Chip Inductors - 0603LS Series (1608)
These ferrite core surface mount inductors have lower
DCR and higher current ratings than our 0603CS Series.
They’re available with inductance values from 47 to 8200 nH.
Coilcraft
Designer’s Kit C147
contains samples of all
standard parts shown. To order, contact Coilcraft or visit
http://order.coilcraft.com
to order on-line.
2
Part Number
1
Inductance
2
(nH)
Percent
Tolerance
3
10,5
10,5
10,5
10,5
10,5
10,5
10,5
10,5
10,5
10,5
10,5
10,5
10,5
10,5
10,5
10,5
10,5
10,5
10,5
10,5
10,5
10,5
10,5
10,5
10,5
10,5
10,5
3
3
Q min
10
16
14
18
16
17
21
21
23
23
23
22
22
23
23
23
23
23
23
23
23
22
22
24
24
26
24
4
SRF min
5
(MHz)
>1800
>1800
>1800
1470
1460
1460
1140
1050
950
860
815
425
415
640
550
310
215
150
125
95
90
68
60
55
50
37
36
3
DCR max
6
(Ohms)
.04
.04
.04
.08
.09
.10
.16
.27
.32
.51
.56
.44
.52
.83
.67
.81
.87
.96
1.1
1.2
1.3
1.5
1.6
2.1
2.6
3.5
3.6
Color
Code
Black
Brown
Red
Orange
Yellow
Green
Violet
Grey
White
Black
Brown
Red
Orange
Yellow
Green
Blue
Violet
Grey
White
Black
Brown
Red
Orange
Yellow
Green
Blue
Violet
0603LS-47NX_B_
0603LS-72NX_B_
0603LS-101X_B_
0603LS-121X_B_
0603LS-151X_B_
0603LS-181X_B_
0603LS-241X_B_
0603LS-271X_B_
0603LS-331X_B_
0603LS-391X_B_
0603LS-471X_B_
0603LS-561X_B_
0603LS-681X_B_
0603LS-781X_B_
0603LS-821X_B_
0603LS-102X_B_
0603LS-122X_B_
0603LS-152X_B_
0603LS-182X_B_
0603LS-222X_B_
0603LS-272X_B_
0603LS-332X_B_
0603LS-392X_B_
0603LS-472X_B_
0603LS-562X_B_
0603LS-782X_B_
0603LS-822X_B_
47 @ 7.9 MHz
72 @ 7.9 MHz
100 @ 7.9 MHz
120 @ 7.9 MHz
150 @ 7.9 MHz
180 @ 7.9 MHz
240 @ 7.9 MHz
270 @ 7.9 MHz
330 @ 7.9 MHz
390 @ 7.9 MHz
470 @ 7.9 MHz
560 @ 7.9 MHz
680 @ 7.9 MHz
780 @ 7.9 MHz
827 @ 7.9 MHz
1000 @ 7.9 MHz
1200 @ 7.9 MHz
1500 @ 7.9 MHz
1800 @ 7.9 MHz
2200 @ 7.9 MHz
2700 @ 7.9 MHz
3300 @ 7.9 MHz
3900 @ 7.9 MHz
4700 @ 7.9 MHz
5600 @ 7.9 MHz
7800 @ 7.9 MHz
8200 @ 7.9 MHz
1. When ordering, please specify tolerance and packaging codes:
Inductance tolerance code:
Table above shows stock tolerances in bold.
J=
±5%,
K=
±10%
B
overall
F
A
G
F
E
terminal
C
I
J
I
D
Terminal wraparound:
approx. .007/0,18 both ends
H
0603LS-822X_B_
Packaging code:
C=7” machine-ready reel
EIA RS-481 clear plastic
tape. 2000 per reel.
B= Less than full reel
Not machine-ready. The
carrier tape may not be a single continuous length.
To have a leader and trailer added ($25 charge),
use code letter C instead.
Inductance measured at 100 kHz, 0.1 Vrms, using Coilcraft SMD-A fixture in
Agilent/HP 4286A impedance analyzer with Coilcraft-provided correlation
pieces. For recommended test procedures, contact Coilcraft.
Tolerances in bold are stocked for immediate shipment.
Q measured on Agilent/HP4291A with Agilent/HP16193 test fixture.
SRF measured using Agilent/HP8753D network analyzer with Coilcraft
SMD-D test fixture.
DCR measured on Cambridge Technology Micro-ohmmeter.
Operating temperature range -40° C to +85° C.
Electrical specifications at 25° C.
For environmental data, see “Product Specifications” page (Doc. 121)
Pad
Layout
2.
A max B max C max
.071
1,80
.048
1,22
.042
1,07
D ref
.015
0,38
E
.030
0,76
F
.013
0,33
G
.034
0,86
H
I
J
.040 .025 .025
1,02 0,64 0,64
3.
4.
5.
6.
7.
8.
9.
Parts/reel: 7” 2000 Tape width: 8 mm
For packaging data see “Tape and Reel Specifications” (Document 173)
Specifications subject to change without notice. Document 264 Revised 11/13/01
