GBPC1005, GBPC101, GBPC102, GBPC104, GBPC106, GBPC108, GBPC110
www.vishay.com
Vishay General Semiconductor
Glass Passivated Single-Phase Bridge Rectifier
~
~
~
Case Style GBPC1
FEATURES
• UL recognition, file number E54214
• Ideal for printed circuit boards
• Typical I
R
less than 0.1 μA
• High case dielectric strength
• High surge current capability
• Solder dip 275 °C max. 10 s, per JESD 22-B106
• Material categorization: For definitions of compliance
please see
www.vishay.com/doc?99912
e4
~
PRIMARY CHARACTERISTICS
Package
I
F(AV)
V
RRM
I
FSM
I
R
V
F
at I
F
= 1.5 A
T
J
max.
Diode variations
GBPC1
3A
50 V, 100 V, 200 V, 400 V, 600 V,
800 V, 1000 V
60 A
5 μA
1.0 V
150 °C
Quad
TYPICAL APPLICATIONS
General purpose use in AC/DC bridge full wave rectification
for switching power supply, home appliances, office
equipment, industrial automation applications.
MECHANICAL DATA
Case:
GBPC1
Molding compound meets UL 94 V-0 flammability rating
Base P/N-E4 - RoHS-compliant, commercial grade
Terminals:
Silver plated
J-STD-002 and JESD22-B102
leads,
solderable
per
Polarity:
As marked, positive lead by belevled corner
Mounting Torque:
10 cm-kg (8.8 inches-lbs) max.
Recommended Torque:
5.7 cm-kg (5 inches-lbs)
MAXIMUM RATINGS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Maximum repetitive peak reverse voltage
Maximum RMS bridge input voltage
Maximum DC blocking voltage
Maximum average forward
rectified output current at
T
C
= 60 °C
(1)
T
A
= 25 °C
(2)
SYMBOL
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
I
2
t
T
J
, T
STG
GBPC
1005
50
35
50
GBPC
101
100
70
100
GBPC
102
200
140
200
GBPC
104
400
280
400
3.0
2.0
60
15
- 55 to + 150
GBPC
106
600
420
600
GBPC
108
800
560
800
GBPC
110
1000
700
1000
UNIT
V
V
V
A
A
A
2
s
°C
Peak forward surge current single sine-wave
superimposed on rated load
Rating for fusing (t < 8.3 ms)
Operating junction and storage temperature
range
Notes
(1)
Unit mounted on 4.0" x 4.0" x 0.11" thick (10.5 cm x 10.5 cm x 0.3 cm) aluminum plate
(2)
Unit mounted on P.C.B. at 0.375" (9.5 mm) lead length with 0.5" x 0.5" (12 mm x 12 mm) copper pads
Revision: 08-Jul-13
Document Number: 88611
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
GBPC1005, GBPC101, GBPC102, GBPC104, GBPC106, GBPC108, GBPC110
www.vishay.com
Vishay General Semiconductor
GBPC
1005
GBPC
101
GBPC
102
GBPC
104
1.0
5.0
I
R
μA
500
C
J
21
pF
GBPC
106
GBPC
108
GBPC
110
ELECTRICAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Maximum instantaneous
forward voltage drop per
diode
Maximum DC reverse
current at rated DC blocking
voltage per diode
Typical junction capacitance
per diode
TEST CONDITIONS SYMBOL
I
F
= 1.5 A
T
A
= 25 °C
T
A
= 125 °C
4.0 V, 1 MHz
V
F
UNIT
V
THERMAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Typical thermal resistance
(1)
SYMBOL
R
JA
R
JC
GBPC
1005
GBPC
101
GBPC
102
GBPC
104
12
8.0
GBPC
106
GBPC
108
GBPC
110
UNIT
°C/W
Note
(1)
Bolt down on heat-sink with silicone thermal compound between bridge and mounting surface for maximum heat transfer with #6 screw
ORDERING INFORMATION
(Example)
PREFERRED P/N
GBPC106-E4/51
UNIT WEIGHT (g)
2.5
PREFERRED PACKAGE CODE
51
BASE QUANTITY
100
DELIVERY MODE
Paper box
RATINGS AND CHARACTERISTICS CURVES
(T
A
= 25 °C unless otherwise noted)
5.0
60
Average Forward Output Current (A)
Peak Forward Surge Current (A)
4.0
3.0
Case Temperature,
T
C
Heatsink Mounting
4.0 x 4.0 x 0.11" Thk.
(10.5 x 10.5 x 0.3 cm)
Al. Plate
60 Hz Resistive or
Inductive Load
T
C
= 60 °C
Single Sine-Wave
50
40
30
2.0
20
1.0
0
0
Ambient Temperature, T
A
P.C.B. Mounting
0.375"
(9.5 mm) Lead Length
50
100
150
10
1.0 Cycle
0
1
10
100
Ambient Temperature (°C)
Number
of Cycles at 60 Hz
Fig. 1 -
Derating Curve Output Rectified Current
Fig. 2 -
Maximum Non-Repetitive Peak Forward Surge
Current Per Diode
Revision: 08-Jul-13
Document Number: 88611
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
GBPC1005, GBPC101, GBPC102, GBPC104, GBPC106, GBPC108, GBPC110
www.vishay.com
Vishay General Semiconductor
100
100
Instantaneous Forward Current (A)
10
Junction Capacitance (pF)
T
J
= 25 °C
Pulse Width = 300 µs
1 % Duty Cycle
T
J
= 25 °C
f = 1.0 MHz
V
sig
= 50 mVp-p
1
10
0.1
0.01
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1
0.1
1
10
100
Instantaneous Forward Voltage (V)
Reverse Voltage (V)
Fig. 3 -
Typical Forward Characteristics Per Diode
Fig. 5 -
Typical Junction Capacitance Per Diode
100
100
10
T
J
= 125 °C
Transient Thermal Impedance (°C/W)
Instantaneous Reverse Current (µA)
10
1
1
0.1
T
J
= 25 °C
0.01
0
20
40
60
80
100
0.1
0.01
0.1
1
10
100
Percent of Rated Peak Reverse Voltage (%)
t - Heating Time (s)
Fig. 4 -
Typical Reverse Leakage Characteristics Per Diode
Fig. 6 -
Typical Transient Thermal Impedance Per Diode
PACKAGE OUTLINE DIMENSIONS
in inches (millimeters)
Case Style GBPC1
Hole For #6 Screw
0.158 (4.01)
DIA.
0.142 (3.61)
0.630 (16.00)
0.590 (14.98)
0.445 (11.30)
0.405 (10.29)
AC
0.630 (16.00)
0.590 (14.98)
0.445 (11.30)
0.405 (10.29)
AC
0.128 (3.25)
0.048 (1.22)
0.032 (0.81)
DIA.
0.028 (0.71)
0.094 (2.4) x 45°
0.040 (1.02) TYP.
0.750 (19.05)
MIN.
0.200 (5.08)
0.160 (4.06)
Polarity shown on side of case: Positive lead by beveled corner
Revision: 08-Jul-13
Document Number: 88611
3
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
