KRD
CONNECTOR
Emboss Tape
2.0mm pitch/Disconnectable Insulation displacement connectors
Specifications –––––––––––––––––––
• Current rating: 1.0 A AC, DC (AWG #26)
• Voltage rating: 100 V AC, DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/ 10 mΩ max.
After environmental tests/ 20 mΩ max.
• Insulation resistance: 1,000 MΩ min.
• Withstanding voltage: 800 VAC/minute
• Applicable wire: UL1571, UL1061 (Contact JST for details
regarding other UL styles.)
AWG #28, #26
Conductor/ 7 strands, tin-coated
Insulation O.D./ 0.9 to 1.0 mm
• Applicable PC board thickness: 0.8 to 1.6 mm
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
* Compliant with RoHS.
This 2.0 mm pitch insulation displacement
connector is another version of the NRD
connector for printed circuit boards.
The KRD connector allows daisy chaining
and is very useful in simplifying connection
systems in electronic equipment.
• Daisy chain connection
• Twin slot insulation displacement section
• Distortion resistant construction
• Interchangeability
• Low profile design - a mere 9.0 mm high from
the PC board surface
Standards ––––––––––––––––––––––
1
Certified LR20812
Side entry type
0
Recognized E60389
PC board layout and Assembly layout
<Through-hole type>
Top entry type
2
±0.05
4.9
10.6
2
±0.05
7.6
9
4.8
φ0.7
＋0.1
0
3.4
φ0.7
＋0.1
0
Note: 1. The above figure is the figure viewed from soldering side.
2. Tolerances are non-cumulative:
±
0.05 mm for all centers.
3. Hole dimensions differ according to the type of PC boards and piercing method. If PC boards made of hard material are used,
the hole dimensions should be larger. The dimensions above should serve as a guideline. Contact JST for details.
6.25
<SMT type/SM4 type>
Top entry type
1.6
±0.1
1.6
±0.1
2
±0.05
Side entry type
1.5
±0.1
1.6
±0.1
2
±0.05
0.2
10.6
7.6
（1）
5
End face of wafer on the mating side
1
End face of wafer on the mating side
3
±0.1
3.4
±0.1
2
max
7.5
min
9.6
6.6
5.5
max
9
min
1
min
（2）
1
min
Note: 1. The above figure is the figure viewed from the connector mounting side.
2. Tolerances are non-cumulative:
±
0.05 mm for all centers.
3. The dimensions above should serve as a guideline. Contact JST for details.
1
5.5
4.9
KRD CONNECTOR
Socket
Circuits
2
3
4
5
6
7
8
9
JST
7.25
Model No.
AWG #28(green) AWG #26(natural/white)
02KR-D8M-P
03KR-D8M-P
04KR-D8M-P
05KR-D8M-P
06KR-D8M-P
07KR-D8M-P
08KR-D8M-P
09KR-D8M-P
10KR-D8M-P
11KR-D8M-P
12KR-D8M-P
13KR-D8M-P
14KR-D8M-P
15KR-D8M-P
16KR-D8M-P
02KR-D6S-P
03KR-D6S-P
04KR-D6S-P
05KR-D6S-P
06KR-D6S-P
07KR-D6S-P
08KR-D6S-P
09KR-D6S-P
10KR-D6S-P
11KR-D6S-P
12KR-D6S-P
13KR-D6S-P
14KR-D6S-P
15KR-D6S-P
16KR-D6S-P
Material and Finish
Dimensions (mm)
A
B
2.0
4.0
6.0
8.0
10.0
12.0
14.0
16.0
18.0
20.0
22.0
24.0
26.0
28.0
30.0
6.0
8.0
10.0
12.0
14.0
16.0
18.0
20.0
22.0
24.0
26.0
28.0
30.0
32.0
34.0
Q'ty/
box
2,000
2,000
2,000
1,000
1,000
1,000
1,000
500
500
500
500
500
500
500
500
10
11
12
13
14
15
16
2
2
A
B
3.5
4.9
Contact: Phosphor bronze, tin-plated (reflow treatment)
Housing: PA 66, UL94V-0
RoHS compliance
<For reference>
As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex.
02KR-D6S-P
AWG #26: S…natural (white)
AWG #28: M…green
Shrouded header
The shrouded headers are interchangeable with the PH crimp style connectors and with CR and KR insulation displacement connectors.
