MUR6030SW
MUR6030SW ULTRAFAST PLASTIC RECTIFIER
Features:
•
•
•
•
•
Utra-Fast Switching
High Current Capability
Low Reverse Leakage Current
High Surge Current Capability
Plastic Material has UL Flammability Classification 94V-O
Mechanical Data:
•
•
•
•
•
Case: Molded Plastic
Terminals: Solder Leads, Solderable per MIL-STD-202, Method 208
Weight: 6 grams (approx.)
Marking: Type Number
Mounting Position: Any
Mechanical Dimensions: In mm / Inches
ANODE
1
ANODE
3
2
CATHODE
A
OPTION C
Option C is also available.
To order specifically the option C, please add suffix “–C” to the
part number:
To order specifically the standard option, please add suffix “–S”
to the part number.
If there is no suffix to the part number, the part could come with
either option.
TO-247AD
Deer Park, NY 11729-4681
(631) 586-7600 FAX (631) 242-9798
•
•
221 West Industry Court
•
World Wide Web Site - http://www.sensitron.com
•
E-Mail Address - sales@sensitron.com
•
SENSITRON
SEMICONDUCTOR
Data Sheet M2616, Rev. –
MUR6030SW
Maximum Ratings:
Characteristics
Peak Inverse Voltage
Max. Average Forward
Max. Peak One Cycle Non-
Repetitive Surge Current
Symbol
V
RRM
I
o(AV)
Condition
-
50Hz Sine wave
Max.
300
60
Units
V
A
I
FSM
50Hz Half Sine wave
250
A
Electrical Characteristics:
Characteristics
Max. Forward Voltage Drop
Symbol
V
F
I
R1
I
R2
Max. Reverse Recovery Time
* Pulse width < 300 µs, duty cycle < 2%
Max. Reverse Current
t
rr
Condition
@I
F
=60A, Pulse, T
J
= 25°C
@ I
F
=60A, Pulse, T
J
= 125°C
@V
R
= rated V
R
T
J
= 25°C
@V
R
= rated V
R
T
J
= 125°C
I
F
=500mA, I
R
=1A,and I
rm
=250mA
Max.
1.40
1.30
15
2
60
Units
V
µA
mA
ns
Thermal-Mechanical Specifications:
Characteristics
Max. Junction Temperature
Max. Storage Temperature
Maximum Thermal
Resistance Junction to Case
Transient thermal resistance
at 1µs
Approximate Weight
Case Style
Symbol
T
J
T
stg
R
θJC
Z
θJC
wt
Condition
-
-
-
-
-
TO-247AD
Specification
-65 to +175
-65 to +175
0.80
0.002
6
Units
°C
°C
°C/W
°C/W
g
