FE
CONNECTOR
NON-
1.25mm pitch/Connectors for FFC
Specifications –––––––––––––––––––
• Current rating: 1.0A AC, DC
• Voltage rating: 200V AC, DC
• Temperature range: -25˚C to+85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/20m
Ω
max.
After environmental testing/30m
Ω
max.
• Insulation resistance:
1,000M
Ω
min.
• Withstanding voltage: 500V AC/minute
• Applicable FFC:
Conductor pitch/1.25mm
Conductor width/0.8mm
Mating part thickness/0.3±0.05mm
Note
:
FFC to be actually used should be checked for applicability.
The FE connector ensures easy, secure
connection of flexible flat cables (FFC).
This compact connector is 4.8mm wide,
7.5mm high, and provides high contact
pressure even though little force is
required for insertion. The result is smooth
insertion and reliable contact performance.
The connector is useful in making
personal computers, VCRs and car stereo
systems smaller and lighter.
• Low insertion force and high contact
pressure
• Snap-in connection
• Temporary board retention feature
• Applicable PC board thickness: 1.2 to 1.6mm
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
Standards ––––––––––––––––––––––
1
Certified LR20812
Side entry type
0
Recognized E60389
PC board layout (viewed from component side) and Assembly layout
Top entry type
4.8
1.25
±0.05
φ0.8
＋0.1
0
2.5
±0.05
1.25
±0.05
Contact
point
2.5
±0.05
φ0.8
＋0.1
0
7.5
7.5
Circuit No.1
2.5
±0.05
Circuit No.1
2.5
±0.05
1.175
6.5
Note: 1. Tolerances are non-cumulative:
±
0.05mm for all centers.
2. Hole dimensions differ according to the kind of PC board and piercing method. The dimensions above should serve as a guideline. Contact JST for details.
4.8
Contact
point
1
FE CONNECTOR
Connector
Top entry type
Circuits
4
5
B
C
A
1.25
6
7
1.125
7.5
3.5
8
9
10
11
12
13
14
15
16
17
18
Circuit No.1
1.5
Circuit No.1
Side entry type
19
20
21
22
B
C
A
1.25
9.1
7.5
23
24
25
26
27
28
29
3.1
1.5
30
31
2.5
Circuit No.1
Circuit No.1
32
33
34
35
36
37
38
39
40
Model No.
Top entry type
Side entry type
04FE-BT-VK-N 04FE-ST-VK-N
05FE-BT-VK-N 05FE-ST-VK-N
06FE-BT-VK-N 06FE-ST-VK-N
07FE-BT-VK-N 07FE-ST-VK-N
08FE-BT-VK-N 08FE-ST-VK-N
09FE-BT-VK-N 09FE-ST-VK-N
10FE-BT-VK-N 10FE-ST-VK-N
11FE-BT-VK-N 11FE-ST-VK-N
12FE-BT-VK-N 12FE-ST-VK-N
13FE-BT-VK-N 13FE-ST-VK-N
14FE-BT-VK-N 14FE-ST-VK-N
15FE-BT-VK-N 15FE-ST-VK-N
16FE-BT-VK-N 16FE-ST-VK-N
17FE-BT-VK-N 17FE-ST-VK-N
18FE-BT-VK-N 18FE-ST-VK-N
19FE-BT-VK-N 19FE-ST-VK-N
20FE-BT-VK-N 20FE-ST-VK-N
21FE-BT-VK-N 21FE-ST-VK-N
22FE-BT-VK-N 22FE-ST-VK-N
23FE-BT-VK-N 23FE-ST-VK-N
24FE-BT-VK-N 24FE-ST-VK-N
25FE-BT-VK-N 25FE-ST-VK-N
26FE-BT-VK-N 26FE-ST-VK-N
27FE-BT-VK-N 27FE-ST-VK-N
28FE-BT-VK-N 28FE-ST-VK-N
29FE-BT-VK-N 29FE-ST-VK-N
30FE-BT-VK-N 30FE-ST-VK-N
31FE-BT-VK-N 31FE-ST-VK-N
32FE-BT-VK-N 32FE-ST-VK-N
33FE-BT-VK-N 33FE-ST-VK-N
34FE-BT-VK-N 34FE-ST-VK-N
35FE-BT-VK-N 35FE-ST-VK-N
36FE-BT-VK-N 36FE-ST-VK-N
37FE-BT-VK-N 37FE-ST-VK-N
38FE-BT-VK-N 38FE-ST-VK-N
39FE-BT-VK-N 39FE-ST-VK-N
40FE-BT-VK-N 40FE-ST-VK-N
Dimensions (mm)
A
B
C
3.75
5.00
6.25
7.50
8.75
10.00
11.25
12.50
13.75
15.00
16.25
17.50
18.75
20.00
21.25
22.50
23.75
25.00
26.25
27.50
28.75
30.00
31.25
32.50
33.75
35.00
36.25
37.50
38.75
40.00
41.25
42.50
43.75
45.00
46.25
47.50
48.75
8.55
9.80
11.05
12.30
13.55
14.80
16.05
17.30
18.55
19.80
21.05
22.30
23.55
24.80
26.05
27.30
28.55
29.80
31.05
32.30
33.55
34.80
36.05
37.30
38.55
39.80
41.05
42.30
43.55
44.80
46.05
47.30
48.55
49.80
51.05
52.30
53.55
6.35
7.60
8.85
10.10
11.35
12.60
13.85
15.10
16.35
17.60
18.85
20.10
21.35
22.60
23.85
25.10
26.35
27.60
28.85
30.10
31.35
32.60
33.85
35.10
36.35
37.60
38.85
40.10
41.35
42.60
43.85
45.10
46.35
47.60
48.85
50.10
51.35
Q'ty / box
Top entry Side entry
type
type
2,350
2,000
1,800
1,600
1,500
1,350
1,250
1,150
1,100
1,000
950
900
850
800
750
700
700
650
650
600
600
550
550
500
500
500
450
450
450
450
400
400
400
400
350
350
350
1,410
1,200
1,080
960
900
810
750
690
660
600
570
540
510
480
450
420
420
390
390
360
360
330
330
300
300
300
270
270
270
270
240
240
240
240
210
210
210
4.8
4.0
4.8
4.0
2.5
Material and Finish
Contact: Copper alloy, tin-plated (reflow treatment)
Housing: PBT, UL94V-0, white
RoHS compliance
Note: 33 to 40 circuits products are not UL/CSA approved.
Lead section dimensions of FFC
1.25×(N＋1)
＋0.05
−0.2
1.25
±0.2
1.25×(
N
−1)
±0.15
1.25
±0.1
0.8
±0.1
1.25
±0.2
0.30
±0.05
5.0min
Conductor
Film cover layer
Note: N --- Number of circuits
2
（7.0）
Reinforcing layer
