F-212
PCIEC–098–0151–EC–EM
PCIEC–064–0151–EC–EC–P
(1,00mm) .03937"
PCIEC SERIES
PCI EXPRESS JUMPERS
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?PCIEC
®
Mates with:
PCIE
30 AWG
ribbon cable
Connector:
PCIEC
Cable
Length
6" (152mm)
Rated @ 7dB
Insertion Loss
–DP
4.70 GHz / 9.40 Gbps
Insulator Material:
Black Nylon
Contact:
Phosphor Bronze
Plating:
Au or Sn over
50µ" (1,27µm) Ni
Operating Temp:
-55°C to +125°C
Card Insertion Depth:
(8,00mm) .315" nominal
RoHS Compliant:
Yes
Performance data for other cable lengths
and complete test data available at
www.samtec.com?PCIEC or contact
sig@samtec.com
Supports one, four,
eight and sixteen
PCI Express
®
links
30 AWG
twinax ribbon
cable
Card:
APPLICATIONS
Loop back Extender (From one PCIe
®
slot to another PCIe
®
slot)
Ser-Des Physical Extender (From one PCIe
®
slot to another PCIe
®
Ser-Des)
Physical Extender for easy troubleshooting of PCIe
®
card debug and analysis
(PCIe
®
slot to Emulator or Analyzer)
Conductor:
1
/
2
oz. Copper
Contact Area:
Hard Gold (Contact area)
Insulator:
Nelco 4000-13
RoHS Compliant:
Yes
Cable:
Conductor:
30 AWG shielded twinax
30 AWG standard ribbon
RoHS Compliant:
Yes
PCIEC
NO. OF
POSITIONS
WIRE
LENGTH
END
NO. 1
END
NO. 2
POWER
LINES
–“XXXX”
–036, –064,
–098, –164
= Wire Length
in millimeters
0044mm minimum
–EC
= Edge
Card
–EC
= PCIe
®
Edge Card
–P
= Power Lines
(Leave Blank
for no
Power Lines)
ALSO
AVAILABLE
PCI Express
Card Sockets. See
www.samtec.com?PCIE
®
–EM
= PCIe
®
Edge Mount
Connector
OAL = Wire Length +
L
END TO END
–EC to –EC
–EC to –EM
L
(39,6) 1.56
(49,6) 1.95
A
B
NO. OF
POSITIONS
–036
–064
–098
–164
A
(20,30) .800
(34,30) 1.35
(51,30) 2.02
(84,30) 3.32
B
(25,40) 1.00
(39,40) 1.55
(56,40) 2.22
(89,40) 3.52
(1,57)
.062
PCI Express
®
is a registered
trademark of PCI-SIG
®
.
Note:
This Series is non-standard,
non-returnable.
Wire Length = ±(1,27) .050
(8,71)
.343
(10,11)
.398
WWW.SAMTEC.COM
