MC74HC03A
Quad 2-Input NAND Gate
with Open-Drain Outputs
High–Performance Silicon–Gate CMOS
The MC74HC03A is identical in pinout to the LS03. The device
inputs are compatible with Standard CMOS outputs; with pullup
resistors, they are compatible with LSTTL outputs.
The HC03A NAND gate has, as its outputs, a high–performance
MOS N–Channel transistor. This NAND gate can, therefore, with a
suitable pullup resistor, be used in wired–AND applications. Having
the output characteristic curves given in this data sheet, this device can
be used as an LED driver or in any other application that only requires
a sinking current.
•
Output Drive Capability: 10 LSTTL Loads With Suitable Pullup
Resistor
•
Outputs Directly Interface to CMOS, NMOS and TTL
•
High Noise Immunity Characteristic of CMOS Devices
•
Operating Voltage Range: 2 to 6V
•
Low Input Current: 1µA
•
In Compliance With the JEDEC Standard No. 7A Requirements
•
Chip Complexity: 28 FETs or 7 Equivalent Gates
DESIGN GUIDE
Criteria
Internal Gate Count*
Internal Gate Propagation Delay
Internal Gate Power Dissipation
Speed Power Product
* Equivalent to a two–input NAND gate
Value
7.0
1.5
5.0
0.0075
Unit
ea
ns
µW
pJ
http://onsemi.com
MARKING
DIAGRAMS
14
PDIP–14
N SUFFIX
CASE 646
MC74HC03AN
AWLYYWW
1
14
SOIC–14
D SUFFIX
CASE 751A
1
14
TSSOP–14
DT SUFFIX
CASE 948G
HC
03A
ALYW
HC03A
AWLYWW
1
A
= Assembly Location
WL or L = Wafer Lot
YY or Y = Year
WW or W = Work Week
FUNCTION TABLE
Inputs
Output
B
L
H
L
H
Y
Z
Z
Z
L
LOGIC DIAGRAM
OUTPUT
PROTECTION
DIODE
VCC
A
L
L
H
H
PIN 14 = VCC
PIN 7 = GND
* Denotes open–drain outputs
3,6,8,11
Y*
Z = High Impedance
A
B
1,4,9,12
2,5,10,13
Pinout: 14–Lead Packages
(Top View)
VCC
14
B4
13
A4
12
Y4
11
B3
10
A3
9
Y3
8
ORDERING INFORMATION
Device
MC74HC03AN
MC74HC03AD
MC74HC03ADR2
MC74HC03ADT
Package
PDIP–14
SOIC–14
SOIC–14
TSSOP–14
TSSOP–14
Shipping
2000 / Box
55 / Rail
2500 / Reel
96 / Rail
2500 / Reel
1
A1
2
B1
3
Y1
4
A2
5
B2
6
Y2
7
GND
MC74HC03ADTR2
©
Semiconductor Components Industries, LLC, 2000
1
March, 2000 – Rev. 8
Publication Order Number:
MC74HC03A/D
MC74HC03A
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎ
Î Î
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î Î
Î
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎ Î
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
ÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
MAXIMUM RATINGS*
Symbol
VCC
Vin
Parameter
Value
Unit
V
V
V
DC Supply Voltage (Referenced to GND)
DC Input Voltage (Referenced to GND)
– 0.5 to + 7.0
– 0.5 to VCC + 0.5
– 0.5 to VCC + 0.5
±
20
±
25
±
50
750
500
450
Vout
Iin
DC Output Voltage (Referenced to GND)
DC Input Current, per Pin
mA
mA
mA
Iout
DC Output Current, per Pin
ICC
PD
DC Supply Current, VCC and GND Pins
Power Dissipation in Still Air
Plastic DIP†
SOIC Package†
TSSOP Package†
mW
Tstg
TL
Storage Temperature
– 65 to + 150
260
This device contains protection
circuitry to guard against damage
due to high static voltages or electric
fields. However, precautions must
be taken to avoid applications of any
voltage higher than maximum rated
voltages to this high–impedance cir-
cuit. For proper operation, Vin and
Vout should be constrained to the
range GND (Vin or Vout) VCC.
Unused inputs must always be
tied to an appropriate logic voltage
level (e.g., either GND or VCC).
Unused outputs must be left open.
v
v
_
C
_
C
Lead Temperature, 1 mm from Case for 10 Seconds
Plastic DIP, SOIC or TSSOP Package
*Maximum Ratings are those values beyond which damage to the device may occur.
Functional operation should be restricted to the Recommended Operating Conditions.
