Document 100-1
ChipInductors
–
0805CSSeries(2012)
These ultra-compact inductors provide excep-
tional Q values, even at high frequencies. They
have a ceramic body and wire wound construction
to provide the highest SRFs available in 0805 size.
Part number
1
Coilcraft
Designer’s Kit C103
contains samples of
all 5% inductance tolerance parts. Kits with 2%
tolerance are also available. To order, contact Coilcraft
or purchase on-line at
http://order.coilcraft.com.
Q min
4
Inductance
2
(nH)
2.8 @ 250 MHz
3.0 @ 250 MHz
3.3 @ 250 MHz
5.6 @ 250 MHz
6.8 @ 250 MHz
7.5 @ 250 MHz
8.2 @ 250 MHz
10 @ 250 MHz
12 @ 250 MHz
15 @ 250 MHz
18 @ 250 MHz
22 @ 250 MHz
24 @ 250 MHz
27 @ 250 MHz
33 @ 250 MHz
36 @ 250 MHz
39 @ 250 MHz
43 @ 200 MHz
47 @ 200 MHz
56 @ 200 MHz
68 @ 200 MHz
82 @ 150 MHz
91 @ 150 MHz
100 @150 MHz
110 @ 150 MHz
120 @ 150 MHz
150 @ 100 MHz
180 @ 100 MHz
220 @ 100 MHz
240 @ 100 MHz
270 @ 100 MHz
330 @ 100 MHz
390 @ 100 MHz
470 @ 50 MHz
560 @ 25 MHz
680 @ 25 MHz
820 @ 25 MHz
Percent
tolerance
3
20,10,5
20,10,5
20,10,5
20,10,5
20,10,5
20,10,5
20,10,5,2
20,10,5,2
20,10,5,2
20,10,5,2
20,10,5,2
20,10,5,2
20,10,5,2
20,10,5,2
20,10,5,2,1
20,10,5,2,1
20,10,5,2,1
20,10,5,2,1
20,10,5,2,1
10,5,2,1
10,5,2,1
10,5,2,1
20,10,5,2,1
10,5,2,1
20,10,5,2
10,5,2,1
10,5,2,1
10,5,2,1
10,5,2
20,10,5,2
10,5,2
10,5,2
10,5,2
10,5,2
10,5,2
10,5,2
10,5,2
SRF min
5
DCR max
6
Irms
max
7
Color
(MHz)
(Ohms)
(mA)
code
7900
7900
7900
5500
5500
4500
4700
4200
4000
3400
3300
2600
2000
2500
2050
1700
2000
1650
1650
1550
1450
1300
1200
1200
1000
1100
920
870
850
690
650
600
560
375
340
188
215
0.06
0.06
0.08
0.08
0.11
0.14
0.12
0.10
0.15
0.17
0.20
0.22
0.22
0.25
0.27
0.27
0.29
0.34
0.31
0.34
0.38
0.42
0.48
0.46
0.48
0.51
0.56
0.64
0.70
1.0
1.0
1.4
1.5
1.76
1.90
2.20
2.35
800
800
600
600
600
600
600
600
600
600
600
500
500
500
500
500
500
500
500
500
500
400
400
400
400
400
400
400
400
350
350
310
290
250
230
190
180
Gray
White
Black
Orange
Brown
Green
Red
Blue
Orange
Yellow
Green
Blue
Gray
Violet
Gray
Orange
White
Yellow
Black
Brown
Red
Orange
Black
Yellow
Brown
Green
Blue
Violet
Gray
Red
White
Black
Brown
Violet
Orange
Green
Blue
0805CS-020X _ B _
0805CS-3N0X _ B _
0805CS-030X _ B _
0805CS-050X _ B _
0805CS-060X _ B _
0805CS-070X _ B _
0805CS-080X _ B _
0805CS-100X _ B _
0805CS-120X _ B _
0805CS-150X _ B _
0805CS-180X _ B _
0805CS-220X _ B _
0805CS-240X _ B _
0805CS-270X _ B _
0805CS-330X _ B _
0805CS-360X _ B _
0805CS-390X _ B _
0805CS-430X _ B _
0805CS-470X _ B _
0805CS-560X _ B _
0805CS-680X _ B _
0805CS-820X _ B _
0805CS-910X _ B _
0805CS-101X _ B _
0805CS-111X _ B _
0805CS-121X _ B _
0805CS-151X _ B _
0805CS-181X _ B _
0805CS-221X _ B _
0805CS-241X _ B _
0805CS-271X _ B _
0805CS-331X _ B _
0805CS-391X _ B _
0805CS-471X _ B _
0805CS-561X _ B _
0805CS-681X _ B _
0805CS-821X _ B _
80 @ 1500 MHz
65 @ 1500 MHz
50 @ 1500 MHz
65 @ 1000 MHz
50 @ 1000 MHz
50 @ 1000 MHz
50 @ 1000 MHz
60 @ 500 MHz
50 @ 500 MHz
50 @ 500 MHz
50 @ 500 MHz
55 @ 500 MHz
50 @ 500 MHz
55 @ 500 MHz
60 @ 500 MHz
55 @ 500 MHz
60 @ 500 MHz
60 @ 500 MHz
60 @ 500 MHz
60 @ 500 MHz
60 @ 500 MHz
65 @ 500 MHz
65 @ 500 MHz
65 @ 500 MHz
50 @ 250 MHz
50 @ 250 MHz
50 @ 250 MHz
50 @ 250 MHz
50 @ 250 MHz
44 @ 250 MHz
48 @ 250 MHz
48 @ 250 MHz
48 @ 250 MHz
33 @ 100 MHz
23 @ 50 MHz
23 @ 50 MHz
23 @ 50 MHz
1. Specify
tolerance, termination,
and
packaging
codes:
0805CS-821XGBC
Tolerance: F
= 1%
G
= 2%
J
= 5%
K
= 10%
M
= 20%
(Table shows stock tolerances in bold.)
Termination:B
= Ag/Pd/Pt/Pb
L
= Lead free Ag/Pd/Pt
Packaging: C
= 7″ machine-ready reel. EIA-481 embossed plastic tape
(2000 per full reel).
B
= Less than full reel. On tape, but not machine-ready. To have a
leader and trailer added ($25 charge), use code letter C instead.
D
= 13″ machine-ready reel. EIA-481 embossed plastic tape.
Factory order only, not stocked (7500 per full reel).
2. Inductance measured using Coilcraft SMD-A fixture in Agilent/HP 4286A
impedance analyzer with Coilcraft-provided correlation pieces. For
recommended test procedures, contact Coilcraft.
3. Tolerances in bold are stocked for immediate shipment.
4. Q measured using Agilent/HP 4291A with Agilent/HP 16193 test fixture
and on Agilent/HP 8753D with Coilcraft SMD-D test fixture.
5. SRF measured using Agilent/HP 8720D network analyzer and Coilcraft
SMD-D test fixture.
6. DCR measured on Cambridge Technology micro-ohmmeter and Coilcraft
CCF858 test fixture.
7. Average current for a 15°C rise above 25°C ambient.
8. Operating temperature range
−40°C
to +125°C.
9. Electrical specifications at 25°C.
See Qualification Standards section for
environmental and test data.
Specifications subject to change without notice. Document 100-1 Revised 11/25/02
