HCPL-9000/-0900, -9030/-0930,
HCPL-9031/-0931, -900J/-090J,
HCPL-901J/-091J, -902J/-092J
High Speed Digital Isolators
Data Sheet
Lead (Pb) Free
RoHS 6 fully
compliant
RoHS 6 fully compliant options available;
-xxxE denotes a lead-free product
Description
The HCPL-90xx and HCPL-09xx CMOS digital isolators
feature high speed performance and excellent transient
immunity specifications. The symmetric magnetic
coupling barrier gives these devices a typical pulse width
distortion of 2 ns, a typical propagation delay skew of
4 ns and 100 Mbaud data rate, making them the indus-
try’s fastest digital isolators.
The single channel digital isolators (HCPL-9000/
-0900) features an active-low logic output enable.
The dual channel digital isolators are configured as
unidirectional (HCPL-9030/-0930) and bi-directional
(HCPL-9031/-0931), operating in full duplex mode making
it ideal for digital fieldbus applications.
The quad channel digital isolators are configured as
unidirectional (HCPL-900J/-090J), two channels in one
direction and two channels in opposite direction (HCPL-
901J/-091J), and one channel in one direction and
three channels in opposite direction (HCPL-902J/-092J).
These high channel density make them ideally suited
to isolating data conversion devices, parallel buses and
peripheral interfaces.
They are available in 8-pin PDIP, 8-pin Gull Wing, 8-pin
SOIC packages, and 16–pin SOIC narrow-body and
wide-body packages. They are specified over the tem-
perature range of -40°C to +100°C.
Features
•
+3.3V and +5V TTL/CMOS compatible
•
3 ns max. pulse width distortion
•
6 ns max. propagation delay skew
•
15 ns max. propagation delay
•
High speed: 100 MBd
•
15 kV/µs min. common mode rejection
•
Tri-state output (HCPL-9000/-0900)
•
2500 V RMS isolation
•
UL1577 and IEC 61010-1 approved
Applications
•
Digital fieldbus isolation
•
Multiplexed data transmission
•
Computer peripheral interface
•
High speed digital systems
•
Isolated data interfaces
•
Logic level shifting
CAUTION:
It is advised that normal static precautions be taken in handling and assembly
of this component to prevent damage and/or degradation which may be induced by ESD.
Selection Guide
Device Number
HCPL-9000
HCPL-0900
HCPL-9030
HCPL-0930
HCPL-9031
HCPL-0931
HCPL-900J
HCPL-090J
HCPL-901J
HCPL-091J
HCPL-902J
HCPL-092J
Channel Configuration
Single
Single
Dual
Dual
Dual, Bi-Directional
Dual, Bi-Directional
Quad
Quad
Quad, 2/2, Bi-Directional
Quad, 2/2, Bi-Directional
Quad, 1/3, Bi-Directional
Quad, 1/3, Bi-Directional
Package
8-pin DIP (300 Mil)
8-pin Small Outline
8-pin DIP (300 Mil)
8-pin Small Outline
8-pin DIP (300 Mil)
8-pin Small Outline
16-pin Small Outline, Wide Body
16-pin Small Outline, Narrow Body
16-pin Small Outline, Wide Body
16-pin Small Outline, Narrow Body
16-pin Small Outline, Wide Body
16-pin Small Outline, Narrow Body
Ordering Information
HCPL-09xx and HCPL-90xx are UL Recognized with 2500 V
rms
for 1 minute per UL1577.
Option
Part number
HCPL-9000
HCPL-9030
HCPL-9031
HCPL-0900
HCPL-0930
HCPL-0931
HCPL-900J
HCPL-901J
HCPL-902J
HCPL-090J
HCPL-091J
HCPL-092J
RoHS
Compliant
-000E
-300E
-500E
-000E
-500E
-000E
-500E
-000E
-500E
Non RoHS
Compliant
No option
-300
-500
No option
-500
No option
-500
No option
-500
Package
300mil
DIP-8
Surface
Mount
X
X
X
X
X
X
X
X
Gull
Wing
X
X
Tape &
Reel
Quantity
50 per tube
50 per tube
X
X
X
X
1000 per reel
100 per tube
1500 per reel
50 per tube
1000 per reel
50 per tube
1000 per reel
SO-8
Wide Body
SO-16
Narrow Body
SO-16
To order, choose a part number from the part number column and combine with the desired option from the option
column to form an order entry.
Example 1:
HCPL-9031-500E to order product of 300mil DIP Gull Wing Surface Mount package in Tape and Reel in RoHS
compliant.
Example 2:
HCPL-0900 to order product of SO-8 package in tube packaging and non RoHS compliant.
Option datasheets are available. Contact your Avago sales representative or authorized distributor for information.