†Derating — Plastic DIP: – 10 mW/
_
C from 65
_
to 125
_
C
SOIC Package: – 7 mW/
_
C from 65
_
to 125
_
C
TSSOP Package: – 6.1 mW/
_
C from 65
_
to 125
_
C
For high frequency or heavy load considerations, see Chapter 2 of the ON Semiconductor High–Speed CMOS Data Book (DL129/D).
ÎÎÎÎ
Î
Î
Î
Î Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎ Î
ÎÎÎÎ Î
ÎÎ Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎ Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎ Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎ Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎ Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎ Î
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
Symbol
VCC
Parameter
Min
2.0
0
Max
6.0
Unit
V
V
DC Supply Voltage (Referenced to GND)
Vin, Vout
TA
DC Input Voltage, Output Voltage (Referenced to GND)
Operating Temperature, All Package Types
Input Rise and Fall Time
(Figure 1)
VCC
– 55
0
0
0
+ 125
1000
500
400
RECOMMENDED OPERATING CONDITIONS
_
C
ns
tr, tf
VCC = 2.0 V
VCC = 4.5 V
VCC = 6.0 V
DC CHARACTERISTICS
(Voltages Referenced to GND)
Symbol
VIH
Parameter
Minimum High–Level Input
Voltage
Condition
Vout = 0.1V or VCC –0.1V
|Iout|
≤
20µA
VCC
V
2.0
3.0
4.5
6.0
2.0
3.0
4.5
6.0
2.0
4.5
6.0
3.0
4.5
6.0
6.0
6.0
6.0
Guaranteed Limit
–55 to 25°C
1.50
2.10
3.15
4.20
0.50
0.90
1.35
1.80
0.1
0.1
0.1
0.26
0.26
0.26
±0.1
1.0
±0.5
≤85°C
1.50
2.10
3.15
4.20
0.50
0.90
1.35
1.80
0.1
0.1
0.1
0.33
0.33
0.33
±1.0
10
±5.0
≤125°C
1.50
2.10
3.15
4.20
0.50
0.90
1.35
1.80
0.1
0.1
0.1
0.40
0.40
0.40
±1.0
40
±10
µA
µA
µA
Unit
V
VIL
Maximum Low–Level Input
Voltage
Vout = 0.1V or VCC – 0.1V
|Iout|
≤
20µA
V
VOL
Maximum Low–Level Output
Voltage
Vout = 0.1V or VCC – 0.1V
|Iout|
≤
20µA
Vin = VIH or VIL
|Iout|
≤
2.4mA
|Iout|
≤
4.0mA
|Iout|
≤
5.2mA
V
Iin
ICC
IOZ
Maximum Input Leakage Current
Maximum Quiescent Supply
Current (per Package)
Maximum Three–State Leakage
Current
Vin = VCC or GND
Vin = VCC or GND
Iout = 0µA
Output in High–Impedance State
Vin = VIL or VIH
Vout = VCC or GND
NOTE: Information on typical parametric values can be found in Chapter 2 of the ON Semiconductor High–Speed CMOS Data Book (DL129/D).
http://onsemi.com
2
MC74HC03A
AC CHARACTERISTICS
(CL = 50pF, Input tr = tf = 6ns)
Symbol
tPLZ,
tPZL
Parameter
Maximum Propagation Delay, Input A or B to Output Y
(Figures 1 and 2)
VCC
V
2.0
3.0
4.5
6.0
2.0
3.0
4.5
6.0
Guaranteed Limit
–55 to 25°C
120
45
24
20
75
27
15
13
10
10
≤85°C
150
60
30
26
95
32
19
16
10
10
≤125°C
180
75
36
31
110
36
22
19
10
10
Unit
ns
tTLH,
tTHL
Maximum Output Transition Time, Any Output
(Figures 1 and 2)
ns
Cin
Cout
Maximum Input Capacitance
Maximum Three–State Output Capacitance
(Output in High–Impedance State)
pF
pF
NOTE: For propagation delays with loads other than 50 pF, and information on typical parametric values, see Chapter 2 of the ON
Semiconductor High–Speed CMOS Data Book (DL129/D).
