MA SERIES

P3AU-XXXXE 1KV ISOLATED 0,5W UNREGULATED SINGLE OUTPUT SIP4

Available Inputs:

5, 12 and 24 VDC

Available Outputs:

3.3, 5, 7.2, 12, 15 and 18 VDC

Other specifications please enquire.

Electrical Specifications

(Typical at + 25° C, nominal input voltage, rated output current unless otherwise specified)

Input Specifications

Voltage range

Filter

Isolation Specifications

Rated voltage

Leakage current

Resistance

Capacitance

Output Specifications

Voltage accuracy

Ripple and noise (at 20 MHz BW)

Short circuit protection

Line voltage regulation

Load voltage regulation

Temperature coefficient

General Specifications

Efficiency

Switching frequency

Environmental Specifications

Operating temperature (ambient)

Storage temperature

Derating

Humidity

Cooling

Physical Characteristics

Dimensions SIP

Weight

Case material

+/- 10 %

Capacitors

1000 VDC

1 mA

Ohm

60 pF typ.

+/- 5 %, max.

100 mV p-p, max.

Momentary

+/- 1,2 % / 1,0 % of Vin

+/- 8 %, load = 20 ~ 100 %

+/- 0,02 % / °C

75 % to 85 %

80 KHz, typ.

- 40° C to + 85° C

- 55 °C to + 125 °C

See graph

Up to 90 %, non condensing

Free air convection

11.68 x 6.00 x 10.16 mm

0.46 x 0,24 x 0,40 inches

1,8 g

Non conductive black plastic

Examples of Partnumbers

PART

NO.

INPUT

VOLTAGE

(VDC)

INPUT

CURRENT

NO LOAD

INPUT

CURRENT

FULL

LOAD

OUTPUT

VOLTAGE

(VDC)

OUTPUT

CURRENT

(max. mA)

EFFICIENCY FULL LOAD

(% TYP.)

P3AU-053R3E

P3AU-0505E

P3AU-057R2E

P3AU-0512E

P3AU-1205E

P3AU-1212E

P3AU-2405E

133

135

134

133

3,3

7,2

150

100
