C&K OS Series
Miniature Slide Switches
Features/Benefits
•
Variety of actuators & terminations
•
PC and panel mounting
•
Gold or silver plating available
•
Shorting or non-shorting contacts
•
RoHS compliant
Typical Applications
•
Test & measurement equipment
•
Computer peripherals &
network products
•
Consumer products
Specifications
CONTACT RATING: See individual parts.
MECHANICAL & ELECTRICAL LIFE: 10,000 cycles.
CONTACT RESISTANCE: 20 m
Ω
or less.
INSULATION RESISTANCE: 100 m
Ω
min. at 500 VDC.
DIELECTRIC STRENGTH: 500 VAC for 1 minute.
OPERATING TEMPERATURE: –10ºC to +70ºC.
PACKAGING: Bulk
* For RoHS compatible switches contact customer service.
Materials
BASE: Phenolic resin.
ACTUATOR: POM, black.
HOUSING PLATE: SPCC Sn plated.
MOVABLE CONTACT: Copper alloy, silver plated or gold.
STATIONARY CONTACTS: Brass, silver plated.
TERMINALS: Brass, silver plated (Gold plate - Contact
customer service).
TERMINAL SEAL: None.
NOTE:
For the latest information regarding RoHS compliance, please
go to: www.ittcannon.com/rohs.
NOTE:
Specifications and materials listed above are for switches with standard options.
For information on specific and custom switches, consult Customer Service Center.
J
Slide
How To Order
Complete part numbers for OS Series Slide Switches are shown on pages J–36 through J–42.
PC MOUNTING
SWITCH FUNCTION
POS. 1
POS. 2
PART NUMBER
1 2 3
OS102011MS2QN1
(Non-shorting)
ON
ON
OS102011MS2QN1
ON
1-2
ON
2-3
1 2 3
3
OS102011MS2QS1
(Shorting)
CONN. TERMINALS
SCHEMATIC
SPDT
SPDT
CONTACT RATING: 0.1A @ 12 VDC
Actuator shown in pos. 2
PC MOUNTING
SWITCH FUNCTION
POS. 3
POS. 2
POS. 1
PART NUMBER
1
2 3 4
OS103011MS8QP1
(Non-specified)
CONN. TERMINALS
SCHEMATIC
ON
1-2
ON
2-3
ON
2-4
OS103011MS8QP1
SP3T
1
2 3 4
4
SP3T
CONTACT RATING: 0.1A @ 12 VDC
Actuator shown in pos. 3
Dimensions are shown: Inch (mm)
Specifications and dimensions subject to change
J–36
www.ittcannon.com
C&K OS Series
Miniature Slide Switches
PC MOUNTING
SWITCH FUNCTION
1 2 3
POS.1
PART NUMBER
POS. 2
4 5 6
OS202011MS2QS1
(Shorting)
ON
ON
OS202011MS2QN1
(Non-shorting)
ON
1-2,4-5
ON
2-3,5-6
OS202011MS2QS1
CONN. TERMINALS
SCHEMATIC
4 5 6
6
3
DPDT
J
DPDT
CONTACT RATING: 0.1A @ 12 VDC
Actuator shown in pos. 2
Slide
PC MOUNTING
1 2 3
4
SWITCH FUNCTION
POS.1
POS. 2
POS. 3
5 6 7
8
PART NUMBER
OS203011MS1QP1
(Non-specified)
CONN. TERMINALS
ON
1-3,5-7
ON
2-3,6-7
ON
3-4,7-8
OS203011MS1QP1
SCHEMATIC
DP3T
5 6 7
8
DP3T
CONTACT RATING: 0.3A @ 30 VDC
Actuator shown in pos. 3
PC MOUNTING
SWITCH FUNCTION
POS.1
1
2
3
POS. 2
PART NUMBER
4 5 6
OS202013MT5QN1
(Non-shorting)
CONN. TERMINALS
SCHEMATIC
ON
1-2,4-5
ON
2-3,5-6
OS202013MT5QN1
DPDT
4
6
5 6
3
DPDT
CONTACT RATING: 0.3A @ 30 VDC
Actuator shown in pos. 1
Dimensions are shown: IN (mm)
Specifications and dimensions subject to change
