This document was generated on 11/06/2009
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0460101011
Active
4.20mm (.165") Pitch Mini-Fit Plus HCS™ PCB Receptacle, Dual Row, Vertical, Blind
Mating, 10 Circuits, with Snap-in Plastic Peg PCB Lock, PA Polyamide Nylon 6/6, UL
94V-2, Tin (Sn) Over Nickel (Ni) Plating
Documents:
3D Model
Drawing (PDF)
General
Product Family
Series
Application
Comments
Overview
Product Name
Physical
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
Flammability
Glow-Wire Compliant
Guide to Mating Part
Keying to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Number of Rows
Orientation
PC Tail Length (in)
PC Tail Length (mm)
PCB Locator
PCB Retention
PCB Thickness Recommended (in)
PCB Thickness Recommended (mm)
Packaging Type
Pitch - Mating Interface (in)
Pitch - Mating Interface (mm)
Plating min: Mating (µin)
Plating min: Mating (µm)
Plating min: Termination (µin)
Plating min: Termination (µm)
Polarized to Mating Part
Polarized to PCB
Stackable
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
Electrical
Current - Maximum
RoHS Certificate of Compliance (PDF)
Series image - Reference only
PCB Receptacles
46010
Board-to-Board
Polarized to Mating Part
Mini-Fit HCS™
Mini-Fit Plus HCS™
10
10
Natural
30
94V-2
No
Yes
None
None
Copper Alloy
Tin
Tin
Nylon
2
Vertical
0.071 In
1.80 mm
Yes
Yes
0.070 In
1.78 mm
Tray
0.165 In
4.20 mm
100
2.54
50
1.27
Yes
Yes
No
No
-40°C to +105°C
Through Hole
12A
EU RoHS
China RoHS
ELV and RoHS
Compliant
REACH SVHC
Not Reviewed
Halogen-Free
Status
Not Reviewed
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
Duration at Max.
Process Temperature
(seconds)
Lead-free Process
Capability
Max. Cycles at Max.
Process Temperature
Process Temperature
max. C
5
Wave Capable (TH
only)
1
235
Search Parts in this Series
46010 Series
Mates With
42404 Mini-Fit BMI™ Right Angle Header,
46011 Mini-Fit Plus HCS™ Vertical Header,
42475 Mini-Fit BMI™ Plug Housing
