BAV70
www.vishay.com
Vishay Semiconductors
Small Signal Switching Diode, Dual
FEATURES
• Silicon epitaxial planar diode
3
• Fast switching dual diode with common
cathode
• AEC-Q101 qualified available
• Base P/N-E3 - RoHS-compliant, commercial
grade
• Base P/N-HE3 - RoHS-compliant, AEC-Q101 qualified
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
1
18108
2
DESIGN SUPPORT TOOLS
click logo to get started
Models
Available
MECHANICAL DATA
Case:
SOT-23
Weight:
approx. 8.8 mg
Packaging codes / options:
18/10K per 13" reel (8 mm tape), 10K/box
08/3K per 7" reel (8 mm tape), 15K/box
PARTS TABLE
PART
BAV70
ORDERING CODE
BAV70-E3-08 or BAV70-E3-18
BAV70-HE3-08 or BAV70-HE3-18
CIRCUIT CONFIGURATION
Common cathode
TYPE MARKING
JJ
REMARKS
Tape and reel
ABSOLUTE MAXIMUM RATINGS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Peak reverse voltage
Reverse voltage
Forward current (continuous)
t
p
= 1 μs
Non repetitive peak forward current
Power dissipation
(1)
TEST CONDITION
SYMBOL
V
RRM
V
R
I
F
I
FSM
I
FSM
I
FSM
P
tot
VALUE
70
70
250
2
1
0.5
350
UNIT
V
V
mA
A
A
A
mW
t
p
= 1 ms
t
p
= 1 s
Note
(1)
Device on fiberglass substrate
THERMAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Thermal resistance junction to ambient air
(1)
Junction temperature
Storage temperature range
Operating temperature range
Note
(1)
Device on fiberglass substrate
TEST CONDITION
SYMBOL
R
thJA
T
j
T
stg
T
op
VALUE
430
150
-65 to +150
-55 to +150
UNIT
K/W
°C
°C
°C
Rev. 2.2, 13-Feb-18
Document Number: 85546
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BAV70
www.vishay.com
Vishay Semiconductors
ELECTRICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
TEST CONDITION
I
F
= 1 mA
Forward voltage
I
F
= 10 mA
I
F
= 50 mA
I
F
= 150 mA
V
R
= 70 V
Reverse current
Diode capacitance
Reverse recovery time
V
R
= 70 V, T
j
= 150 °C
V
R
= 25 V, T
j
= 150 °C
V
R
= 0 V, f = 1 MHz
I
F
= 10 mA to i
R
= 1 mA,
V
R
= 6 V, R
L
= 100
SYMBOL
V
F
V
F
V
F
V
F
I
R
I
R
I
R
C
D
t
rr
MIN.
TYP.
MAX.
0.715
0.855
1
1.25
2500
50
30
1.5
6
UNIT
V
V
V
V
nA
μA
μA
pF
ns
TYPICAL CHARACTERISICS
(T
amb
= 25 °C, unless otherwise specified)
1000
10
2
D = 0.005
0.01
0.02
0.05
0.1
0.2
I
F
- Forward Current (mA)
100
T
j
= 100 °C
10
25 °C
1
10
-1
10
1
/
FM
10
0
0.1
t
p
D=
t
p
T
10
-3
T
10
-2
10
-1
s
10
-0
10
-2
10
-6
22290
0.01
0
14356
0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0
10
-5
10
-4
V
F
- Forward Voltage (V)
t
Fig. 1 - Forward Current vs. Forward Voltage
Fig. 2 - Peak forward current/
FM
= f (t
p
)
Rev. 2.2, 13-Feb-18
Document Number: 85546
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BAV70
www.vishay.com
PACKAGE DIMENSIONS
in millimeters (inches):
SOT-23
1.15 (0.045)
0.9 (0.035)
0.9 (0.035)
Vishay Semiconductors
0.1 (0.004) max.
3.1 (0.122)
2.8 (0.110)
0.550 ref. (0.022 ref.)
0.175 (0.007)
0.098 (0.004)
0.2 (0.008)
0.45 (0.018)
0.35 (0.014)
0.45 (0.018)
0.35 (0.014)
0.3 (0.012)
2.6 (0.102)
2.35 (0.093)
0.45 (0.018)
1.43 (0.056)
1.20 (0.047)
0.35 (0.014)
Foot print recommendation:
0.7 (0.028)
1 (0.039)
0.9 (0.035)
1 (0.039)
0.9 (0.035)
2 (0.079)
Document no.: 6.541-5014.01-4
Rev. 8 - Date: 23.Sept.2009
17418
0.95 (0.037)
0.95 (0.037)
Rev. 2.2, 13-Feb-18
Document Number: 85546
3
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
0° t
0.5 (0.020)
o8
°
