NJW1138M-(TE2): DescriptionTone Control Circuit, PDSO30, SDMP-30; CategoryConsumption circuit; File Size117KB，14 Pages; ManufacturerNew Japan Radio Co., Ltd..

Download Datasheet Parametric Compare View All

NJW1138M-(TE2) Overview

Tone Control Circuit, PDSO30, SDMP-30

NJW1138M-(TE2) Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	New Japan Radio Co., Ltd..
Parts packaging code	SOIC
package instruction	SSOP,
Contacts	30
Reach Compliance Code	compliant
Is Samacsys	N
Commercial integrated circuit types	TONE CONTROL CIRCUIT
JESD-30 code	R-PDSO-G30
JESD-609 code	e6
length	15.4 mm
Humidity sensitivity level	2
Number of terminals	30
Package body material	PLASTIC/EPOXY
encapsulated code	SSOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, SHRINK PITCH
Certification status	Not Qualified
Maximum seat height	2.7 mm
surface mount	YES
Terminal surface	TIN BISMUTH
Terminal form	GULL WING
Terminal pitch	1 mm
Terminal location	DUAL
width	7.5 mm
Base Number Matches	1

Preview

Download Datasheet

View All

NJW1138

P R E L I M I N A LY

AUDIO PROCESSOR

GENERAL DESCRIPTION

The

NJW1138

is an audio processor. It includes all of

functions processing audio signal for TV, such as tone

control, balance, volume, mute, NJRC original surround, and

AGC functions.

The NJRC original surround system reproduces natural

surround sound and clear vocal orientation.

All of internal status and variables are controlled by I C

BUS interface.

PACKAGE OUTLINE

NJW1138L

NJW1138M

FEATURES

8 to 13V

Operating Voltage

I C BUS Interface

AGC Circuit (It reduces volume difference among input sources.)

NJRC Original Surround

Simulated Surround

Bi-CMOS Technology

SDIP30, SDMP30

Package Outline

BLOCK DIAGRAM

VOL1

NJRC

Original

Surround

Sim ulated

Surround

TONE

VOL2

I2C Bus

Interface

AGC

VOL1

TONE

VOL2

Bias

-1–
