RM7935/RM7965
64-bit Microprocessors with Integrated L2 Cache and EJTAG
Released
Product Brief
PRODUCT HIGHLIGHTS
•
New high performance MIPS64-compatible Instruction Set
•
High-performance system interface:
•
•
•
•
•
32-bit multiplexed address/data (SysAD) bus with RM7935.
64-bit SysAD with RM7965.
Multiple outstanding reads with out-of-order return.
1600 Mbyte/s peak throughput.
200 MHz maximum frequency using HSTL signaling on the SysAD
bus.
SysAD bus supports 1.5 V, 2.5 V, 3.3 V I/O logic.
Processor clock multipliers 2, 3, 3.5, 4, 4.5, 5, 5.5, 6, 6.5, 7, 7.5, 8,
8.5, 9, 10, 11, 12, 13, 14, 15, 16, 17.
Architecture with integrated L2 cache and EJTAG:
•
•
•
•
•
•
668, 750, 835 and 900 MHz operating frequency.
1890 Dhrystone 2.1 MIPS @ 900 MHz.
Dual-issue superscalar 7-stage pipeline.
16 Kbyte, 4-way set associative L1 Instruction cache.
16 Kbyte, 4-way set associative L1 Data cache.
256 Kbyte, 4-way set associative L2 cache with industry best 5-
cycle access latency.
Fast Packet Cache to assists processing of packet data.
8K entry branch prediction table.
Fully associative 64-entry TLB with dual pages.
High-performance Floating Point Unit (IEEE 754).
Fixed-point DSP instructions such as Multiply/Add,
Multiply/Subtract, and 3 Operand Multiply.
•
•
•
•
•
•
•
•
Integrated on-chip EJTAG capability.
•
A 64-entry dynamic Trace Buffer for use in real-time trace and
debug.
•
Two 32-bit virtually-addressed Watch registers.
•
Integrated performance counters:
•
•
2 independent 32-bit counters.
Counts over 30 processor events including miss predicted
branches.
Enables full characterization and analysis of application
software.
•
BLOCK DIAGRAM
On-Chip Debug
64-bit Integer Unit
Dual-Issue Superscalar
Integer Multiplier
Branch Trace Buffer
64-bit Floating Point Unit
Double/Single IEEE-754
Instruction Dispatch
8K Entry Branch History Tbl
Instruction Cache
16 KB, 4-way
Line Lockable
Memory Manager
64-Entry, Dual Page
Data Cache
16 KB, 4-way
Line Lockable
Interface Unit
System Control
Secondary Cache
256 KB, 4-way
Line Lockable
E9000 Core
SysAD
System Interface
Interrupt
Interface
EJTAG/JTAG
Controller
Cache Test
Mode
PLL & Clock
PMC-2030350, Issue 4
© Copyright PMC-Sierra, Inc. 2003–2006
All rights reserved. Proprietary and Confidential to PMC-Sierra, Inc. and for its customers’ internal use.
RM7935/RM7965 64-bit Microprocessors with Integrated L2 Cache and EJTAG
PACKAGING
•
RM7935 is available in a 128-pin enhanced exposed pad (eePad)
EVALUATION BOARDS
•
Momentum Computer
•
Marvell Semiconductor
package (20 x 20 mm), pin-compatible with the RM5231A and
RM7035C exposed pad products.
•
RM7965 package options:
•
COMPANION CHIPS
•
Marvell Semiconductor: (MV-64340, GT-64240)
256-pin TBGA package, 27 x 27 mm, pin compatible with
RM7065A and RM7065C TBGA products.
216-pin enhanced exposed pad (eePad) package,
24 x 24 mm, pin compatible with the RM5261A and RM7965C
exposed pad products.
•
APPLICATIONS
•
Voice Gateways
•
Multi-Service Access Platforms
•
DSLAMs/Access Concentrators
•
Remote Access Switches
•
Web Switches
•
Layer 3 Switches
•
Backbone Switches/Routers
•
RAIDs
•
Set Top Boxes
•
Networked Printers
•
Cellular Base Stations
DEVELOPMENT TOOLS
OPERATING SYSTEMS
•
Linux
•
VxWorks
EJTAG EMULATORS
•
Wind River
•
Corelis
TYPICAL APPLICATIONS
RM7935
RM7965
32-Bit
100 MHz
ITE
IT-8172G
or
ASIC
PCI Bus
32-bit @ 33 MHz
32-bit
PCI-to-PCI
Bridge
32-bit
32-bit
32-bit
32-Bit
100 MHz
SDRAM
PCI-(X) Bus
2x32/64-bit @ 66 MHz
64-bit
Boot-Flash
Flash
Disk
Watchdog,
I
2
C & Control
Registers
Dual UART
PCI-to-PCI
Bridge
GbE MAC
32-bit
32-bit
64-Bit
200 MHz
Marvell
MV-64340
or
ASIC
2x64-bit
64-Bit
183 MHz
DDR
SDRAM
Data
Buffer
8-bit
Data
Buffer
8-bit
Boot-Flash
Flash
Disk
Watchdog,
I
2
C & Control
Registers
Dual UART
GbE MAC
GbE MAC
GbE MAC
Corporate Head Office:
PMC-Sierra, Inc.
Mission Towers One
3975 Freedom Circle
Santa Clara, CA, 95054, U.S.A.
Tel: 1.408.239.8000
Fax: 1.408. 492.1157
Operations Head Office:
PMC-Sierra, Inc.
100-2700 Production Way
Burnaby, BC V5A 4X1 Canada
Tel: 1.604.415.6000
Fax: 1.604.415.6200
PMC-2030350 (R4) © Copyright PMC-Sierra, Inc. 2003–2006. All
rights reserved. For a complete list of PMC-Sierra’s trademarks , visit
www.pmc-sierra.com/legal/. Other product and company names
mentioned herein may be the trademarks of their respective owners.
For corporate information, send email to: info@pmc-sierra.com.
All product documentation is available on our web site at:
www.pmc-sierra.com.
