6-174650-5 Product Details
Live Product Chat
Product Photo
.100 inch AMPMODU Receptacles
Not re vie we d for R oHS C om plia nce
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
6-174650-5
T E I nternal N umber: 6 - 1 7 4 6 5 0 - 5
Product Highlights:
l
Receptacle
l
Mod II
l
Number of Positions = 10
l
Number of Rows = Dual
l
Standard Profile
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
No title
(PDF, English)
l
EC ONOMY AMPMODU C ONNEC TOR
(PDF, English)
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Receptacle
l
C onnector Series
= Mod II
l
Number of Positions
= 10
l
Profile
= Standard
l
Mount Angle
= Vertical
l
Mounting Pattern (mm [in])
= 2.54 x 2.54 [.100 x .100]
l
Sealed
= No
l
Holddown Feature
= Without
l
PC B Retention Feature = No
l
C losed Entry = With
l
Board Standoff = With
l
PC B Thickness (mm [in]) = 1.60 [0.063]
l
C omment = Mate with 5.8 - 6.5 mm Length Posts
Mechanical Attachment:
l
Stackable
= Yes
Termination Related Features:
l
Termination Post Length (mm [in])
= 2.60 [0.102]
l
Solder Tail C ontact Plating = Tin-Lead over Nickel
Body Related Features:
l
Number of Rows
= Dual
l
C onnector Height (mm [in])
= 6.00 [0.236]
l
C enterline, Matrix (mm [in])
= 2.54 x 2.54 [.100 x .100]
Contact Related Features:
l
C ontact Termination Type
= Through Hole
l
C ontact Mating Area Plating Material
= Gold (8)
l
C ontact Base Material = Phosphor Bronze
l
C ontact Type = Dual Tine
Housing Related Features:
l
Housing Entry Style = Top
l
Housing Material = Polyester
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
Government/Industry Qualification = No
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Conditions for Usage:
l
High Temperature C ompatible = No
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