Typical @ 25°C, VCC = 5.0 V, VEE = 0 V
CPD
Power Dissipation Capacitance (Per Buffer)*
8.0
pF
* Used to determine the no–load dynamic power consumption: PD = CPD VCC2f + ICC VCC. For load considerations, see Chapter 2 of the
ON Semiconductor High–Speed CMOS Data Book (DL129/D).
http://onsemi.com
3
MC74HC03A
VCC
tr
INPUT A
90%
50%
10%
tPZL
OUTPUT Y
90%
50%
10%
tTHL
tPLZ
tf
VCC
GND
HIGH
IMPEDANCE
10%
VOL
*Includes all probe and jig capacitance
DEVICE
UNDER
TEST
1kΩ
OUTPUT
Rpd
TEST
POINT
CL*
Figure 1. Switching Waveforms
25
TYPICAL
T=25°C
20
I D, SINK CURRENT (mA)
T=25°C
15
T=85°C
10
T=125°C
EXPECTED MINIMUM*
5
VCC=5V
Figure 2. Test Circuit
0
0
1
2
3
4
VO, OUTPUT VOLTAGE (VOLTS)
5
*The expected minimum curves are not guarantees, but are design aids.
Figure 3. Open–Drain Output Characteristics
VCC
PULLUP
RESISTOR
A1
B1
A2
B2
1/4
HC03
1/4
HC03
Y1
VCC
+
VR
–
+
VF
–
LED1
1/4
HC03
1/4
HC03
VCC
OUTPUT
Y2
LED2
LED
ENABLE
DESIGN EXAMPLE
CONDITIONS: ID 10mA
USING FIGURE NO TAG TYPICAL
CURVE, at ID=10mA, VDS 0.4V
^
An
Bn
1/4
HC03
Yn
OUTPUT = Y1
•
Y2
•
. . .
•
Yn
= A1B1
•
A2B2
•
. . .
•
AnBn
N
R
+
VCC
*
IVF
*
VO
D
+
5V
*
1.7V
*
0.4V
10mA
+
290
W
USE R = 270Ω
^
Figure 4. Wired AND
Figure 5. LED Driver With Blanking
http://onsemi.com
4
MC74HC03A
PACKAGE DIMENSIONS
PDIP–14
N SUFFIX
CASE 646–06
ISSUE L
14
8
B
1
7
NOTES:
1. LEADS WITHIN 0.13 (0.005) RADIUS OF TRUE
POSITION AT SEATING PLANE AT MAXIMUM
MATERIAL CONDITION.
2. DIMENSION L TO CENTER OF LEADS WHEN
FORMED PARALLEL.
3. DIMENSION B DOES NOT INCLUDE MOLD
FLASH.
4. ROUNDED CORNERS OPTIONAL.
DIM
A
B
C
D
F
G
H
J
K
L
M
N
INCHES
MIN
MAX
0.715
0.770
0.240
0.260
0.145
0.185
0.015
0.021
0.040
0.070
0.100 BSC
0.052
0.095
0.008
0.015
0.115
0.135
0.300 BSC
0
_
10
_
0.015
0.039
MILLIMETERS
MIN
MAX
18.16
19.56
6.10
6.60
3.69
4.69
0.38
0.53
1.02
1.78
2.54 BSC
1.32
2.41
0.20
0.38
2.92
3.43
7.62 BSC
0
_
10
_
0.39
1.01
A
F
C
N
H
G
D
SEATING
PLANE
L
J
K
M
SOIC–14
D SUFFIX
CASE 751A–03
ISSUE F
–A–
14
8
NOTES:
1. DIMENSIONING AND TOLERANCING PER ANSI
Y14.5M, 1982.
2. CONTROLLING DIMENSION: MILLIMETER.
3. DIMENSIONS A AND B DO NOT INCLUDE
MOLD PROTRUSION.
4. MAXIMUM MOLD PROTRUSION 0.15 (0.006)
PER SIDE.
5. DIMENSION D DOES NOT INCLUDE DAMBAR
PROTRUSION. ALLOWABLE DAMBAR
PROTRUSION SHALL BE 0.127 (0.005) TOTAL
IN EXCESS OF THE D DIMENSION AT
MAXIMUM MATERIAL CONDITION.
–B–
1
7
P
7 PL
0.25 (0.010)
M
B
M
G
C
R
X 45
_
F
–T–
SEATING
PLANE
D
14 PL
0.25 (0.010)
K
M
M
S
J
T B
A
S
DIM
A
B
C
D
F
G
J
K
M
P
R
MILLIMETERS
MIN
MAX
8.55
8.75
3.80
4.00
1.35
1.75
0.35
0.49
0.40
1.25
1.27 BSC
0.19
0.25
0.10
0.25
0
_
7
_
5.80
6.20
0.25
0.50
INCHES
MIN
MAX
0.337
0.344
0.150
0.157
0.054
0.068
0.014
0.019
0.016
0.049
0.050 BSC
0.008
0.009
0.004
0.009
0
_
7
_
0.228
0.244
0.010
0.019
http://onsemi.com
5
京公网安备 11010802033920号
EEWORLD
