Power PCB Relay 429 00 / 429 10 / 429 01
1 pole 10 A / 16 A, DC-coil
Features
•
•
•
•
1 C/O, 1 N/O or 1N/C contact
15 mm height
Ambient temperature up to 105°C
4 kV / 8 mm coil-contact
Applications
General purpose power relay, timers, heating controls,
domestic appliances
F0247-A
VZ S
Contact data
Configuration
Type of contact
Rated current
Rated voltage / max.breaking voltage AC
Rated voltage / max.breaking voltage DC
Maximum breaking capacity AC
Make current (max. 4 s at duty cycle 10%)
Contact material
1 C/O, 1 N/O or 1 N/C contact
single contact
10 A
16 A
250 Vac / 400 Vac
250 Vdc
2500 VA
4000 VA
20 A
AgCdO, AgNi
Technical data of approved types on request
H
Contact ratings
Type
1 C/O
42900
1 N/O, N/C 42900
1 N/O
42900
1 C/O
42900
Load
16 A,
16 A,
10 A,
10 A,
250
250
250
400
Vac,
Vac,
Vac,
Vac,
cosϕ=1
cosϕ=1
cosϕ=1
cosϕ=1
Operations
3x10
4
5x10
4
3x10
5
8x10
4
Coil data
Nominal voltage
Nominal coil power
Operate category
DC coil
DC coil
3...60 Vdc
0.48 W (C/O), 0.42 W (N/O, N/C)
1/b
Coil versions C/O contact
Coil
Nominal
Pull-in
Release
Maximum
code
voltage
voltage
voltage
voltage
Vdc
Vdc
Vdc
Vdc
16
6
4.1
0.4
12.0
13
12
8.1
0.9
24.0
10
18
12.2
1.3
36.0
08
24
16.2
1.8
48.0
06
36
24.3
2.7
72.0
05
48
32.4
3.6
96.0
03
60
40.5
4.5
120.0
All figures are given for coil without preenergization, at ambient
Other coil voltages on request
Edition: 11/2003
Coil
Coil
resistance
current
c
mA
80+10%
75.0
300+10%
40.0
690+10%
26.1
1200+10%
20.0
2600+10%
13.8
4825+10%
10.0
7500+10%
8.0
temperature +20°C
Power PCB Relay 429 00 / 429 10 / 429 01
1 pole 10 A / 16 A, DC-coil
Coil versions, 1 N/O or 1 N/C contact
Coil
Nominal
Pull-in
Release
Maximum
code
voltage
voltage
voltage
voltage
Vdc
Vdc
Vdc
Vdc
66
6
4.1
0.4
13
62
12
8.1
0.9
25
60
18
12.2
1.3
39
58
24
16.2
1.8
52
56
36
24.3
2.7
78
55
48
32.4
3.6
104
53
60
40.5
4.5
130
All figures are given for coil without preenergization, at ambient
Other coil voltages on request
Dimensions
Coil
Coil
resistance
current
c
mA
97+10%
61.8
340+10%
35.3
800+10%
22.5
1400+10%
17.1
3050+10%
11.8
5600+10%
8.6
8700+10%
6.9
temperature +20°C
View on solder pins
Dimensions in mm
1 C/O contact
S0421-AC
Insulation
Dielectric strength
coil-contacts
open contact circuit
Clearance / creepage
Insulation to IEC 60664
Voltage rating
Pollution degree
Overvoltage category
Insulation to VDE 0110b (2/79)
Insulation category / reference voltage
Tracking resistance of relay base
4000 V
rms
2000 V
rms
> 8 mm
250 V
3
III
C / 250
PTI 100 M
1 N/O contact
S0421-AA
Other data
Flammability class according to UL 94
Ambient temperature
DC-coil
Mechanical life
DC-coil
Operate- / release time
Bounce time
Shock resistance (destruction)
Category of protection (IEC 61810)
Relay weight
Packaging unit
V-0
-20...+105 °C
5x10
6
operations
typ. 6 / 2 ms
typ. 3 ms
100 g
RT I dust protected
10 g
50 / 400
PCB layout / terminal assignment
1 C/O contact, 16 A
1 N/O contact, 16 A
1 C/O contact, 10 A
1 N/O contact, 10 A
Edition: 11/2003
S0420-AH
S0420-AA
S0420-AX
S0420-AV
S0420-AC
S0420-AF
S0420-AU
S0420-AS
Power PCB Relay 429 00 / 429 10 / 429 01
1 pole 10 A / 16 A, DC-coil
Edition: 11/2003
Rights to change data / design reserved
