OET SERIES - TRIPLE OUTPUT, 25 WATT
DESCRIPTION
OET triple output DC/DC converters provide 25 watts
of output power in an industry-standard package. The
OET series features excellent efficiency and industry-
leading power density. The OET features open-frame
packaging to provide maximum useable power with
minimal thermal constraints. These units are fully
compatible with production board washing processes.
TECHNICAL SPECIFICATIONS
Input
Voltage Range
24 VDC Nominal
48 VDC Nominal
Turn On Voltage 24V/48V Models
Turn On Hysteresis
Reflected Ripple Input Current
Input Reverse Voltage Protection
Output
Setpoint Accuracy
Line Regulation V
in
Min. - V
in
Max., I
out
Rated
Load Regulation I
out
Min. - I
out
Max., V
in
Nom.
Secondary Output Regulation, All Line/Load Conditions
Minimum Output Current
Dynamic Regulation, Loadstep
Pk Deviation
Settling Time
Short Circuit And Overcurrent Protection
Power LimitThreshold Range
Short Circuit
OVP Trip Range
OVP Type
±1%
0.2% V
out
0.5% V
out
10% V
out
25% I
out
4% V
out
500
µs
Shutdown and Self-Recovering
110 - 130%
200% I
out
Nom.
115 - 140% V
out
Nom.
Self-Recovering
General
Notes
† MTBF predictions may vary slightly from model to model.
Specifications typically at 25°C, normal line, and full load, unless otherwise
stated.
Soldering Conditions: I/O pins, 260°C, ten seconds; fully compatible with
commercial wave-soldering equipment.
Safety: Agency approvals may vary from model to model. Please consult
factory for specific model information.
Units are water-washable and fully compatible with commercial spray or
immersion post wave-solder washing equipment.
EFFICIENCY %
FEATURES
• Triple Output 2” x 2”
• Open-Frame
Construction
• 1.5 Million Hours MTBF
• Short Circuit and
Overvoltage Protection
• Input Undervoltage
Lockout
• 24V or 48V Input
Versions
• 1500V Isolation
• 100°C Baseplate
Operation
18 - 36 VDC
34 - 75 VDC
<17V / <34V
1V Nominal
50 mA pk-pk
Shunt Diode
Efficiency vs. Load (48V Input)
90
85
80
75
EFF. OETZGHH-A
70
EFF. OETZGJJ-A
65
60
10
20
30
40
50
60
70
80
90
10
LOAD %
10 % I
out
rated
Switching Frequency
Turn-On Time
Remote Shutdown
Isolation
Input - Output
Input - Case
Output - Case
Temperature Coefficient
Case Temperature
Operating Range
Storage Range
Thermal Shutdown Range
Humidity Max., Non-Condensing
Vibration, 3 Axes, 5 Min Each
MTBF
†
(Bellcore TR-NWT-000332)
Safety
Weight (approx.)
500 kHz
10ms
Positive Logic
1500 VDC
1050 VDC
1050 VDC
0.03%/°C
-40 to +100°C
-40 to +125°C
105 to 115°C
95%
5 g, 10 - 55 Hz
1.5 x 106 hrs
UL, cUL, TUV
1.3 oz
Rev. SEP 17, 2002
1
OPTIONS
When ordering equipment options, use the following suffix information. Select the option(s) that you prefer
and add them to the model number. Example ordering options are located below the options table.
OPTION
Negative Logic
Lucent-Compatible Trim
Terminal Strip
Trim
Enable
Trim and Enable
SUFFIX
N
T
TS
1
2
3
APPLICABLE SERIES
HAS, HBD, HBS, HES, HLS, HLD, LES,
QBS, QES, QLS, TES, TQD
HAS, HBD, HBS, HES, HLS, QBS, QES,
QLS
XWS, XWD, XWT
IAS, LES
IAD, IAS, LES, SMS
IAS, LES
REMARKS
TTL "Low" Turns Module ON
TTL "High" Turns Module OFF
Pin Length and Heatsink Options
0.110" (2.8mm) Pin Length
0.150" (3.8mm) Pin Length
0.24" (6.1mm) Horizontal Heatsink
0.24" (6.1mm) Vertical Heatsink
0.45" (11.4mm) Horizontal Heatsink
0.45" (11.4mm) Vertical Heatsink
0.95" (24.1mm) Horizontal Heatsink
0.95" (24.1mm) Vertical Heatsink
8
9
1H
1V
2H
2V
3H
3V
All Leaded Models
All Leaded Models
All 1/4-Bricks, 1/2-Bricks, 3/4-Bricks, Full-Bricks
(Except HLS, HLD, QLS, TLD, and TKD Packages)
All 1/4-Bricks, 1/2-Bricks, 3/4-Bricks, Full-Bricks
(Except HLS, HLD, QLS, TLD, and TKD Packages)
All 1/4-Bricks, 1/2-Bricks, 3/4-Bricks, Full-Bricks
(Except HLS, HLD, QLS, TLD, and TKD Packages)
All 1/4-Bricks, 1/2-Bricks, 3/4-Bricks, Full-Bricks
(Except HLS, HLD, QLS, TLD, and TKD Packages)
All 1/4-Bricks, 1/2-Bricks, 3/4-Bricks, Full-Bricks
(Except HLS, HLD, QLS, TLD, and TKD Packages)
All 1/4-Bricks, 1/2-Bricks, 3/4-Bricks, Full-Bricks
(Except HLS, HLD, QLS, TLD, and TKD Packages)
Standard Pin Length is 0.180" (4.6mm)
Includes Thermal Pad
Includes Thermal Pad
Includes Thermal Pad
Includes Thermal Pad
Includes Thermal Pad
Includes Thermal Pad
Example Options:
HBS050ZG-ANT3V = HBS050ZG-A with negative logic, Lucent-compatible trim, and 0.95” vertical heatsink.
LES015YJ-3N = LES015YJ with optional trim and enable, negative logic.
QBS066ZG-AT8 = QBS066ZG-A with Lucent-compatible trim and 0.110” pin length.
NUCLEAR AND MEDICAL APPLICATIONS - Power-One products are not authorized for use as critical components in life support systems,
equipment used in hazardous environments, or nuclear control systems without the express written consent of the respective divisional President
of Power-One, Inc.
TECHNICAL REVISIONS - The appearance of products, including safety agency certifications pictured on labels, may change depending on the date
manufactured. Specifications are subject to change without notice.
REV. AUG 16, 2002
3
