PIC18F1230/1330
PIC18F1230/1330 Rev. A4 Silicon Errata
The PIC18F1230/1330 Rev. A4 parts you have
received conform functionally to the Device Data Sheet
(DS39758C), except for the anomalies described
below. Any Data Sheet Clarification issues related to
the PIC18F1230/1330 will be reported in a separate
Data Sheet errata. Please check the Microchip web site
for any existing issues.
The following silicon errata apply only to
PIC18F1230/1330 devices with these Device/
Revision IDs:
Part Number
PIC18F1230
PIC18F1330
Device ID
0001 1110 000
0001 1110 001
Revision ID
0 0101
0 0101
2. Module: Enhanced Universal
Synchronous Asynchronous
Receiver Transmitter (EUSART)
In Synchronous Slave Transmission mode, the
TRMT bit (TXSTA<1>) may not indicate when the
TSR register is empty.
Work around
Instead of polling the TRMT bit to determine the
status of the EUSART, poll the TXIF flag
(PIR1<4>) to determine when new data can be
written to the TXREG register.
Date Codes that pertain to this issue:
All engineering and production devices.
The Device IDs (DEVID1 and DEVID2) are located at
addresses 3FFFFEh:3FFFFFh in the device’s
configuration space. They are shown in binary in the
format “DEVID2 DEVID1”.
All of the issues listed here will be addressed in future
revisions of the PIC18F1230/1330 silicon.
3. Module: Enhanced Universal
Synchronous Asynchronous
Receiver Transmitter (EUSART)
In rare situations, one or more extra bytes have
been observed in a packet transmitted by the
module operating in Asynchronous mode. The
actual data is not lost or corrupted – only extra
bytes are added. The extra bytes may be 0x00 or
0xFF.
This situation occurs when the contents of the
transmit buffer (TXREG) are transferred to the
TSR at the end of the Stop bit period at the same
time that firmware writes to TXREG.
Note that TXIF is set at the beginning of the Stop
bit period.
Work around
None.
Date Codes that pertain to this issue:
All engineering and production devices.
1. Module: Comparator
The CMPxIF flag, which indicates when each
comparator has a switched state, cannot be
cleared immediately after reading CMCON. The
mismatch condition that sets CMPxIF persists for
1 T
CY
after reading/writing CMCON.
Work around
Insert a
NOP
instruction between reading/writing
CMCON and clearing the CMPxIF flag.
Date Codes that pertain to this issue:
All engineering and production devices.
©
2008 Microchip Technology Inc.
DS80308D-page 1
PIC18F1230/1330
4. Module: Comparator Voltage Reference
The comparator voltage reference module
(CV
REF
) does not offer the option of bypassing the
CV
REF
module.
The CV
REF
module offers the option of providing
the following inputs to the comparators:
• Scaled V
DD
• Scaled V
REF
• No reference (disabled)
Table 1 shows how the CVREN and CVRSS bits
are configured to enable the options.
5. Module: Enhanced Universal
Synchronous Asynchronous
Receiver Transmitter (EUSART)
In rare situations when interrupts are enabled,
unexpected results may occur if:
• The EUSART is disabled (the SPEN bit,
RCSTA <7> =
0)
• The EUSART is re-enabled (RCSTA <7> =
1)
• A two-cycle instruction is executed
Work around
Add a 2 T
CY
delay after re-enabling the EUSART.
1.
2.
3.
4.
5.
Disable Receive Interrupts (RCIE bit,
PIE1<5> =
0).
Disable the EUSART (RCSTA <7> =
0).
Re-enable the EUSART (RCSTA <7> =
1).
Re-enable receive interrupts (PIE1<5> =
1).
(This is the first T
CY
delay.)
Execute a
NOP
instruction.
(This is the second T
CY
delay.)
Date Codes that pertain to this issue:
All engineering and production devices.
