PS2715-1-V-F4-A datasheet, PDF

Datasheet> All Categories > LED optoelectronic/LED> PS2715-1-V-F4-A

PS2715-1-V-F4-A: Description1 CHANNEL AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER; CategoryLED optoelectronic/LED; File Size232KB，10 Pages; ManufacturerCEL; Websitehttp://www.cel.com/

Download Datasheet Parametric Compare View All

PS2715-1-V-F4-A Overview

1 CHANNEL AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER

PS2715-1-V-F4-A Parametric

Parameter Name	Attribute value
Minimum operating temperature	-55 Cel
Maximum operating temperature	100 Cel
Processing package description	LEAD FREE, THIN, PLASTIC, SOP-4
each_compli	Yes
EU RoHS regulations	Yes
China RoHS regulations	Yes
state	Active
Optoelectronic device type	AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER
Minimum Coll-emtr Bkdn voltage	40 V
structure	SINGLE
Rated current transfer ratio	200 %
Maximum dark current	100 nA
forward_current_max	0.0500 A
Maximum insulation voltage	3750 V
jesd_609_code	e6
Number of components	1
terminal coating	TIN BISMUTH
dditional_feature	UL RECOGNIZED, VDE APPROVED

Preview

Download Datasheet

View All

PHOTOCOUPLER

PS2715-1

HIGH CTR, AC INPUT

4-PIN SOP PHOTOCOUPLER

−NEPOC

Series−

DESCRIPTION

The PS2715-1 is an optically coupled isolator containing GaAs light emitting diodes and an NPN silicon

phototransistor in a plastic SOP for high density applications.

The package is an SOP (Small Outline Package) type for high density mounting applications.

FEATURES

• AC input response

• High current transfer ratio (CTR = 200% TYP. @ I

±1

mA)

• High isolation voltage (BV = 3 750 Vr.m.s.)

• Small and thin package (4-pin SOP)

• Ordering number of tape product: PS2715-1-F3, F4

• Pb-Free product

• Safety standards

• UL approved: File No. E72422

• DIN EN60747-5-2 (VDE0884 Part2) approved (Option)

PIN CONNECTION

(Top View)

1. Anode, Cathode

2. Cathode, Anode

3. Emitter

4. Collector

APPLICATIONS

• Programmable logic controllers

• Modem/FAX

Document No. PN10247EJ02V0DS (2nd edition)

Date Published April 2005 CP(K)

The mark

shows major revised points.

PS2715-1-V-F4-A Related Products

	PS2715-1-V-F4-A	PS2715-1-F3	PS2715-1-V	PS2715-1	PS2715-1-F4	PS2715-1-V-F4	PS2715-1-V-F3	PS2715-1-V-A	PS2715-1-V-F3-A	PS2715-1-F4-A
Description	1 CHANNEL AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	1 CHANNEL AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	1 CHANNEL AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	1 CHANNEL AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	1 CHANNEL AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	1 CHANNEL AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	1 CHANNEL AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	1 CHANNEL AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	1 CHANNEL AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	1 CHANNEL AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER
Minimum operating temperature	-55 Cel	-55 Cel	-55 Cel	-55 Cel	-55 Cel	-55 Cel	-55 Cel	-55 Cel	-55 Cel	-55 Cel
Maximum operating temperature	100 Cel	100 Cel	100 Cel	100 Cel	100 Cel	100 Cel	100 Cel	100 Cel	100 Cel	100 Cel
Processing package description	LEAD FREE, THIN, PLASTIC, SOP-4	LEAD FREE, THIN, PLASTIC, SOP-4	LEAD FREE, THIN, PLASTIC, SOP-4	LEAD FREE, THIN, PLASTIC, SOP-4	LEAD FREE, THIN, PLASTIC, SOP-4	LEAD FREE, THIN, PLASTIC, SOP-4	LEAD FREE, THIN, PLASTIC, SOP-4	LEAD FREE, THIN, PLASTIC, SOP-4	LEAD FREE, THIN, PLASTIC, SOP-4	LEAD FREE, THIN, PLASTIC, SOP-4
each_compli	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
EU RoHS regulations	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
China RoHS regulations	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
state	Active	Active	Active	Active	Active	Active	Active	Active	Active	Active
Optoelectronic device type	AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER
Minimum Coll-emtr Bkdn voltage	40 V	40 V	40 V	40 V	40 V	40 V	40 V	40 V	40 V	40 V
structure	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE
Rated current transfer ratio	200 %	200 %	200 %	200 %	200 %	200 %	200 %	200 %	200 %	200 %
Maximum dark current	100 nA	100 nA	100 nA	100 nA	100 nA	100 nA	100 nA	100 nA	100 nA	100 nA
forward_current_max	0.0500 A	0.0500 A	0.0500 A	0.0500 A	0.0500 A	0.0500 A	0.0500 A	0.0500 A	0.0500 A	0.0500 A
Maximum insulation voltage	3750 V	3750 V	3750 V	3750 V	3750 V	3750 V	3750 V	3750 V	3750 V	3750 V
jesd_609_code	e6	e6	e6	e6	e6	e6	e6	e6	e6	e6
Number of components	1	1	1	1	1	1	1	1	1	1
terminal coating	TIN BISMUTH	TIN BISMUTH	TIN BISMUTH	TIN BISMUTH	TIN BISMUTH	TIN BISMUTH	TIN BISMUTH	TIN BISMUTH	TIN BISMUTH	TIN BISMUTH
dditional_feature	UL RECOGNIZED, VDE APPROVED	UL RECOGNIZED, VDE APPROVED	UL RECOGNIZED, VDE APPROVED	UL RECOGNIZED, VDE APPROVED	UL RECOGNIZED, VDE APPROVED	UL RECOGNIZED, VDE APPROVED	UL RECOGNIZED, VDE APPROVED	UL RECOGNIZED, VDE APPROVED	UL RECOGNIZED, VDE APPROVED	UL RECOGNIZED, VDE APPROVED
