BAV99
www.vishay.com
Vishay Semiconductors
Small Signal Switching Diode, Dual in Series
FEATURES
3
• Fast switching speed
• High conductance
• Surface mount package ideally suited for
automatic insertion
1
18109
2
• Connected in series
• AEC-Q101 qualified
• Base P/N-E3 - RoHS-compliant, commercial grade
• Base P/N-HE3 - RoHS-compliant, AEC-Q101 qualified
• Material categorization: For definitions of compliance
please see
www.vishay.com/doc?99912
MECHANICAL DATA
Case:
SOT-23
Weight:
approx. 8.8 mg
Packaging codes/options:
18/10K per 13" reel (8 mm tape), 10K/box
08/3K per 7" reel (8 mm tape), 15K/box
PARTS TABLE
PART
BAV99
ORDERING CODE
BAV99-E3-08 or BAV99-E3-18
BAV99-HE3-08 or BAV99-HE3-18
INTERNAL CONSTRUCTION
Dual diodes serial
TYPE MARKING
JE
REMARKS
Tape and reel
ABSOLUTE MAXIMUM RATINGS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Non repetitive peak reverse voltage
Repetitive peak reverse voltage
= working peak reverse voltage
= DC blocking voltage
Peak forward surge current
t
p
= 1 s
t
p
= 1 μs
Half wave rectification with resistive load
and f
50 MHz, on ceramic substrate
10 mm x 8 mm x 0.7 mm
On ceramic substrate
10 mm x 8 mm x 0.7 mm
On ceramic substrate
10 mm x 8 mm x 0.7 mm
TEST CONDITION
SYMBOL
V
RM
V
RRM
= V
RWM
= V
R
I
FSM
I
F(AV)
I
F
P
tot
VALUE
100
70
1
4.5
150
mA
250
300
mW
V
UNIT
A
Average forward current
Forward current
Power dissipation
THERMAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Junction ambient
Junction and storage temperature range
Operating temperature range
TEST CONDITION
On ceramic substrate
10 mm x 8 mm x 0.7 mm
SYMBOL
R
thJA
T
j
= T
stg
T
op
VALUE
430
- 55 to + 150
- 55 to + 150
UNIT
K/W
°C
°C
Rev. 1.9, 16-May-13
Document Number: 85718
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BAV99
www.vishay.com
Vishay Semiconductors
TEST CONDITION
I
F
= 1 mA
I
F
= 10 mA
I
F
= 50 mA
I
F
= 150 mA
V
R
= 70 V
SYMBOL
MIN.
TYP.
MAX.
0.715
V
F
0.855
1
1.25
2500
I
R
C
D
t
rr
50
30
1.5
6
UNIT
V
V
V
V
nA
μA
μA
pF
ns
ELECTRICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Forward voltage
Reverse current
Diode capacitance
Reverse recovery time
V
R
= 70 V, Tj = 150 °C
V
R
= 25 V, Tj = 150 °C
V
R
= 0, f = 1 MHz
I
F
= 10 mA to i
R
= 1 mA,
V
R
= 6 V, R
L
= 100
TYPICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
1000
10
2
D = 0.005
0.01
0.02
0.05
0.1
0.2
I
F
- Forward Current (mA)
100
T
j
= 100 °C
10
25 °C
1
10
-1
10
1
/
FM
10
0
0.1
t
p
D=
t
p
T
10
-3
-2
0.01
0
14356
10
0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0
T
10
-2
10
22290
-6
10
-5
10
-4
10
-1
s
10
-0
V
F
- Forward
Voltage
(V)
Fig. 1 -
Forward Current vs. Forward Voltage
t
Fig. 2 -
Peak forward current /
FM
=
f
(t
p
)
LAYOUT FOR R
thJA
TEST
Thickness:
Fiberglass 1.5 mm (0.059 inches)
Copper leads 0.3 mm (0.012 inches)
7.5 (0.3)
3 (0.12)
1 (0.4)
12 (0.47)
15 (0.59)
0.8 (0.03)
2 (0.8)
1 (0.4)
2 (0.8)
5 (0.2)
1.5 (0.06)
5.1 (0.2)
17451
Rev. 1.9, 16-May-13
Document Number: 85718
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BAV99
www.vishay.com
PACKAGE DIMENSIONS
in millimeters (inches):
SOT-23
Vishay Semiconductors
1.15 (0.045)
0.1 (0.004) max.
0.175 (0.007)
0.098 (0.004)
0.2 (0.008)
0.45 (0.018)
0.35 (0.014)
0.45 (0.018)
0.35 (0.014)
0.3 (0.012)
2.6 (0.102)
2.35 (0.093)
0.45 (0.018)
1.43 (0.056)
1.20 (0.047)
0.35 (0.014)
Foot print recommendation:
0.7 (0.028)
2 (0.079)
1 (0.039)
0.9 (0.035)
1 (0.039)
0.9 (0.035)
Document no.: 6.541-5014.01-4
Rev. 8 - Date: 23.Sept.2009
17418
0.95 (0.037)
0.95 (0.037)
Rev. 1.9, 16-May-13
Document Number: 85718
3
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
0.9 (0.035)
0° t
0.5 (0.020)
o8
°
0.9 (0.035)
3.1 (0.122)
2.8 (0.110)
0.550 ref. (0.022 ref.)
