SMT POWER INDUCTORS
Shielded Drum Core - PF0464/PF0465 Series
Height:
PF0464: 3mm Max - PF0465: 4mm Max
Small Size:
7.2mm x 7.2mm Max
Current Rating:
PF0464: up to 4.5A - PF0465: up to 3.5A
Inductance Range:
1.5µH to 100µH
Electrical Specifications @ 25°C — Operating Temperature -40°C to +125°C
1, 6
Part
5
Number
PF0464 S
ERIES
PF0464.152
PF0464.302
PF0464.392
PF0464.502
PF0464.602
PF0464.732
PF0464.862
PF0464.103
PF0464.123
PF0464.153
PF0464.183
PF0464.223
PF0464.273
PF0464.333
PF0464.393
PF0464.473
PF0464.563
PF0464.683
PF0464.823
PF0464.104
PF0465 S
ERIES
PF0465.332
PF0465.502
PF0465.622
PF0465.732
PF0465.862
PF0465.103
PF0465.123
PF0465.153
PF0465.183
PF0465.223
PF0465.273
PF0465.333
PF0465.393
PF0465.473
PF0465.563
PF0465.683
PF0465.823
PF0465.104
Inductance
1
@Irated
(
μ
H TYP)
1.2
2.4
3.1
4.0
4.8
5.8
6.9
8.0
9.6
12.0
14.4
17.6
21.6
26.4
31.2
37.6
44.8
54.4
65.6
80.0
2.6
4.0
5.0
5.8
6.9
8.0
9.6
12.0
14.4
17.6
21.6
26.4
31.2
37.6
44.8
54.4
65.6
80.0
Irated
2
(A)
4.50
3.00
2.60
2.40
2.25
2.10
1.85
1.70
1.55
1.40
1.32
1.20
1.05
0.97
0.86
0.80
0.73
0.65
0.60
0.54
3.50
2.90
2.50
2.30
2.20
2.00
1.70
1.60
1.50
1.30
1.20
1.10
1.00
0.95
0.85
0.75
0.70
0.65
DCR
(m
Ω
)
TYP
9
17
19
24
26
36
38
41
52
55
69
85
104
132
142
197
216
235
291
401
16
19
21
25
27
29
39
44
62
68
75
94
101
112
154
188
261
286
MAX
12
22
25
30
33
45
48
52
66
75
90
113
132
165
180
238
270
300
370
505
20
24
26
31
34
37
50
55
78
86
95
118
128
140
195
234
324
350
Inductance
@0A
DC
(
μ
H ±20%)
1.5
3.0
3.9
5.0
6.0
7.3
8.6
10
12
15
18
22
27
33
39
47
56
68
82
100
3.3
5.0
6.2
7.3
8.6
10
12
15
18
22
27
33
39
47
56
68
82
100
Saturation
3
Current
I
SAT
(A)
4.50
3.00
2.60
2.40
2.25
2.10
1.85
1.70
1.55
1.40
1.32
1.20
1.05
0.97
0.86
0.80
0.73
0.65
0.60
0.54
3.50
2.90
2.50
2.30
2.20
2.00
1.70
1.60
1.50
1.30
1.20
1.10
1.00
0.95
0.85
0.75
0.70
0.65
Heating
4
Current I
DC
(A)
5.50
4.25
3.80
3.55
3.20
3.10
2.95
2.90
2.40
2.35
2.10
1.85
1.70
1.50
1.45
1.25
1.15
1.10
1.00
0.85
4.65
4.10
3.90
3.50
3.30
3.20
2.80
2.60
2.25
2.10
2.00
1.75
1.70
1.60
1.35
1.25
1.05
1.00
* NOTE:
To order RoHS compliant part, add the suffix “NL” to the part number (i.e. PF0464.152 becomes PF0464.152NL and PF0464.152T becomes PF0464.152NLT).
Mechanical
.284
7,20
MAX
MAX
Schematic
.104
2,65
REF
A
Date Code
XXX
.284
7,20
MAX
.287
7,30
REF
.079 REF
2,00
SUGGESTED PAD LAYOUT
PF0464
PF0465
Weight............................0.5
grams .........0.7 grams
Tape & Reel
....................1200/reel ............900/reel
“A” (height - in./mm)
....0.118/3,00 ........0.158/4,00
Dimensions:
Inches
mm
Unless otherwise specified, all tolerances are ± .004
0,10
1
2
USA 858 674 8100
•
UK 44 1483 401 700
•
France 33 3 84 35 04 04
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 769 5538070
•
Taiwan 886 3 4641811
www.pulseeng.com
35
SPM2006 (3/06)
SMT POWER INDUCTORS
Shielded Drum Core - PF0464/PF0465 Series
.472
12,00
Tape and Reel Layout
PF0464
PF0465
“B” (height - in./mm)
....0.150/3,80 ........0.205/5,20
.301
7,65
.630
± .012
16,00
± 0,30
B
.293
7,45
USER DIRECTION OF FEED
Notes from Tables
1. Inductance at Irated is a typical inductance value measured when 4. The heating current I
DC
is the DC current which causes the
the inductor is subjected to the rated current.
temperature rise of the part to increase by approximately 40°C.
This current is determined by mounting the component on a
2. The rated current as listed is either the saturation current @ 25°C
typical application PCB and applying the current to the device
or the heating current depending on which value is lower.
for 30 minutes.
3. The saturation current Isat is the current which causes the
inductance to drop by 20% (typical) at an ambient temperature of 5. Optional Tape & Reel packaging can be ordered by adding a "T"
suffix to the part number (i.e. PF0464.152 becomes PF0464.152T).
25°C. This current is determined by placing the component in the
Pulse complies to industry standard tape and reel specification EIA481.
specified ambient environment and applying a short duration pulse
current (to eliminate self-heating effects) to the component.
6. The temperature of the component (ambient plus temperature rise)
must be within the stated operating temperature range.
Inductance vs Current Characteristics