TABLE 1:
VOLTAGE REFERENCE
OUTPUT
Comparator
Reference
CVREN
CVRSS
CVRCON<7> CVRCON<4>
0
1
1
x
(don’t care) Disabled
0
1
CV
REF
uses AV
DD
CV
REF
uses V
REF
DS80308D-page 2
©
2008 Microchip Technology Inc.
Note the following details of the code protection feature on Microchip devices:
•
•
Microchip products meet the specification contained in their particular Microchip Data Sheet.
Microchip believes that its family of products is one of the most secure families of its kind on the market today, when used in the
intended manner and under normal conditions.
There are dishonest and possibly illegal methods used to breach the code protection feature. All of these methods, to our
knowledge, require using the Microchip products in a manner outside the operating specifications contained in Microchip’s Data
Sheets. Most likely, the person doing so is engaged in theft of intellectual property.
Microchip is willing to work with the customer who is concerned about the integrity of their code.
Neither Microchip nor any other semiconductor manufacturer can guarantee the security of their code. Code protection does not
mean that we are guaranteeing the product as “unbreakable.”
•
•
•
Code protection is constantly evolving. We at Microchip are committed to continuously improving the code protection features of our
products. Attempts to break Microchip’s code protection feature may be a violation of the Digital Millennium Copyright Act. If such acts
allow unauthorized access to your software or other copyrighted work, you may have a right to sue for relief under that Act.
Information contained in this publication regarding device
applications and the like is provided only for your convenience
and may be superseded by updates. It is your responsibility to
ensure that your application meets with your specifications.
MICROCHIP MAKES NO REPRESENTATIONS OR
WARRANTIES OF ANY KIND WHETHER EXPRESS OR
IMPLIED, WRITTEN OR ORAL, STATUTORY OR
OTHERWISE, RELATED TO THE INFORMATION,
INCLUDING BUT NOT LIMITED TO ITS CONDITION,
QUALITY, PERFORMANCE, MERCHANTABILITY OR
FITNESS FOR PURPOSE. Microchip disclaims all liability
arising from this information and its use. Use of Microchip
devices in life support and/or safety applications is entirely at
the buyer’s risk, and the buyer agrees to defend, indemnify and
hold harmless Microchip from any and all damages, claims,
suits, or expenses resulting from such use. No licenses are
conveyed, implicitly or otherwise, under any Microchip
intellectual property rights.
Trademarks
The Microchip name and logo, the Microchip logo, Accuron,
dsPIC, K
EE
L
OQ
, K
EE
L
OQ
logo, MPLAB, PIC, PICmicro,
PICSTART, rfPIC, SmartShunt and UNI/O are registered
trademarks of Microchip Technology Incorporated in the
U.S.A. and other countries.
FilterLab, Linear Active Thermistor, MXDEV, MXLAB,
SEEVAL, SmartSensor and The Embedded Control Solutions
Company are registered trademarks of Microchip Technology
Incorporated in the U.S.A.
Analog-for-the-Digital Age, Application Maestro, CodeGuard,
dsPICDEM, dsPICDEM.net, dsPICworks, dsSPEAK, ECAN,
ECONOMONITOR, FanSense, In-Circuit Serial
Programming, ICSP, ICEPIC, Mindi, MiWi, MPASM, MPLAB
Certified logo, MPLIB, MPLINK, mTouch, PICkit, PICDEM,
PICDEM.net, PICtail, PIC
32
logo, PowerCal, PowerInfo,
PowerMate, PowerTool, REAL ICE, rfLAB, Select Mode, Total
Endurance, WiperLock and ZENA are trademarks of
Microchip Technology Incorporated in the U.S.A. and other
countries.
SQTP is a service mark of Microchip Technology Incorporated
in the U.S.A.
All other trademarks mentioned herein are property of their
respective companies.
© 2008, Microchip Technology Incorporated, Printed in the
U.S.A., All Rights Reserved.
Printed on recycled paper.
Microchip received ISO/TS-16949:2002 certification for its worldwide
