Document 218-1
Chip Inductors – 0603HC (1608)
will handle transient currents up to 50% higher. At low
inductance values, their Q factors are also higher than
our 0603CS Series.
With their high current ratings and ultra-small size, these
chip inductors are ideal for today’s high frequency, low
voltage applications like mobile phones. They feature
continuous current ratings up to 2.4 Amps DC and
Inductance
2
Percent
(nH)
tolerance
3
1.6
5
3.6
5
3.9
5
6.8
5
7.5
5
10
5,2
12
5,2
15
5,2
18
5,2
22
5,2
24
5,2
33
5
47
5
Q
min
4
24
24
25
35
38
38
38
38
40
42
42
47
40
Part
0603HC-1N6XJL_
0603HC-3N6XJL_
0603HC-3N9XJL_
0603HC-6N8XJL_
0603HC-7N5XJL_
0603HC-10NX_L_
0603HC-12NX_L_
0603HC-15NX_L_
0603HC-18NX_L_
0603HC-22NX_L_
0603HC-24NX_L_
0603HC-33NXJL_
0603HC-47NXJL_
number
1
900 MHz
L typ Q typ
1.67
49
3.65
70
3.74
70
6.72
70
7.33
70
9.70
73
12.3
68
15.5
65
19.5
62
24.0
61
25.8
55
34.3
50
49.5
45
1.7 GHz
L typ Q typ
1.65
63
3.75
90
3.90
90
7.10
75
7.90
68
10.5
57
14.5
41
17.6
40
25.0
40
31.5
26
35.0
21
—
—
—
—
SRF
min
5
(MHz)
12500
5900
5900
5800
3700
3700
3000
2800
2800
2400
2400
1900
1530
DCR
max
6
(Ohms)
0.030
0.048
0.054
0.054
0.059
0.071
0.075
0.080
0.099
0.099
0.105
0.175
0.195
Irms
7
(A)
2.4
2.3
2.2
2.1
2.1
2.0
2.0
1.9
1.9
1.8
1.8
0.95
0.85
Color
code
Black
Brown
Red
Orange
Yellow
Green
Blue
Violet
Gray
White
Black
Brown
Red
1. When ordering, specify
tolerance, termination
and
packaging
codes:
0603HC-24NXJLW
Tolerance: G
= 2%
J
= 5% (Table shows stock tolerances in bold.)
Termination: L
= RoHS compliant silver-palladium-platinum-glass frit.
E
= Halogen free component. RoHS compliant silver-
palladium-platinum-glass frit terminations.
Special order:
T
= RoHS tin-silver-copper (95.5/4/0.5)
or
S
= non-RoHS tin-lead (63/37).
Packaging: W
= 7″ machine-ready reel. EIA-481 punched paper tape
(2000 parts per full reel).
U
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use
code letter W instead.
2. Inductance measured at 250 MHz using Coilcraft SMD-A fixture in
Agilent/HP 4286 impedance analyzer with Coilcraft-provided correla-
tion pieces.
3. Tolerances in bold are stocked for immediate shipment.
4. Q measured at 250 MHz using Agilent/HP 4291A with Agilent/
HP 16193 test fixture.
5. SRF measured using Agilent/HP 8720D network analyzer and Coil-
craft SMD-D test fixture.
6. DCR measured on micro-ohmmeter and Coilcraft CCF858 test fixture.
7. Current that causes a 20°C temperature rise from 25°C ambient.
8. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
Designer’s Kit C339
contains 10 of each of all 5% parts
Core material
Ceramic
Environmental
RoHS compliant, halogen free optional
Terminations
RoHS compliant silver-palladium-platinum-glass frit.
Weight
3.3 – 3.7 mg
Ambient temperature
–40°C to +125°C with
Irms
current, +125°C to
+145°C with derated current
Storage temperature
Component: –40°C to +145°C.
Tape and reel packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Temperature Coefficient of Inductance (TCL)
+25 to +125 ppm/°C
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
One per billion hours / one billion hours, calculated per Telcordia SR-332
Packaging
2000 per 7″ reel. Paper tape: 8 mm wide, 1.0 mm thick,
4 mm pocket spacing
PCB washing
Tested with pure water or alcohol only. For other solvents,
see Doc787_PCB_Washing.pdf.
US
+1-847-639-6400 sales@coilcraft.com
UK
+44-1236-730595 sales@coilcraft-europe.com
Taiwan
+886-2-2264 3646 sales@coilcraft.com.tw
China
+86-21-6218 8074 sales@coilcraft.com.cn
Singapore
+ 65-6484 8412 sales@coilcraft.com.sg
Document 218-1
Revised 09/30/13
© Coilcraft Inc. 2013
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specification subject to change without notice.
Please check web site for latest information.
URRENT
HIGH C
0603HC (1608) Chip Inductors
Typical Q vs Frequency
100
90
80
6.8 nH
3.6
5.6 nH
15 nH
Document 218-2
Typical L vs Frequency
30
22 nH
Inductance (nH)
70
Q Factor
60
50
40
30
20
10
0
22 nH
20
15 nH
10
6.8 nH
3.6 nH
0
1
10
100
1000
10000
1
10
100
1000
10000
Frequency (MHz)
Frequency (MHz)
Irms Derating
120
110
100
A
B
overall
F
G
F
E
terminal
C
D
Pick and
place
material
I
J
I
Terminal wraparound:
approx 0.008/0,20 both ends
H
Percent of rated
I
rms
90
80
70
60
50
40
30
20
10
0
-40
-20
0
20
40
60
80
100
120
140 160
Recommended
Land Pattern
25°C
A
B
C
D
max max max ref
E
F
G
H
I
J
0.071 0.044 0.040 0.015 0.030 0.013 0.034 0.040 0.025 0.025 inches
1,80 1,12 1,02 0,38 0,76 0,33 0,86 1,02 0,64 0,64 mm
Note:
Height dimension (C) is before optional solder application. For maximum
height dimension including solder, add 0.006 in / 0,152 mm.
Ambient temperature (°C)
US
+1-847-639-6400 sales@coilcraft.com
UK
+44-1236-730595 sales@coilcraft-europe.com
Taiwan
+886-2-2264 3646 sales@coilcraft.com.tw
China
+86-21-6218 8074 sales@coilcraft.com.cn
Singapore
+ 65-6484 8412 sales@coilcraft.com.sg
Document 218-2
Revised 09/30/13
© Coilcraft Inc. 2013
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specification subject to change without notice.
Please check web site for latest information.
