146292-2 Product Details
Live Product Chat
Product Photo
.100 inch AMPMODU Headers
Not re vie we d for R oHS C om plia nce
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
146292-2
T E I nternal N umber: 1 4 6 2 9 2 - 2
Product Highlights:
l
Header
l
Header Type = Breakaway
l
Number of Rows = Single
l
Number of Positions = 2
l
Mating Post Length = 5.84 mm
View all Features
Superseded
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
HEADER ASSEMBLY, MODII, BREAKAWAY,SINGLE ROW,HIGH T...
(PDF, English)
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Header
l
Number of Positions
= 2
l
Mount Angle
= Vertical
l
PC B Retention Feature
= Yes
l
Surface Mount C ompatible
= Yes
l
Board Standoff
= With
l
Mounting Ears
= Without
l
Mating C onnector Lock
= Without
l
Post Size (mm [in]) = 0.64 [.025]
Mechanical Attachment:
l
Mating Post Length (mm [in]) = 5.84 [0.230]
l
Panel Attachment
= Without
Termination Related Features:
l
Termination Post Length (mm [in])
= 3.05 [0.120]
l
Solder Tail C ontact Plating = Tin-Lead over Nickel
Body Related Features:
l
Header Type
= Breakaway
l
Number of Rows
= Single
l
C enterline, Matrix (mm [in])
= 2.54 [.100]
l
Selectively Loaded
= No
l
PC B Retention Method
= Retention Solder Tails
l
Mount Type
= Printed C ircuit Board
Contact Related Features:
l
C ontact Mating Area Plating Material
= Gold (15)
l
C ontact Shape = Square
l
C ontact Base Material = Phosphor Bronze
Housing Related Features:
l
Housing Material = PPA
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Conditions for Usage:
l
High Temperature Housing
= Yes
Operation/Application:
l
High Speed Serial Data C onnector
= No
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
