5149010-1: DescriptionHEADER CONNECTOR,PCB MNT,PLUG,40 CONTACTS,PIN,0.05 PITCH,PC TAIL TERMINAL,LOCKING,NATURAL; CategoryThe connector The connector; File Size113KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

5149010-1 Overview

HEADER CONNECTOR,PCB MNT,PLUG,40 CONTACTS,PIN,0.05 PITCH,PC TAIL TERMINAL,LOCKING,NATURAL

5149010-1 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknow
body width	0.285 inch
subject depth	0.648 inch
body length	1.214 inch
Body/casing type	PLUG
Connector type	BOARD CONNECTOR
Contact to complete cooperation	AU ON NI
Contact completed and terminated	TIN OVER NICKEL
Contact point gender	MALE
Contact material	PHOSPHOR BRONZE
contact mode	RECTANGULAR
Contact style	SQ PIN-SKT
Dielectric withstand voltage	500VAC V
Durability	50 Cycles
Insulation resistance	5000000000 Ω
Insulator color	NATURAL
insulator material	THERMOPLASTIC
Manufacturer's serial number	5149010
Plug contact pitch	0.05 inch
Match contact row spacing	0.1 inch
Installation option 1	LOCKING
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
PCB row number	5
Number of rows loaded	2
Maximum operating temperature	125 °C
Minimum operating temperature	-65 °C
PCB contact pattern	STAGGERED
PCB contact row spacing	1.27 mm
Plating thickness	30u inch
polarization key	POLARIZED HOUSING
reliability	COMMERCIAL
Terminal length	0.1 inch
Terminal pitch	2.54 mm
Termination type	SOLDER
Total number of contacts	40
Base Number Matches	1

Preview

Download Datasheet

View All

My Account

Tyco Electronics

(C hange)

Se a rch by Ke yword or Pa rt #

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Backplane/Midplane

Product Feature Selector

> Product Details

5149010-1 Product Details

Live Product Chat

.050 Centerline Micro-Strip Connectors

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

5149010-1

T E I nternal N umber: 5 1 4 9 0 1 0 - 1

Product Highlights:

C onnector

C onnector Type = Plug

40 Positions

Vertical Mount Angle

PC B Termination Type = Soldertail

View all Features

Obsolete

C ontact Product Information C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

None Available

Product Specifications:

C onnector, Micro-Strip, Board To Board

(PDF, English)

Application Specifications:

Micro-Strip Board-To-Board Plug and Receptacle C onne...

(PDF, English)

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= C onnector

C onnector Type = Plug

Number of Positions

= 40

Mount Angle

= Vertical

PC B Termination Type = Soldertail

PC B Retention Feature

= Yes

Guides

= Without

Flame Retardant = Yes

C omment = First tail from right of each ground bus is kinked.

Mechanical Attachment:

Bus Bar Material = Phosphor Bronze

Contact Related Features:

Signal C ontact Material = Phosphor Bronze

Signal C ontact Mating Area Plating = Gold (30)

Signal C ontact Termination Area Plating = Matte Tin with Nickel

underplated

Housing Related Features:

Housing Material = High Temperature Thermoplastic

Configuration Related Features:

Stack Height (mm [in])

= 18.75 [0.738]

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Wave solder capable to 240?C , Wave

solder capable to 260?C , Wave solder capable to 265?C

RoHS/ELV C ompliance History = Always was RoHS compliant

Additional Information:

Product Line Information
