Length of Braid
500T011
Top Entry
Cable Entry Code
Micro-D Backshells
Sample Part Number
Series
Shell Finesh
Connector Size
Hardware Option
500-011
EMI/RFI Shield Sock Backshell
Round Cable Entry
Shield Sock Backshells
save assembly time. These
backshells are terminated to tinned copper braid in
whatever length you require.
Available in Top, 45° and Side Entry,
these backshells
feature one piece construction and are available in a
variety of plating finishes.
Precision Swaged Braid Termination
adds mechanical
strength and lowers resistance compared to hex crimps.
How To Order Shield Sock EMI/RFI Backshells
500T011
M
25
h
08
-12
500T011
- Top Entry
500S011
- Side Entry
500E011
- 45° Entry
(See Table I)
E
– Chem Film (Alodyne)
J
– Cadmium, Yellow Chromate
M
– Electroless Nickel
NF
– Cadmium, Olive Drab
Z2
– Gold
09, 15, 21, 25, 31, 37, 51, 51-2, 67, 69, 100
(See Table III)
B
- Fillister Head Jackscrew
H
- Hex Head Jackscrew
E
- Extended Jackscrew
F
- Jackpost, Female
(See Table II)
04
- .125 (3.2)
05
- .156 (4.0)
06
- .188 (4.8)
07
- .219 (5.6)
08
- .250 (6.4)
09
- .281 (7.1)
10
- .312 (7.9)
11
- .344 (8.7)
(See Table IV)
Maximum Cable Entry Diameter per Shell Size and Style
Size
T
Top Entry
E
45° Entry
S
Side Entry
9
08
08
09
15
08
08
12
21
08
08
12
25
08
08
12
31
09
09
12
37
09
09
12
51
10
10
12
51-2
09
09
12
67
09
09
12
69
10
10
12
100
12
12
12
Length in One Inch Increments
-
Example: “12” equals twelve inches.
12
- .375 (9.5)
Table I: Entry Styles
500S011
Side Entry
500E011
45° Entry
Material and Finish
•
•
•
•
• Shell:
Aluminum Alloy 6061 -T6 Per QQ-A-200, QQ-A-225 (Machined
Components)
Aluminum Alloy 6061-T6 Per QQ-A-591 (A380) (Die-Cast Components)
Braid: Tinned Copper Braid Per QQ-B-575 ASTM B33, #36 AWG Strands,
90% Coverage
Crimp Ring: Copper, Tin Plated
Clips, E-Rings: 17-7PH Stainless Steel
Jackscrews, Washers, Jackposts: 300 Series Stainless Steel, Passivated
High Performance Micro-D Connectors and Cables
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
M-10
E-Mail: sales@glenair.com
500-011
EMI/RFI Shield Sock Backshell
Round Cable Entry
Table II: Hardware Options
A
F
- Jackpost, Female
B
- Fillister Head Jackscrew
H
- Hex Head Jackscrew
E
- Extended Jackscrew
(Not for 45° Entry)
B
C
D
E
F
G
H
J
K
L
Table III: Dimensions
C
B
A
E
G
F
N
SHOWN WITH H HEX HEAD
JACKSCREW
M
E - 45º ENTRY
Table IV: Cable Entry Code
Cable
Entry
Code
04
05
06
07
08
09
10
11
12
F
In.
mm.
± .010
± 0.25
.125
.156
.188
.219
.250
.281
.312
.344
.375
A Max.
In. mm.
3.18
3.96
4.78
5.56
6.35
7.14
7.92
8.74
9.53
G Max.
In.
.310
.350
.380
.400
.425
.450
.500
.525
.550
mm.
D
.50 (12.7) MAX.
CONNECTOR ORDERED
SEPARATELY
7.87
8.89
9.65
10.16
13.31
11.43
12.70
13.34
13.97
C
In.
mm.
.175 (4.4)
SHOWN WITH B FILISTER HEAD
JACKSCREW
CONNECTOR ORDERED
SEPARATELY
T - TOP ENTRY
H
L
J
K
#2-56 UNC THDS. 9-69 PIN
#4-40 UNC THDS. 100 PIN
S - SIDE ENTRY
SHOWN WITH E EXTENDED
JACKSCREW
CONNECTOR ORDERED
SEPARATELY
Size
09
15
21
25
31
37
B Max.
In. mm.
9.40
9.40
9.40
D Max.
In. mm.
E Max.
In. mm.
H Max.
In. mm.
J Max.
In. mm.
K
In.
mm.
L Max.
In. mm.
M Max.
In. mm.
N Max.
In. mm.
.850 21.59 .370
1.000 25.40 .370
1.150 29.21 .370
1.250 31.75 .370
1.400 35.56 .370
1.550 39.37 .370
.565 14.35 .780 19.81 .410 10.41 .350 8.89 .637 16.18 .435 11.05 1.040 26.42 1.000 25.40 .680 17.27
.715 18.16 .910 23.11 .580 14.73 .470 11.94 .673 17.09 .440 11.20 1.170 29.72 1.030 26.16 .730 18.54
.865 21.97 1.030 26.16 .740 18.80 .590 14.99 .707 17.95 .458 11.63 1.290 32.77 1.050 26.67 .765 19.43
M
N
P
Q
INDEX
9.40 .965 24.51 1.090 27.69 .850 21.59 .650 16.51 .748 19.00 .483 12.27 1.350 34.29 1.090 27.69 .830 21.08
9.40 1.115 28.32 1.150 29.21 .980 24.89 .710 18.03 .756 19.20 .476 12.09 1.420 36.07 1.130 28.70 .890 22.61
9.40 1.265 32.13 1.190 30.23 1.130 28.70 .750 19.05 .774 19.66 .478 12.14 1.450 36.83 1.230 31.24 .955 24.26
51
1.500 38.10 .410 10.41 1.215 30.86 1.220 30.99 1.080 27.43 .780 19.81 .859 21.82 .548 13.91 1.480 37.59 1.250 31.75 1.005 25.53
51-2
1.910 48.51 .370 9.40 1.615 41.02 1.220 30.99 1.510 38.35 .780 19.81 .859 21.82 .548 13.91 1.480 37.59 1.250 31.75 1.005 25.53
67
2.310 58.67 .370 9.40 2.015 51.18 1.220 30.99 1.880 47.75 .780 19.81 .859 21.82 .548 13.91 1.480 37.59 1.250 31.75 1.005 25.53
69
1.810 45.97 .410 10.41 1.515 38.48 1.220 30.99 1.380 35.05 .780 19.81 .859 21.82 .548 13.91 1.480 37.59 1.250 31.75 1.005 25.53
100
2.235 56.77 .460 11.68 1.800 45.72 1.280 32.51 1.470 37.34 .840 21.34 1.014 25.76 .687 17.45 1.580 40.13 1.320 33.53 1.080 27.43
