PLL602-00
Multiplier XO IC Die for 12 to 25MHz Parallel Resonant Crystals
FEATURES
•
•
•
•
•
•
Integrated crystal oscillator circuitry (XO).
Low phase noise (-135dBc @ 10kHz offset)
selectable frequency multipliers (x1, x2, x4, x8
as bonding options).
3.3V supply voltage.
Uses inexpensive fundamental-mode parallel
resonant crystals (from 12 to 25MHz).
Selectable High Drive (30mA) or Standard Drive
(10mA) output.
Available in DIE (65 mil x 62 mil).
DIE CONFIGURATION
65 mil
VDD
VDD
OE^
S0
V
S1
V
S2
V
(1550,1475)
25
23
21
20
19
18
Die ID:
A0303-03H
XIN
27
62 mil
13
CLK
XOUT
29
DESCRIPTION
The PLL602-00 is a monolithic low jitter and low
phase noise (-135dBc @10kHz offset), high
performance CMOS XO IC. This flexible device can
be used as a XO with output frequencies ranging
from F
XIN
x 1 to F
XIN
x 8 thanks to selector pads
allowing bonding options (see Divider Selection
Table on this page). This makes the PLL602-00 ideal
for a wide range of applications from 12MHz to
200MHz (including 50MHz, 77.76MHz, 125MHz and
155.52MHz, etc.).
Y
X
(0,0)
C502A
7
10
GND
Note:
^ denotes internal pull up
V
denotes internal pull down
MULTIPLIER SELECTION
SELECTION
S2
S1
S0
0
0
0
0
0
1
0
1
0
1
0
0
0
1
1
1
1
0
1
0
1
1
1
1
F
XIN
CLK (MHz)
F
XIN
x 2
F
XIN
x 4
F
XIN
x 1
F
XIN
x 8
F
XIN
x 2*
F
XIN
x 4*
F
XIN
x 1*
F
XIN
x 8*
BLOCK DIAGRAM
S[0:2]
12MHz – 25MHz
XIn
XO
XOut
Selectable
PLL
CLK
Note: -
Selector pads default to ‘0’, wire bond to VDD to set to ‘1’
- (*) High-drive CMOS output
PAD DESCRIPTION
Name
Number
Description
XIN
27
29
7,10
13
18,19,20
21,22,23
25
Crystal input connection.
Crystal connection.
Ground.
Clock Output.
Frequency selection pad
3.3V Power Supply.
Output Enable: ‘0’ to disable (tri-
state output), 1’ (default value
when not connected) to enabled
the output.
DIE SPECIFICATIONS
Name
Value
XOUT
GND
CLK
S[0:2]
VDD
OE
Size
Reverse side
Pad dimensions
Thickness
62 x 65 mil
GND
80 micron x 80 micron
10 mil
47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991
www.phaselink.com
Rev 09/03/04 Page 1
GND
PLL602-00
Multiplier XO IC Die for 12 to 25MHz Parallel Resonant Crystals
ELECTRICAL SPECIFICATIONS
1. Absolute Maximum Ratings
PARAMETERS
Supply Voltage
Input Voltage, dc
Output Voltage, dc
Storage Temperature
Ambient Operating Temperature*
Junction Temperature
Lead Temperature (soldering, 10s)
ESD Protection, Human Body Model
SYMBOL
V
DD
V
I
V
O
T
S
T
A
T
J
MIN.
-0.5
-0.5
-65
-40
MAX.
4.6
V
DD
+0.5
V
DD
+0.5
150
85
125
260
2
UNITS
V
V
V
°C
°C
°C
°C
kV
Exposure of the device under conditions beyond the limits specified by Maximum Ratings for extended periods may cause permanent damage to the
device and affect product reliability. These conditions represent a stress rating only, and functional operations of the device at these or any other
conditions above the operational limits noted in this specification is not implied.
*
Note:
Operating Temperature is guaranteed by design for all parts (COMMERCIAL and INDUSTRIAL), but tested for COMMERCIAL grade only.
2. DC Electrical Specifications
PARAMETERS
Supply Current, Dynamic, with
Loaded Outputs
Operating Voltage
Output drive current
(High Drive)
Output drive current
(Standard Drive)
Short Circuit Current
SYMBOL
I
DD
V
DD
I
OH
I
OL
I
OH
I
OL
CONDITIONS
F
XIN
= 12 - 25MHz
Output load of 10pF
V
OH
= V
DD
-0.4V, V
DD
=3.3V
V
OL
= 0.4V, V
DD
= 3.3V
V
OH
= V
DD
-0.4V, V
DD
=3.3V
V
OL
= 0.4V, V
DD
= 3.3V
MIN.
