1N914UR Overview

0.125 A, SILICON, SIGNAL DIODE, DO-213AA

Preview

Download Datasheet

View All

• 1N914UR AVAILABLE IN

JAN, JANTX,

AND

JANTXV

PER MIL-PRF-19500/116

• SWITCHING DIODE

• HERMETICALLY SEALED

• DOUBLE PLUG CONSTRUCTION

• METALLURGICALLY BONDED

1N914UR

and

CDLL914

MAXIMUM RATINGS

Operating Temperature: -65°C to +175°C

Storage Temperature: -65°C to +200°C

Operating Current: 75 mA @ TA = + 25°C

Derating Factor: 0.5 mA/°C Above TA = + 25°C

Surge Current A: 1A, sine wave, Pw = 8.3ms

Surge Current B: 0.704A, square wave, Pw = 8.3ms

ELECTRICAL CHARACTERISTICS

@ 25°C, unless otherwise specified

Vf 1

VBR

V RWM

@I F = 10mA

Vf 2

@I F = 50mA

t rr

(Note 1)

DIM

MILLIMETERS

INCHES

MIN MAX MIN MAX

1.60

1.70 0.063 0.067

0.41

0.55 0.016 0.022

3.30

3.70 .130 .146

2.54 REF.

.100 REF.

0.03 MIN.

.001 MIN.

Volts (min)

100

Volts (pk)

V dc

0.8

V dc

1.2

n sec

FIGURE 1

DESIGN DATA

I R1

@ 20 V dc

I R2

@ 75 V dc

I R3

@ 20 V

TA = 150°C

µA

0.5

µA

I R4

@ 75 V

TA = 150°C

µA

4.0

2.8

CAPACITANCE

@0V

CAPACITANCE

@ 1.5 V

CASE:

DO-213AA, Hermetically sealed

glass case. (MELF, SOD-80; LL34)

LEAD FINISH:

Tin / Lead

THERMAL RESISTANCE (ROJEC):

100 °C/W maximum AT L = 0

THERMAL IMPEDANCE: (ZO

JX): 70

˚C/W maximum

POLARITY:

Cathode end is banded.

MOUNTING SURFACE SELECTION:

The Axial Coefficient of Expansion

(COE) Of this Device is Approximately

+6PPM/°C. The COE of the Mounting

Surface System Should Be Selected To

Provide A Suitable Match With This

Device.

NOTE 1

IF = IR = 10 mA, RL = 100 ohms.

22 COREY STREET, MELROSE, MASSACHUSETTS 02176

PHONE (781) 665-1071

FAX (781) 665-7379

WEBSITE: http://www.cdi-diodes.com

E-mail: mail@cdi-diodes.com
