BFG520TRL datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The transistor> BFG520TRL

BFG520TRL: DescriptionL BAND, Si, NPN, RF SMALL SIGNAL TRANSISTOR; CategoryThe transistor; File Size50KB，1 Pages; ManufacturerNXP; Websitehttps://www.nxp.com; Environmental Compliance

Download Datasheet Parametric Compare View All

BFG520TRL Overview

L BAND, Si, NPN, RF SMALL SIGNAL TRANSISTOR

BFG520TRL Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	NXP
package instruction	SMALL OUTLINE, R-PDSO-G4
Reach Compliance Code	unknown
ECCN code	EAR99
Is Samacsys	N
Maximum collector current (IC)	0.07 A
Collector-emitter maximum voltage	15 V
Configuration	SINGLE
highest frequency band	L BAND
JESD-30 code	R-PDSO-G4
JESD-609 code	e3
Number of components	1
Number of terminals	4
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
Polarity/channel type	NPN
Minimum power gain (Gp)	13 dB
Certification status	Not Qualified
surface mount	YES
Terminal surface	TIN
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	40
transistor applications	AMPLIFIER
Transistor component materials	SILICON
Nominal transition frequency (fT)	9000 MHz
Base Number Matches	1

Preview

Download Datasheet

View All

BFG520TRL Related Products

	BFG520TRL	BFG505TRL	BFG540TRL13	BFG540TRL	BFG520TRL13	BFG590TRL13	BFG590TRL	BFG505TRL13
Description	L BAND, Si, NPN, RF SMALL SIGNAL TRANSISTOR	L BAND, Si, NPN, RF SMALL SIGNAL TRANSISTOR	L BAND, Si, NPN, RF SMALL SIGNAL TRANSISTOR	L BAND, Si, NPN, RF SMALL SIGNAL TRANSISTOR	L BAND, Si, NPN, RF SMALL SIGNAL TRANSISTOR	TRANSISTOR Si, NPN, RF SMALL SIGNAL TRANSISTOR, BIP RF Small Signal	TRANSISTOR Si, NPN, RF SMALL SIGNAL TRANSISTOR, BIP RF Small Signal	L BAND, Si, NPN, RF SMALL SIGNAL TRANSISTOR
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to	conform to	conform to
package instruction	SMALL OUTLINE, R-PDSO-G4	SMALL OUTLINE, R-PDSO-G4	SMALL OUTLINE, R-PDSO-G4	SMALL OUTLINE, R-PDSO-G4	SMALL OUTLINE, R-PDSO-G4	SMALL OUTLINE, R-PDSO-G4	SMALL OUTLINE, R-PDSO-G4	SMALL OUTLINE, R-PDSO-G4
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknow
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Maximum collector current (IC)	0.07 A	0.018 A	0.12 A	0.12 A	0.07 A	0.2 A	0.2 A	0.018 A
Collector-emitter maximum voltage	15 V	15 V	15 V	15 V	15 V	15 V	15 V	15 V
Configuration	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE
JESD-30 code	R-PDSO-G4	R-PDSO-G4	R-PDSO-G4	R-PDSO-G4	R-PDSO-G4	R-PDSO-G4	R-PDSO-G4	R-PDSO-G4
JESD-609 code	e3	e3	e3	e3	e3	e3	e3	e3
Number of components	1	1	1	1	1	1	1	1
Number of terminals	4	4	4	4	4	4	4	4
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260	260	260	260	260	260	260	260
Polarity/channel type	NPN	NPN	NPN	NPN	NPN	NPN	NPN	NPN
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
surface mount	YES	YES	YES	YES	YES	YES	YES	YES
Terminal surface	TIN	TIN	TIN	TIN	TIN	TIN	TIN	TIN
Terminal form	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL
Maximum time at peak reflow temperature	40	40	40	40	40	40	40	40
transistor applications	AMPLIFIER	AMPLIFIER	AMPLIFIER	AMPLIFIER	AMPLIFIER	AMPLIFIER	AMPLIFIER	AMPLIFIER
Transistor component materials	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON
Nominal transition frequency (fT)	9000 MHz	9000 MHz	9000 MHz	9000 MHz	9000 MHz	8000 MHz	8000 MHz	9000 MHz
Is it lead-free?	Lead free	Lead free	Lead free	Lead free	Lead free	-	-	Lead free
Maker	NXP	-	-	-	NXP	NXP	NXP	NXP
highest frequency band	L BAND	L BAND	L BAND	L BAND	L BAND	-	-	L BAND
Minimum power gain (Gp)	13 dB	13 dB	11 dB	11 dB	13 dB	-	-	13 dB
Base Number Matches	1	1	1	1	1	-	-	-
