.20
1.20
1.20
1.10
1.30
1.30
1.30
1.15
1.50
1.50
1.50
1.20
◆
Vdc
6.3
10
16
Cap
(μF)
22
47
100
33
10
22
47
／STANDARD SIZE
Size
(φDxL)
4×6.1
5×6.1
6.3×6.1
5×6.1
4×6.1
5×6.1
6.3×6.1
Rated Ripple
Current
22
38
69
35
18
30
50
Vdc
25
35
Cap
(μF)
33
4.7
10
22
Size φD×L(mm), Rated Ripple Current (mA r.m.s./105℃, 120Hz)
Size
(φDxL)
6.3×6.1
4×6.1
5×6.1
6.3×6.1
Rated Ripple
Current
50
16
27
44
Vdc
Cap
(μF)
0.47
1
2.2
3.3
4.7
10
Size
(φDxL)
4×6.1
4×6.1
4×6.1
4×6.1
5×6.1
6.3×6.1
Rated Ripple
Current
4
8
11
14
19
32
50
◆
□□□
SLV
／PART NUMBER
□□□□□
Capacitance
M
Capacitance Tolerance
□□□
Option
D×L
Case Size
Rated Voltage
Series
