EC3600ETTTS-16.000M TR
EC36 00 ET T TS -16.000M TR
Series
Quartz Crystal Clock Oscillators XO (SPXO) LVCMOS
(CMOS) 3.3Vdc 4 Pad 3.2mm x 5.0mm Ceramic
Surface Mount (SMD)
Frequency Tolerance/Stability
±100ppm Maximum
Operating Temperature Range
-40°C to +85°C
Packaging Options
Tape & Reel
Nominal Frequency
16.000MHz
Pin 1 Connection
Tri-State (High Impedance)
Duty Cycle
50 ±5(%)
ELECTRICAL SPECIFICATIONS
Nominal Frequency
Frequency Tolerance/Stability
16.000MHz
±100ppm Maximum (Inclusive of all conditions: Calibration Tolerance at 25°C, Frequency Stability over the
Operating Temperature Range, Supply Voltage Change, Ouput Load Change, First Year Aging at 25°C,
Shock, and Vibration)
-40°C to +85°C
3.3Vdc ±10%
10mA Maximum
90% of Vdd Minimum ((IOH = -4mA))
10% of Vdd Maximum ((IOL = +4mA))
6nSec Maximum (Measured at 20% to 80% of waveform)
50 ±5(%) (Measured at 50% of waveform)
15pF Maximum
CMOS
Tri-State (High Impedance)
90% of Vdd Minimum or No Connect to Enable Output, 10% of Vdd Maximum to Disable Output (High
Impedance)
10µA Maximum (Disabled Output: High Impedance)
1pSec Maximum (12kHz to 20MHz offset frequency)
10mSec Maximum
-55°C to +125°C
Operating Temperature Range
Supply Voltage
Input Current
Output Voltage Logic High (Voh)
Output Voltage Logic Low (Vol)
Rise/Fall Time
Duty Cycle
Load Drive Capability
Output Logic Type
Pin 1 Connection
Tri-State Input Voltage (Vih and Vil)
Standby Current
RMS Phase Jitter
Start Up Time
Storage Temperature Range
ENVIRONMENTAL & MECHANICAL SPECIFICATIONS
ESD Susceptibility
Fine Leak Test
Flammability
Gross Leak Test
Mechanical Shock
Moisture Resistance
Moisture Sensitivity
Resistance to Soldering Heat
Resistance to Solvents
Solderability
Temperature Cycling
Vibration
MIL-STD-883, Method 3015, Class 1, HBM: 1500V
MIL-STD-883, Method 1014, Condition A
UL94-V0
MIL-STD-883, Method 1014, Condition C
MIL-STD-883, Method 2002, Condition B
MIL-STD-883, Method 1004
J-STD-020, MSL 1
MIL-STD-202, Method 210, Condition K
MIL-STD-202, Method 215
MIL-STD-883, Method 2003
MIL-STD-883, Method 1010, Condition B
MIL-STD-883, Method 2007, Condition A
www.ecliptek.com | Specification Subject to Change Without Notice | Revision L 06/13/2012 | Page 1 of 7
EC3600ETTTS-16.000M TR
Test Circuit for CMOS Output
Oscilloscope
Frequency
Counter
+
+
Power
Supply
_
+
Voltage
Meter
_
Current
Meter
_
Supply
Voltage
(V
DD
)
Probe
(Note 2)
Output
0.01µF
(Note 1)
0.1µF
(Note 1)
Ground
C
L
(Note 3)
No Connect
or Tri-State
Note 1: An external 0.1µF low frequency tantalum bypass capacitor in parallel with a 0.01µF high frequency
ceramic bypass capacitor close to the package ground and V
DD
pin is required.
Note 2: A low capacitance (<12pF), 10X attenuation factor, high impedance (>10Mohms), and high bandwidth
(>300MHz) passive probe is recommended.
Note 3: Capacitance value C
L
includes sum of all probe and fixture capacitance.
www.ecliptek.com | Specification Subject to Change Without Notice | Revision L 06/13/2012 | Page 4 of 7
