IHC Series
High
Current
A
B
0.50
Min.
C
D
CURRENTRATING Based on5%change frominitial inductance
at 0 ADC.
MARKING Part Number
PACKAGING Bulk only
INDUCTANCES 5 µH to 250 µH
OPERATING TEMPERATURE RANGE -55°C to +125°C.
PART
NUMBER
IHC-10A-5
IHC-9A-10
IHC-7A-27
IHC-5.6A-50
IHC-4.9A-100
IHC-4.6A-150
IHC-4A-250
IHC-14A-5
IHC-12A-10
IHC-9A-27
IHC-8A-50
IHC-7.3A-68
IHC-6.8A-100
IHC-6.3A-150
IHC-19A-5
IHC-16A-10
IHC-12.5A-27
IHC-10.5A-50
IHC-10A-65
IHC-10A-100
IHC-23A-5
IHC-20A-10
IHC-15A-27
IHC-15A-50
INDUCTANCE
µh ±20%
5
10
27
50
100
150
250
5
10
27
50
68
100
150
5
10
27
50
68
100
5
10
27
50
DC RESITANCE
OHMS
MAXIMUM (Ω )
0.013
0.017
0.03
0.045
0.061
0.069
0.089
0.009
0.012
0.022
0.028
0.034
0.038
0.046
0.006
0.008
0.014
0.02
0.023
0.027
0.004
0.006
0.01
0.013
Notes: P Number Descr
art
iption:
(1) Designa theAmps DC (Example “20A” f 20 amps DC)
tes
or
(2) Desig
antes the Inductance nominal.
(Example “10” or 10 µh
f
y)
(3) Polyolef n Shrnk tubing on the outside per
i
i
imeter
±10% o
.
ver
inductance range
RATED CURRENT
AMPS MAX.
(DC)
10
9
7
5.6
4.9
4.6
4
14
12
9
8
7.3
6.8
6.3
19
16
12.5
10.5
10
10
23
20
15
15
entir
e
DIMENSIONS
A
0.88
1.12
0.88
0.88
1.12
1.38
1.62
0.88
1.12
1.12
0.88
1.12
1.38
1.62
1.12
1.38
1.12
1.38
1.38
1.62
1.338
1.69
1.38
1.62
B
0.63
0.63
0.81
0.81
0.81
0.81
0.81
0.64
0.64
0.88
0.88
0.88
0.88
0.88
0.69
0.69
0.94
0.94
0.94
0.94
0.72
0.72
1
1
C
0.5
0.69
0.44
0.75
0.94
1.06
1.31
0.75
1
0.56
0.75
0.88
1
1.25
0.81
1.22
0.69
0.94
1.12
1.31
0.94
1.5
0.94
1.12
D
0.042
0.042
0.042
0.042
0.042
0.042
0.042
0.053
0.053
0.053
0.053
0.053
0.053
0.053
0.065
0.065
0.065
0.065
0.065
0.065
0.082
0.082
0.082
0.082
