SI1026X-T1-GE3

Description
Drain-source voltage (Vdss): 60V Continuous drain current (Id) (at 25°C): 305mA Gate-source threshold voltage: 2.5V @ 250uA Drain-source on-resistance: 1.4Ω @ 500mA, 10V Maximum power dissipation ( Ta=25°C): 250mW Type: Dual N-channel
CategoryDiscrete semiconductor    The transistor
File Size147KB,7 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Download Datasheet Parametric View All

SI1026X-T1-GE3 Online Shopping

Suppliers Part Number Price MOQ In stock
SI1026X-T1-GE3 - - View Buy Now

SI1026X-T1-GE3 Overview

Drain-source voltage (Vdss): 60V Continuous drain current (Id) (at 25°C): 305mA Gate-source threshold voltage: 2.5V @ 250uA Drain-source on-resistance: 1.4Ω @ 500mA, 10V Maximum power dissipation ( Ta=25°C): 250mW Type: Dual N-channel

SI1026X-T1-GE3 Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Parts packaging codeSC-89
package instructionSMALL OUTLINE, R-PDSO-F6
Contacts6
Reach Compliance Codeunknown
ECCN codeEAR99
Other featuresLOW THRESHOLD
ConfigurationSEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage60 V
Maximum drain current (Abs) (ID)0.305 A
Maximum drain current (ID)0.305 A
Maximum drain-source on-resistance1.4 Ω
FET technologyMETAL-OXIDE SEMICONDUCTOR
JESD-30 codeR-PDSO-F6
JESD-609 codee3
Humidity sensitivity level1
Number of components2
Number of terminals6
Operating modeENHANCEMENT MODE
Maximum operating temperature150 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)260
Polarity/channel typeN-CHANNEL
Maximum power dissipation(Abs)0.28 W
Certification statusNot Qualified
surface mountYES
Terminal surfaceMatte Tin (Sn)
Terminal formFLAT
Terminal locationDUAL
Maximum time at peak reflow temperature40
transistor applicationsSWITCHING
Transistor component materialsSILICON
Base Number Matches1
Si1026X
Vishay Siliconix
N-Channel 60 V (D-S) MOSFET
PRODUCT SUMMARY
V
DS(min)
(V)
60
R
DS(on)
()
1.40 at V
GS
= 10 V
V
GS(th)
(V)
1 to 2.5
I
D
(mA)
500
FEATURES
Halogen-free According to IEC 61249-2-21
Definition
• Low On-Resistance: 1.40
• Low Threshold: 2 V (typ.)
• Low Input Capacitance: 30 pF
• Fast Switching Speed: 15 ns (typ.)
• Low Input and Output Leakage
• ESD Protected: 2000 V
• Miniature Package
• Compliant to RoHS Directive 2002/95/EC
SC-89
S
1
1
6
D
1
BENEFITS
Low Offset Voltage
Low-Voltage Operation
High-Speed Circuits
Low Error Voltage
Small Board Area
G
1
2
5
G
2
Marking Code: E
D
2
3
4
S
2
APPLICATIONS
• Drivers: Relays, Solenoids, Lamps, Hammers, Displays,
Memories, Transistors, etc.
• Battery Operated Systems
• Solid-State Relays
Top
View
Ordering Information:
Si1026X-T1-GE3 (Lead (Pb)-free and Halogen-free)
ABSOLUTE MAXIMUM RATINGS
(T
A
= 25 °C, unless otherwise noted)
Parameter
Drain-Source Voltage
Gate-Source Voltage
Continuous Drain Current (T
J
= 150 °C)
a
Pulsed Drain Current
b
Continuous Source Current (Diode Conduction)
a
Maximum Power Dissipation
a
Operating Junction and Storage Temperature Range
Gate-Source ESD Rating (HBM, Method 3015)
Notes:
a. Surface mounted on FR4 board.
b. Pulse width limited by maximum junction temperature.
T
A
= 25 °C
T
A
= 85 °C
T
A
= 25 °C
T
A
= 85 °C
Symbol
V
DS
V
GS
I
D
I
DM
I
S
P
D
T
J
, T
stg
ESD
450
280
145
- 55 to 150
2000
320
230
- 650
380
250
130
mW
°C
V
5s
60
± 20
305
220
mA
Steady State
Unit
V
Document Number: 71434
S10-2432-Rev. D, 25-Oct-10
www.vishay.com
1