J–37
www.ittcannon.com
C&K OS Series
Miniature Slide Switches
PIN LAYOUT
SWITCH FUNCTION
POS.1
PART NUMBER
POS. 2
POS. 3
OS203013MT7QN1
(Non-shorting)
CONN. TERMINALS
SCHEMATIC
ON
1-2,4-5
OFF
ON
2-3,5-6
OS203013MT7QN1
DP3T
J
Slide
DP3T
CONTACT RATING: 0.3A @ 30 VDC
4
5
6
6
3
Actuator shown in pos. 3
PC MOUNTING
1
2
3
SWITCH FUNCTION
POS.1
PART NUMBER
POS. 2
4
5
6
OS202013MT8QN1
(Non-shorting)
CONN. TERMINALS
SCHEMATIC
ON
1-2,4-5
ON
2-3,5-6
OS202013MT8QN1
DPDT
4
5
6
6
3
DPDT
CONTACT RATING: 0.3A @ 30 VDC
Actuator shown in pos. 1
PC MOUNTING
1
2
3
4
SWITCH FUNCTION
POS.1
PART NUMBER
POS. 2
POS. 3
5
6
7
8
OS203013MT8QN1
(Non-shorting)
CONN. TERMINALS
SCHEMATIC
ON
1-2,5-6
ON
2-3,6-7
ON
3-4,7-8
OS203013MT8QN1
DP3T
8
5
6
7
8
4
DP3T
CONTACT RATING: 0.3A @ 30 VDC
Actuator shown in pos. 1
Dimensions are shown: Inch (mm)
Specifications and dimensions subject to change
J–38
www.ittcannon.com
C&K OS Series
Miniature Slide Switches
PC MOUNTING
1
2
3
4
SWITCH FUNCTION
POS.1
POS. 2
POS. 3
5
6
78
PART NUMBER
OS203013MT6QN1
OS203013MT6QN1
(Non-shorting)
CONN. TERMINALS
SCHEMATIC
ON
1-2,5-6
ON
2-3,6-7
ON
3-4,7-8
DP3T
5
6
7
8
8
4
DP3T
CONTACT RATING: 0.2A @ 30 VDC
J
Slide
Actuator shown in pos. 3
PC MOUNTING
1
2 3 4
SWITCH FUNCTION
POS.1
PART NUMBER
POS. 2
POS. 3
OS103012MU1QP1
SP3T
OS103012MU1QP1
(Non-shorting)
CONN. TERMINALS
SCHEMATIC
ON
1-2
ON
2-3
ON
2-4
4
1
2 3 4
SP3T
CONTACT RATING: 0.2A @ 30 VDC
Actuator shown in pos. 1
PC MOUNTING
1
2 3 4
SWITCH FUNCTION
POS.1
PART NUMBER
POS. 2
POS. 3
OS103012MU2QP1
SP3T
OS103012MU2QP1
(Non-shorting)
CONN. TERMINALS
SCHEMATIC
4
ON
1-2
ON
2-3
ON
2-4
1
2 3 4
SP3T
CONTACT RATING: 0.2A @ 30 VDC
Actuator shown in pos. 1
Dimensions are shown: IN (mm)
Specifications and dimensions subject to change
J–39
www.ittcannon.com
C&K OS Series
Miniature Slide Switches
PC MOUNTING
SWITCH FUNCTION
POS.1
PART NUMBER
POS. 2
POS. 3
1
2 3 4
OS203012MU5QP1
(Non-specified)
CONN. TERMINALS
SCHEMATIC
5
6 7 8
ON
1-2,5-6
ON
2-3,6-7
ON
2-4,6-8
OS203012MU5QP1
DP3T
5
6 7 8
8
4
J
Slide
DP3T
CONTACT RATING: 0.1A @ 30 VDC
Actuator shown in pos. 1
PC MOUNTING
SWITCH FUNCTION
POS.1
PART NUMBER
POS. 2
1 2 3
OS202011MV4QN1
(Non-shorting)
4 5 6
ON
ON
OS202011MV4QS1
(Shorting)
CONN. TERMINALS
SCHEMATIC
ON
1-2,4-5
ON
2-3,5-6
OS202011MV4QN1
DPDT
4 5 6
6
3
DPDT
CONTACT RATING: 0.1A @ 30 VDC
Actuator shown in pos. 1
SWITCH FUNCTION
POS.1
PART NUMBER
POS. 2
POS. 3
PC MOUNTING
1 2 3 4 5
OS203011MV9QS1
(Shorting)
ON
ON
ON
6 7 8 9 10
OS203011MV9QN1
(Non-shorting)
CONN. TERMINALS
SCHEMATIC
ON
1-2-5,
6-7-10
ON
1-3-5,
6-8-10
ON
OS203011MV9QS1
1-4-5,
6-9-10
DP3T
6 7 8 9
10
10
5
DP3T
CONTACT RATING: 0.1A @ 30 VDC
Actuator shown in pos. 2(A)
Dimensions are shown: Inch (mm)
Specifications and dimensions subject to change
J–40
www.ittcannon.com
