Datasheet> All Categories > The power supply circuit> MGDSI-25-O-B/M

MGDSI-25-O-B/M: DescriptionDC-DC Regulated Power Supply Module, 1 Output, 25W, Hybrid, ROHS COMPLIANT, METAL PACKAGE-8; CategoryThe power supply circuit; File Size537KB，12 Pages; ManufacturerGAIA Converter Inc; Websitehttps://gaia-converter.com; Environmental Compliance

Download Datasheet Parametric View All

MGDSI-25-O-B/M Overview

DC-DC Regulated Power Supply Module, 1 Output, 25W, Hybrid, ROHS COMPLIANT, METAL PACKAGE-8

MGDSI-25-O-B/M Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	GAIA Converter Inc
Parts packaging code	MODULE
package instruction	ROHS COMPLIANT, METAL PACKAGE-8
Contacts	8
Reach Compliance Code	compliant
ECCN code	EAR99
Is Samacsys	N
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage	75 V
Minimum input voltage	18 V
Nominal input voltage	48 V
JESD-30 code	S-MDMA-P8
length	50.8 mm
Maximum load regulation	2.5%
Number of functions	1
Output times	1
Number of terminals	8
Maximum operating temperature	71 °C
Minimum operating temperature	-40 °C
Maximum output current	6 A
Maximum output voltage	3.366 V
Minimum output voltage	3.234 V
Nominal output voltage	3.3 V
Package body material	METAL
Encapsulate equivalent code	MODULE,8LEAD,1.8
Package shape	SQUARE
Package form	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum seat height	12.9 mm
surface mount	NO
technology	HYBRID
Temperature level	OTHER
Terminal form	PIN/PEG
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum total power output	25 W
Fine-tuning/adjustable output	NO
width	50.8 mm
Base Number Matches	1

Preview

Download Datasheet

View All

Industrial DC/DC CONVERTER

MGDI-25 Wide Input : 25W POWER

Industrial

Grade

4:1 Wide Input

Single, Bi & Triple Outputs

Metallic Case - 1 500 VDC Isolation

• Wide input range

• Nominal power up to 25 W

• Wide temperature range : -40°C/+ 95°C case

• High efficiency (typ. 84%)

• Soft start

• Galvanic isolation 1.500 VDC according to EN 60950

• Integrated LC EMI filter

• Permanent short circuit protection

• No optocoupler for high reliability

• RoHS process

1-General

The MGDI-25 wide input series is a complete

line of DC/DC power modules designed for use

in distributed power architecture and are

particularly suitable for mobile or ground fixed

applications in transportation, industrial and

telecommunication areas. These modules use a

high frequency fixed swiching technic at 250KHz

providing excellent reliability, low noise

characteristics and high power density. Standard

models are available with wide input voltage

range of 9-36 and 18-75 volts. The series include

single bi and triple output voltage choices of

3,3, 5, 12, 15 volts.

No external heatsink is required for the MGDI-

25 series to supply 25W output power over the

full temperature range.

The MGDI-25 series is designed in conformity

with safety standards EN60950 and UL1950.

All the modules are designed with LC network

filters to minimize reflected input current ripple

and output voltage ripple according to EN55022

and FCC Part 15J standard.

The modules include a soft-start, a permanent

short circuit protection and an output overvoltage

protection to ensure efficient module protec-

tion. The soft-start allows current limitation and

eliminates inrush current during start-up. The

short circuit protection completely protects the

modules against short-circuits of any duration

by a shut-down and restores to normal when

the overload is removed.

The design has been carried out with surface

mount components and is manufactured in a

fully automated process to guarantee high

quality. Each module is tested with a GAIA

converter automated test equipment.

2-Product Selection

Single output model

Bi output model

Triple output model

: MGDSI - 25 -

: MGDBI - 25 -

: MGDTI - 25 -

input

output

option

Input Voltage Range

Permanent

H :

9-36 VDC

: 18-75 VDC

Transient

40 VDC/100 ms

80 VDC/100 ms

Output

B : 3.3 VDC

C : 5 VDC or +/-5VDC

E : 12 VDC or +/-12VDC

F : 15 VDC or +/-15VDC

BE : 3,3 VDC and +/-12 VDC

BF : 3,3 VDC and +/-15 VDC

CE : 5 VDC and +/-11,5 VDC

CF : 5 VDC and +/-14,6 VDC

Options :

/M : option for On/Off function

REDEFINING THE SOURCE OF POWER

Gaia Converter FC97-023.01/11 Revision L

For locations, phone, fax, E-Mail see back cover
