EL2186, EL2286
Data Sheet
September 26, 2001
FN7056
250MHz/3mA Current Mode Feedback
Amp w/Disable
The EL2186/EL2286 are single/dual
current-feedback operational
amplifiers which achieve a -3dB
bandwidth of 250MHz at a gain of +1 while consuming only
3mA of supply current per amplifier. They will operate with
dual supplies ranging from ±1.5V to ±6V, or from single
supplies ranging from +3V to +12V. The EL2186/EL2286
also include a disable/power-down feature which reduces
current consumption to 0mA while placing the amplifier
output in a high impedance state. In spite of its low supply
current, the EL2286 can output 55mA while swinging to ±4V
on ±5V supplies. The EL2186 can output 100mA with similar
output swings. These attributes make the EL2186/EL2286
excellent choices for low power and/or low voltage cable-
driver, HDSL, or RGB applications.
For Single, Dual and Quad applications without disable,
consider the EL2180 (8-Pin Single), EL2280 (8-Pin Dual) or
EL2480 (14-Pin Quad). For lower power applications where
speed is still a concern, consider the EL2170/EL2176 family
which also comes in similar Single, Dual and Quad
configurations. The EL2170/EL2176 family provides a -3dB
bandwidth of 70MHz while consuming 1mA of supply current
per amplifier.
Features
• Single (EL2186) and dual (EL2286) topologies
• 3mA supply current (per amplifier)
• 250MHz -3dB bandwidth
• Low cost
• Fast disable
• Powers down to 0mA
• Single- and dual-supply operation down to ±1.5V
• 0.05%/0.05° diff. gain/diff. phase into 150Ω
• 1200V/µs slew rate
• Large output drive current:
-100mA (EL2186)
-55mA (EL2286)
• Also available without disable in single (EL2180), dual
(EL2280) and quad (EL2480)
• Lower power EL2170/EL2176 family also available
(1mA/70MHz) in single, dual and quad
Applications
• Low power/battery applications
• HDSL amplifiers
• Video amplifiers
Ordering Information
PART NUMBER
EL2186CN
EL2186CS
EL2286CN
EL2286CS
TEMP. RANGE
-40°C to +85°C
-40°C to +85°C
-40°C to +85°C
-40°C to +85°C
PACKAGE
8-Pin PDIP
8-Pin SOIC
14-Pin PDIP
14-Pin SOIC
PKG. NO.
MDP0031
MDP0027
MDP0031
MDP0027
• Cable drivers
• RGB amplifiers
• Test equipment amplifiers
• Current to voltage converters
Pinouts
EL2186*
(8-PIN SO, PDIP)
TOP VIEW
EL2286*
(14-PIN SO, PDIP)
TOP VIEW
*Manufactured under U.S. Patent No. 5,418,495
1
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 321-724-7143
|
Intersil (and design) is a registered trademark of Intersil Americas Inc.
Copyright © Intersil Americas Inc. 2003. All Rights Reserved. Elantec is a registered trademark of Elantec Semiconductor, Inc.
All other trademarks mentioned are the property of their respective owners.
EL2186, EL2286
Absolute Maximum Ratings
(T
A
= 25°C)
Voltage between V
S
+ and V
S
- . . . . . . . . . . . . . . . . . . . . . . . . +12.6V
Common-Mode Input Voltage . . . . . . . . . . . . . . . . . . . . . V
S
- to V
S
+
Differential Input Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .±6V
Current into +IN or -IN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .±7.5mA
Internal Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . See Curves
Operating Ambient
Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . .-40°C to +85°C
Operating Junction Temperature
Plastic Packages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150°C
Output Current (EL2186) . . . . . . . . . . . . . . . . . . . . . . . . . . . ±120mA
Output Current (EL2286) . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±60mA
Storage Temperature Range . . . . . . . . . . . . . . . . . .-65°C to +150°C
CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation of the
device at these or any other conditions above those indicated in the operational sections of this specification is not implied.
IMPORTANT NOTE: All parameters having Min/Max specifications are guaranteed. Typical values are for information purposes only. Unless otherwise noted, all tests
are at the specified temperature and are pulsed tests, therefore: T
J
= T
C
= T
A
DC Electrical Specifications
PARAMETER
V
OS
TCV
OS
dV
OS
+I
IN
d+I
IN
-I
IN
d-I
IN
CMRR
-ICMR
PSRR
-IPSR
R
OL
+R
IN
+C
IN
CMIR
V
O
Input Offset Voltage
V
S
= ±5V, R
L
= 150Ω, ENABLE = 0V, T
A
= 25°C unless otherwise specified
CONDITIONS
MIN
TYP
2.5
Measured from T
MIN
to T
MAX
EL2286 only
5
0.5
1.5
EL2286 only
20
16
EL2286 only
V
CM
= ±3.5V
45
2
50
5
60
70
1
120
0.5
300
2
1.2
±3.5
V
S
= ±5
V
S
= +5 Single-Supply, High
V
S
= +5 Single-Supply, Low
±3.5
±4.0
±4.0
4.0
0.3
80
50
100
55
10
3
0
4.4
45
85
-0.04
-53
4.5
2.0
6
50
15
30
40
15
MAX
15
UNIT
mV
µV/°C
mV
µA
nA
µA
µA
dB
µA/V
dB
µA/V
kΩ
MΩ
pF
V
V
V
V
mA
mA
µA
mA
µA
pF
kΩ
µA
µA
V
V
DESCRIPTION
Average Input Offset Voltage Drift
V
OS
Matching
+ Input Current
+ I
IN
Matching
- Input Current
-I
IN
Matching
Common Mode Rejection Ratio
- Input Current Common Mode Rejection V
CM
= ±3.5V
Power Supply Rejection Ratio
- Input Current Power Supply Rejection
Transimpedance
+ Input Resistance
+ Input Capacitance
Common Mode Input Range
Output Voltage Swing
V
S
is moved from ±4V to ±6V
V
S
is moved from ±4V to ±6V
V
OUT
= ±2.5V
V
CM
= ±3.5V
I
O
Output Current
EL2186 only
EL2286 only, per Amplifier
I
OUT, OFF
I
S
I
S(DIS)
C
OUT(DIS)
R
EN
I
IH
I
IL
V
DIS
V
EN
Output Current Disable
Supply Current
Supply Current (Disabled)
Output Capacitance (Disabled)
Enable Pin Input Resistance
Logic “1” Input Current
Logic “0” Input Current
Minimum Voltage at ENABLE to Disable
Maximum Voltage at ENABLE to Enable
V
OUT
±2V, A
V
= +1@25°C
ENABLE = 2.0V, per Amplifier
ENABLE = 4.5V
ENABLE = 4.5V
Measured at ENABLE = 2.0V, 4.5V
Measured at ENABLE, ENABLE = 4.5V
Measured at ENABLE, ENABLE = 0V
2