TYP.
16
MAX.
20
3.63
UNITS
mA
V
mA
mA
mA
mA
mA
2.97
30
30
10
10
±50
3. AC Electrical Specifications
PARAMETERS
Input Crystal Frequency
Output Clock Rise/Fall Time
(Standard Drive)
Output Clock Rise/Fall Time
(High Drive)
Output Clock Duty Cycle
SYMBOL
CONDITIONS
0.3V ~ 3.0V with 15 pF load
0.3V ~ 3.0V with 15 pF load
Measured @ 50% V
DD
MIN.
12
TYP.
2.4
1.2
MAX.
25
UNITS
MHz
ns
45
50
55
%
47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991
www.phaselink.com
Rev 09/03/04 Page 2
PLL602-00
Multiplier XO IC Die for 12 to 25MHz Parallel Resonant Crystals
4. Crystal Specifications
PARAMETERS
Crystal Resonator Frequency
Crystal Loading Rating
Recommended ESR
SYMBOL
F
XIN
C
L (xtal)
R
E
CONDITIONS
Parallel Fundamental Mode
AT cut
MIN.
12
20
30
TYP.
MAX.
25
UNITS
MHz
pF
Ω
5. Jitter and Phase Noise Specification
PARAMETERS
CONDITIONS
at 155MHz, with capacitive decoupling
between VDD and GND.
RMS Period Jitter
(1 sigma – 1000 samples)
at 80MHz, with capacitive decoupling
between VDD and GND.
at 44MHz, with capacitive decoupling
between VDD and GND.
Phase Noise relative to carrier
Phase Noise relative to carrier
Phase Noise relative to carrier
Phase Noise relative to carrier
Phase Noise relative to carrier
Phase Noise relative to carrier
Phase Noise relative to carrier
Phase Noise relative to carrier
Phase Noise relative to carrier
Phase Noise relative to carrier
44MHz @100Hz offset
44MHz @1kHz offset
44MHz @10kHz offset
44MHz @100kHz offset
44MHz @1MHz offset
155MHz @100Hz offset
155MHz @1kHz offset
155MHz @10kHz offset
155MHz @100kHz offset
155MHz @1MHz offset
MIN.
TYP.
4
3
2.5
-80
-110
-135
-130
-132
-80
-110
-125
-120
-125
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
ps
MAX.
UNITS
47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991
www.phaselink.com
Rev 09/03/04 Page 3
PLL602-00
Multiplier XO IC Die for 12 to 25MHz Parallel Resonant Crystals
PAD ASSIGNMENT
Pad #
7
10
13
18
19
20
21
23
25
27
29
Name
GND
GND
CLK
S2
S1
S0
VDD
VDD
OE
XIN
XOUT
X (µm)
1042
1400
1400
1232
1042
854
659
459
194
109
109
Y (µm)
109
259
716
1365
1365
1365
1365
1365
1365
1017
646
Ground.
Ground.
CMOS clock output.
Used to select multiplication factor and drive level. Internal pull
down.
Used to select multiplication factor and drive level. Internal pull
down.
Used to select multiplication factor and drive level. Internal pull
down.
3.3V power supply.
3.3V power supply.
Used to enable/disable the output(s). Internal pull up.
Crystal input. See crystal specification page 3.
Crystal output. See crystal specification page 3.
Description
ORDERING INFORMATION
For part ordering, please contact our Sales Department:
47745 Fremont Blvd., Fremont, CA 94538, USA
Tel: (510) 492-0990 Fax: (510) 492-0991
PART NUMBER
The order number for this device is a combination of the following:
Device number, Package type and Operating temperature range
PLL602-00 D C
PART NUMBER
TEMPERATURE
C=COMMERCIAL
I=INDUSTRAL
PACKAGE TYPE
D=DIE
Order Number
PLL602-00DC
Marking
P602-00DC
Package Option
Die – Waffle Pack
PhaseLink Corporation, reserves the right to make changes in its products or specifications, or both at any time without notice. The information
furnished by Phaselink is believed to be accurate and reliable. However, PhaseLink makes no guarantee or warranty concerning the accuracy of said
information and shall not be responsible for any loss or damage of whatever nature resulting from the use of, or reliance upon this product.
LIFE SUPPORT POLICY:
PhaseLink’s products are not authorized for use as critical components in life support devices or systems
without the express written approval of the President of PhaseLink Corporation.
47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991
www.phaselink.com
Rev 09/03/04 Page 4
