5-174650-8: DescriptionHEADER CONNECTOR,PCB MNT,PLUG,34 CONTACTS,SKT,0.1 PITCH,PC TAIL TERMINAL,BLACK; CategoryThe connector The connector; File Size104KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

5-174650-8 Overview

HEADER CONNECTOR,PCB MNT,PLUG,34 CONTACTS,SKT,0.1 PITCH,PC TAIL TERMINAL,BLACK

5-174650-8 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknow
Other features	WITH STANDOFF, CLOSED ENTRY
body width	0.236 inch
subject depth	0.268 inch
body length	1.701 inch
Body/casing type	PLUG
Connector type	BOARD CONNECTOR
Contact to complete cooperation	AU ON NI
Contact completed and terminated	TIN/LEAD OVER NICKEL
Contact point gender	FEMALE
Contact material	PHOSPHOR BRONZE
contact mode	RECTANGULAR
Contact resistance	12 mΩ
Contact style	SQ PIN-SKT
Dielectric withstand voltage	1000VAC V
Durability	200 Cycles
maximum insertion force	1.668 N
Insulation resistance	1000000000 Ω
Insulator color	BLACK
insulator material	THERMOPLASTIC
Manufacturer's serial number	174650
Plug contact pitch	0.1 inch
Match contact row spacing	0.1 inch
Installation method	STRAIGHT TOP MOUNT
Installation type	BOARD
Number of connectors	ONE
PCB row number	2
Number of rows loaded	2
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
PCB contact pattern	RECTANGULAR
PCB contact row spacing	2.54 mm
Plating thickness	30u inch
Guideline	UL, CSA
reliability	COMMERCIAL
Terminal length	0.102 inch
Terminal pitch	2.54 mm
Termination type	SOLDER
Total number of contacts	34
Evacuation force-minimum value	.1946 N
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

PC B C onnectors

Product Feature Selector

> Product Details

5-174650-8 Product Details

Live Product Chat

Product Photo

.100 inch AMPMODU Receptacles

Not re vie we d for R oHS C om plia nce

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

5-174650-8

T E I nternal N umber: 5 - 1 7 4 6 5 0 - 8

Product Highlights:

Receptacle

Mod II

Number of Positions = 34

Number of Rows = Dual

Standard Profile

View all Features

Obsolete

C ontact Product Information C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

None Available

Product Specifications:

No title

(PDF, English)

EC ONOMY AMPMODU C ONNEC TOR

(PDF, English)

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= Receptacle

C onnector Series

= Mod II

Number of Positions

= 34

Profile

= Standard

Mount Angle

= Vertical

Mounting Pattern (mm [in])

= 2.54 x 2.54 [.100 x .100]

Sealed

= No

Holddown Feature

= Without

PC B Retention Feature = No

C losed Entry = With

Board Standoff = With

PC B Thickness (mm [in]) = 1.60 [0.063]

C omment = Mate with 5.8 - 6.5 mm Length Posts

Mechanical Attachment:

Stackable

= Yes

Termination Related Features:

Termination Post Length (mm [in])

= 2.60 [0.102]

Solder Tail C ontact Plating = Tin-Lead over Nickel

Body Related Features:

Number of Rows

= Dual

C onnector Height (mm [in])

= 6.00 [0.236]

C enterline, Matrix (mm [in])

= 2.54 x 2.54 [.100 x .100]

Contact Related Features:

C ontact Termination Type

= Through Hole

C ontact Mating Area Plating Material

= Gold (30)

C ontact Base Material = Phosphor Bronze

C ontact Type = Dual Tine

Housing Related Features:

Housing Entry Style = Top

Housing Material = Polyester

Housing Flammability Rating = UL 94V-0

Industry Standards:

Government/Industry Qualification = No

RoHS/ELV C ompliance

= Not reviewed for ELV/RoHS compliance

Lead Free Solder Processes

= Not reviewed for lead free solder

process

Conditions for Usage:

High Temperature C ompatible = No

Other:

Brand = AMP

Additional Information:
