RADIAL LEAD ALUMINUM ELECTROLYTIC CAPACITORS
RX30
RX30
SERIES
Load Life : 130℃ 1000∼4000 hours
・
Automotive and LED Lighting applications.
For
・
AEC-Q200.
RoHS
compliance
◆SPECIFICATIONS
Items
Category Temperature Range
Rated Voltage Range
Capacitance Tolerance
Characteristics
−40∼＋130℃
10∼100Vdc
±20％
（20℃，
120Hz）
−25∼＋130℃
200, 400Vdc
CV≦1000
Leakage Current(MAX)
CV＞1000
I=0.04CV+100μA
(1 minute)
I＝0.01CV
or 3μA whichever is greater.
(After 2 minutes application of rated voltage)
I=0.1CV+40μA
(1 minute)
I=0.03CV+15μA
(5 minutes)
I=0.02CV+25μA
(5 minutes)
I＝
Leakage Current
(μA) C＝
Capacitance
(μF) V＝
Rated Voltage
(Vdc)
Rated Voltage
120Hz）
10 16 25 35 50 63 100 200 400
（20℃，
(Vdc)
tanδ
0.20 0.16 0.14 0.12 0.10 0.09 0.08 0.15 0.20
When capacitance is over 1000μF, tanδ shall be added 0.02 to the listed value with increase of every 1000μF.
After applying rated voltage with rated ripple current for specified time at 130℃,
the capacitors shall meet the following requirements.
Dissipation Factor(MAX)
(tanδ)
10∼100Vdc
Endurance
Capacitance Change
Within ±30％ of the
initial value.
200, 400Vdc
Within ±20％ of the
initial value.
Case Size
φD=6.3
φD=8, 10
φD≧12.5
−
Life Time
（hrs）
10∼100Vdc 200, 400Vdc
1000
2000
−
2000
4000
Dissipation Factor
Leakage Current
Not more than 300％ Not more than 200％
of the specified value. of the specified value.
Not more than the specified value.
Low Temperature Stability
Impedance Ratio(MAX)
Rated Voltage
10
(Vdc)
Z
（−25℃） （20℃） 3
/Z
（−40℃） （20℃） 6
/Z
Z
16
2
4
25
2
3
35
2
3
50
2
3
63 100 200 400
2
3
2
3
3
−
6
−
（120Hz）
◆MULTIPLIER FOR RIPPLE CURRENT
10∼100Vdc
（Hz）
Frequency
4.7μF
10∼33μF
Coefficient
47∼330μF
470∼1500μF
2200∼4700μF
200, 400Vdc
Frequency
（Hz）
◆DIMENSIONS
SLEEVE(PET)
（mm）
φd
60 50） 120
（
0.35 0.42
0.45 0.55
0.60 0.70
0.65 0.75
0.75 0.80
120
0.20
0.30
0.50
1k
0.40
0.60
0.80
1k
0.60
0.75
0.85
0.90
0.95
10k 100k≦
0.80 1.00
0.90 1.00
0.95 1.00
0.98 1.00
1.00 1.00
L＋2MAX
15MIN
4MIN
φD＋ MAX
β
F
±0.5
φD
6.3
0.5
2.5
8
10 12.5 16
0.6
18
1∼5.6μF
Coefficient
6.8∼15μF
22∼33μF
10k 100k≦
0.80 1.00
0.90 1.00
0.90 1.00
φd
F
β
0.8
7.5
1.0
3.5
0.5
5.0
◆PART NUMBER
□□□
Rated Voltage
◆OPTION
□□□□□
Capacitance
RX30
Series
M
Capacitance Tolerance
□□□
Option
□□
Lead Forming
D×L
Case Size
PET Sleeve
Code
Blank
