TMR
low ESR tantalum chip capacitor
features
•
•
•
•
•
•
Low ESR type
Epoxy molded body, UL94V0 flammability
EIA-US and EIA-Japan compatible sizes
Extended values per case size
Excellent humidity and solder resistance
Marking: Black body color with white marking
dimensions and construction
Case Size
(Inch Size Code)
capacitance ranges
and case sizes
d
g
Voltage Code
0G 0J 1A 1C
Rated Voltage
4 6.3 10 16
Recommended Max
2 2.5 3.5 5
Capacitance (µF) Code
10
106
B
B
B
15
156
B
B
C
22
226
B
C
C
33
336
C
C
E
47
476 B
C
E
E
68
686
E
E
E
100
107
E
E
E
150
157
E
E
220
227
E
E
330
337
E
1D
20
6
C
C
E
E
1E 1V
25 35
8 12
E
E
E
E
L
W
Dimensions
inches
(mm)
t
a
b
c
B
(3528)
C
(6032)
capacitors
.138±.008 .110±.008 .075±.008 .079±.008 .028±.008 .087±.004 .031±.012 .055±.008
(3.5±0.2) (2.8±0.2) (1.9±0.2) (2.0±0.2) (0.7±0.2) (2.2±0.1) (0.8±0.3) (1.4±0.2)
.236±.008 .126±.008 .098±.008 .087±.008 .028±.008 .087±.004 .051±.012 .094±.008
.6.0±0.2)
(3.2±0.2) (2.5±0.2) (2.2±0.2) (0.7±0.2) (2.2±0.1) (1.3±0.3) (2.4±0.2)
.287±.008 .169 ±.012 .110±.008 .118±.008 .047±.008 .094±.004 .051±.012 .149±.008
(7.3±0.2) (4.3±0.3) (2.8±0.2) (3.0±0.2) (1.2±0.2) (2.4±0.1) (1.3±0.3) (3.8±0.2)
E
(7343)
L
t
-
d
g
d
b
c a
b
a
W
t
+
-
d
L
W
b
g
d
c
a
+
c
c
B, C Case
E Case
ordering information
New Part #
TMR
Type
1C
Voltage
Code
0G: 4V
0J: 6.3V
1A: 10V
1C: 16V
1D: 20V
1E: 25V
1V: 35V
B
Case Size
B: 3528
C: 6032
E: 7343
T
Termination
Material
T: Sn
L: SnPb
TE
Packaging
TE: 7" embossed
plastic
106
Nominal
Capacitance
Reference
capacitance
ranges and
case sizes
chart
M
Tolerance
K: ±10%
M:±20%
R
Polarity
Orientation
For further information on packaging,
please refer to Appendix A.
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
10/05/04
194
KOA Speer Electronics, Inc.
• Bolivar Drive • P Box 547 • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
