LGK General Purpose, 85℃
Features
●
Wide CV value range.
●
Load life 1000~2000hrs 85℃.
●
Safety vent construction design.
Specifications
Item
Operating Temperature Range
Rated voltage Range
Capacitance Range
Capacitance Tolerance
Leakage Current
(+20℃, max.)
I≦0.01 CV or 3(uA) After 1minute
whichever is greater measured
with rated working voltage applied.
Working Voltage (VDC)
D.F.(%)max
6.3
23
200
18
250
18
350
20
10
20
400
20
16
16
25
14
450
20
-40 to +85℃
6.3 to 100 VDC
0.1 to 15000 uF
±20%(120Hz,
+20℃)
I≦0.03 CV or 3(uA) After 1minute
with rated working voltage applied..
Performance Characteristics
-25 to 85℃
160 to 450 VDC
0.47 to 470 uF
35
12
50
10
63
10
100
10
Dissipation Factor (tan
δ
)
Working Voltage (VDC)
D.F.(%)max
160
16
For Capacitance > 1000uF , add 2% per another 1000uF (+20℃, at 120Hz)
Impedance ratio max.
Working Voltage (VDC)
Z-25℃/Z+20℃
6.3
4
8
250
3
350
5
10
3
6
400
15
16
2
4
25
2
4
450
15
35
2
3
50
2
3
63
2
3
100
2
3
Low Temperature Characteristics
(120Hz)
Z-40℃/Z+20℃
Working Voltage (VDC)
Z-25℃/Z+20℃
160
3
200
3
For Capacitance Value 1000uF , add 0.5 per another 1000uF for -25℃/+20℃
add 1 per another 1000uF for -40℃/+20℃
Test conditions
Duration time : 5Ø~6Ø 1000Hrs
D≧8Ø 2000Hrs
Ambient temperature:+85℃
Applied voltage: Rated DC working voltage
After test requirements at+20℃
After test requirements:≦±20% of the initial measured value
Dissipation Factor:
≦200%
of the initial specified value
Leakage current:
≦The
initial specified value
Test conditions
Duration time :500Hrs
Ambient temperature:+85℃
Applied voltage: None
After test requirements at +20℃: Some limits as Load life.
Pre-treatment for measurements shall be conducted after
application of DC working voltage for 30 minutes.
Load Life
Shelf Life
Multiplier for Ripple Current V.S Frequency
CAP(uF) \ HZ
CAP≦10
Multiplier for Ripple Current VS Temperature
1K
1.45
1.36
1.25
1.18
10K
1.65
1.48
1.35
1.25
100KUP
1.70
1.53
1.38
1.28
Temperature (℃)
Multiplier
45
1.8
60
1.50
70
1.30
85
1.00
50(60)
0.8
0.8
0.8
0.8
120
1
1
1
1
400
1.30
1.23
1.16
1.11
Multiplier
10<CAP≦100
100<CAP≦1000
1000<CAP
Diagram of Dimensions: (Unit: mm)
Dφ
F
dφ
5
2.0
6.3
2.5
0.5
8
3.5
10
5.0
13
5.0
0.6
16
7.5
18
7.5
0.8
22
10
25
12
1.0
PCB Design
