FM
CONNECTOR
1.0mm
pitch
Emboss Tape
Connectors for FFC and FPC
Features––––––––––––––––––––––––
• Compact
Having no complicated cam or slide mechanism, this
connector is small with a mounting height of only 4.4mm and a
width of 3.0mm.
• Double-sided contact
This connector has highly resilient phosphor bronze contacts,
each of which has two independent mating spring members
that ensure continuity even when subjected to severe vibration.
Because each of the contacts simultaneously mates with both
sides of the FFC or FPC, the engineer has greater freedom in
designing his circuitry.
• Simple snap-in action
The FFC or FPC are securely connected by simply inserting
their leads into the connector.
The FM connector, a miniature connector with a
thickness of only 3.0mm, was developed to
connect flexible flat cables (FFC) or flexible
printed circuits (FPC) with a lead pitch of
1.0mm to printed circuit boards. It is ideally
suited for connections inside high-density
equipment or between mechanical units. The
contact is constructed to ensure a stable
connection and high reliability even under
vibration and impact. Connection is easy with a
simple snap-in action.
• Surface mount model (SMT)
This connector is also available in a surface mount
configuration. Its housing is made of heat resistant resin so that
it is not adversely affected during reflow soldering. Because of
its tiny size and ability to be surface mounted, this connector
meets the demand for high-density mounting of components
inside electronic products.
Specifications –––––––––––––––––––
• Current rating: 0.5A AC, DC
• Voltage rating: 50V AC, DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/20m
Ω
max.
After environmental testing/30m
Ω
max.
• Insulation resistance: 800M
Ω
min.
• Withstanding voltage: 500V AC/minute
• Applicable FFC and FPC: Conductor pitch/1.0mm
Conductor width/0.7mm
Mating part thickness/0.33
+0.02
mm
-0.03
• Applicable PC board thickness: 0.8 to 1.6mm
<Note
>FFC/
FPC to be actually used should be checked for applicability.
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
Standards ––––––––––––––––––––––
0
1
Recognized E60389
Certified LR20812
1
FM
CONNECTOR
Connector –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Top entry type
(Through-hole type)
B
C
A
1.0
7.3
1.5
Insertion
depth
2.8
4.4
2.9
B
C
A
1.0
(SMT type)
1.5
Insertion
depth
2.8
4.4
3.0
2.0
0.4
Circuit No.1
Circuit No.1
0.5
0.4
Circuit No.1
Side entry type
(Through-hole type)
B
C
A
1.0
1.5
Insertion
depth
4.4
2.8
B
C
A
1.0
(SMT type)
1.5
Insertion
depth
4.4
2.8
3.0
0.4
3.0
Circuit No.1
Circuit No.1
3.0
2.0
3.0
1.9
Circuit No.1
0.4
4.35
2.0
0.5
Through-hole type connector
Model No. of Through-hole type
Circuits
Top entry type
03FM-1.0BT
04FM-1.0BT
05FM-1.0BT
06FM-1.0BT
07FM-1.0BT
08FM-1.0BT
10FM-1.0BT
11FM-1.0BT
12FM-1.0BT
Side entry type
03FM-1.0ST
04FM-1.0ST
05FM-1.0ST
06FM-1.0ST
07FM-1.0ST
08FM-1.0ST
10FM-1.0ST
11FM-1.0ST
12FM-1.0ST
A
2.0
3.0
4.0
5.0
6.0
7.0
9.0
10.0
11.0
Dimensions (mm)
B
5.0
6.0
7.0
8.0
9.0
10.0
12.0
13.0
14.0
C
4.1
5.1
6.1
7.1
8.1
9.1
11.1
12.1
13.1
Q'ty / box
3
4
5
6
7
8
10
11
12
2,000
2,000
2,000
1,000
1,000
1,000
1,000
1,000
1,000
SMT type connector on embossed-tape
Circuits
3
4
5
6
7
8
10
12
Model No.
Top entry type
–
Dimensions (mm)
Side entry type
A
2.0
3.0
4.0
5.0
6.0
7.0
9.0
11.0
Q'ty / reel
C
4.1
5.1
6.1
7.1
8.1
9.1
11.1
13.1
B
5.0
6.0
7.0
8.0
9.0
10.0
12.0
14.0
Top entry type Side entry type
–
1,000
1,000
1,000
1,000
1,000
1,000
–
2,500
2,500
2,500
2,500
2,500
2,500
2,000
2,000
03FM-1.0SP-1.9-TF
04FM-1.0SP-1.9-TF
05FM-1.0SP-1.9-TF
06FM-1.0SP-1.9-TF
07FM-1.0SP-1.9-TF
08FM-1.0SP-1.9-TF
10FM-1.0SP-1.9-TF
12FM-1.0SP-1.9-TF
04FM-1.0BP-TF
05FM-1.0BP-TF
06FM-1.0BP-TF
07FM-1.0BP-TF
08FM-1.0BP-TF
10FM-1.0BP-TF-A
–
Material and Finish
(Through-hole type) Contact: Phosphor bronze, copper-undercoated, tin-plated (reflow treatment)
Housing: PBT, UL94V-0
(SMT type) Contact: Phosphor bronze, copper-undercoated, tin-plated (reflow treatment)
Housing: PPS, UL94V-0
RoHS compliance
This product displays (LF)(SN) on a label.
2
FM
(FPC)
CONNECTOR
Lead section dimensions of FFC and FPC –––––––––––––––––––––––––––––––––––––
(FFC)
1.0x(N+1)±0.12
1.0±0.15
1.0±0.05
1.0x(N-1)±0.1
0.7±0.1
1.0±0.15
R0.3
3.0min.
0.33
+0.02
–0.03
1.0x(N+1)±0.12
1.0±0.15
1.0±0.1
1.0x(N-1)±0.1
0.7±0.1
3.0min.
1.0±0.15
0.33
+0.02
–0.03
Conductor
Film cover layer
Reinforcing layer
Conductor
Reinforcing layer
Base layer
Note: N --- Number of circuits
PC board layout and Assembly layout ––––––––––––––––––––––––––––––––––––––––
Top entry type
(Through-hole type)
(viewed from soldering side
)
2.0±0.05
1.0±0.05
φ
0.75±0.05
2.0min.
3.0
0.9min.
1.0±0.05
0.6±0.05
2.0
3.0
(SMT type)
(viewed from component side)
1.5min.
4.4
10.0
7.5
2.0±0.05
Circuit No.1
Side entry type
(Through-hole type)
(viewed from soldering side
)
2.0±0.05
1.0±0.05
4.4
φ
0.75
5.0min.
2.0min.
2.9
(SMT type)
(viewed from component side)
1.5min.
1.0±0.05
0.6±0.05
1.9
3.0
4.4
3.0
3.6
Circuit No.1
Note:
1. Tolerances are non-cumulative: ±0.05mm for all centers.
2. Hole dimensions differ according to the kind of PC board and piercing method. The dimensions above should serve as a guideline.
3. It is recommended that surface mount connectors be secured using thermosetting resin or something similar. Contact JST for details.
2.0±0.15
3.0
1.2
3.0
4.4
3
