1N5225B thru 1N5267B
Vishay Semiconductors
formerly General Semiconductor
Zener Diodes
DO-204AH
(DO-35 Glass)
Zener Voltage Range
3.0 to 75V
Power Dissipation
500mW
Features
• Silicon Planar Power Zener Diodes.
• Standard Zener voltage tolerance is ±5% with a “B” suffix.
Other tolerances are available upon request.
• These diodes are also available in MiniMELF case with
the type designation ZMM5225 ... ZMM5267, SOT-23
case with the type designation MMBZ5265 ...
MMBZ5267 and SOD-23 case with the types
designation MMSZ5225 ... MMSZ5267
Mechanical Data
Case:
DO-35 Glass Case
Weight:
approx. 0.0046 oz., 0.13 g
Packaging codes/options:
D7/10K per 13" reel, (52mm tape), 20K/box
D8/10K per Ammo tape (52mm tape), 20K/box
Dimensions in inches and (millimeters)
Maximum Ratings and Thermal Characteristics
Parameter
Zener Current (see Table “Characteristics”)
Power Dissipation at T
amb
= 75°C
Thermal Resistance Junction to Ambient Air
Maximum Junction Temperature
Storage Temperature Range
(T
A
= 25°C unless otherwise noted)
Symbol
Value
500
(1)
300
(1)
175
–65 to +175
Unit
P
D
R
θJA
T
J
T
S
mW
°C/W
°C
°C
Note:
(1) Valid provided that leads at a distance of 10mm from case are kept at ambient temperature.
Document Number 88305
22-Aug-02
www.vishay.com
1
1N5225B thru 1N5267B
Vishay Semiconductors
formerly General Semiconductor
Electrical Characteristics
(T
A
= 25°C unless otherwise noted)
Maximum V
F
= 1.1V at I
F
= 200mA
Maximum Zener Impedance
Nominal Zener
Voltage
(3)
Test Current
Type
1N5225B
1N5226B
1N5227B
1N5228B
1N5229B
1N5230B
1N5231B
1N5232B
1N5233B
1N5234B
1N5235B
1N5236B
1N5237B
1N5238B
1N5239B
1N5240B
1N5241B
1N5242B
1N5243B
1N5244B
1N5245B
1N5246B
1N5247B
1N5248B
1N5249B
1N5250B
1N5251B
1N5252B
1N5253B
1N5254B
1N5255B
1N5256B
1N5257B
1N5258B
1N5259B
1N5260B
1N5261B
1N5262B
1N5263B
1N5264B
1N5265B
1N5266B
1N5267B
at I
ZT
V
Z
(V)
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.0
6.2
6.8
7.5
8.2
8.7
9.1
10
11
12
13
14
15
16
17
18
19
20
22
24
25
27
28
30
33
36
39
43
47
51
56
60
62
68
75
I
ZT
(mA)
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
9.5
9.0
8.5
7.8
7.4
7.0
6.6
6.2
5.6
5.2
5.0
4.6
4.5
4.2
3.8
3.4
3.2
3.0
2.7
2.5
2.2
2.1
2.0
1.8
1.7
Typical
Temperature
at I
ZK
= 0.25mA Coefficient
at I
ZT
Z
ZT
(Ω)
Z
ZK
(Ω)
α
VZ
(% / °C)
29
28
24
23
22
19
17
11
7
7
5
6
8
8
10
17
22
30
13
15
16
17
19
21
23
25
29
33
35
41
44
49
58
70
80
93
105
125
150
170
185
230
270
1600
1600
1700
1900
2000
1900
1600
1600
1600
1000
750
500
500
600
600
600
600
600
600
600
600
600
600
600
600
600
600
600
600
600
600
600
700
700
800
900
1000
1100
1300
1400
1400
1600
1700
– 0.075
–0.070
–0.065
–0.060
–0.055
±0.030
±0.030
+0.038
+0.038
+0.045
+0.050
+0.058
+0.062
+0.065
+0.068
+0.075
+0.076
+0.077
+0.079
+0.082
+0.082
+0.083
+0.084
+0.085
+0.086
+0.086
+0.087
+0.087
+0.089
+0.090
+0.091
+0.091
+0.092
+0.093
+0.094
+0.095
+0.095
+0.096
+0.096
+0.097
+0.097
+0.097
+0.098
(1)
Maximum Reverse
Leakage Current
Test Voltage Maximum Regulator
I
R
(µA)
50
25
15
10
5.0
5.0
5.0
5.0
5.0
5.0
3.0
3.0
3.0
3.0
3.0
3.0
2.0
1.0
0.5
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
V
R
(V)
1.0
1.0
1.0
1.0
1.0
2.0
2.0
3.0
3.5
4.0
5.0
6.0
6.5
6.5
7.0
8.0
8.4
9.1
9.9
10
11
12
13
14
14
15
17
18
19
21
21
23
25
27
30
33
36
39
43
46
47
52
56
Current
(2)
I
ZM
(mA)
152
138
126
115
106
97
89
81
76
73
67
61
55
52
50
45
41
38
35
32
30
28
27
25
24
23
21
19.1
18.2
16.8
16.2
15.1
13.8
12.6
11.6
10.6
9.7
8.9
–
–
–
–
–
Notes:
(1) The Zener impedance is derived from the 1 kHz AC voltage which results when an AC current having an RMS value equal to 10% of the Zener current (I
ZT
or
I
ZK
) is superimposed on I
ZT
or I
ZK
. Zener impedance is measured at two points to insure a sharp knee on the breakdown curve and to eliminate unstable units
(2) Valid provided that leads at a distance of 10 mm from case are kept at ambient temperature
(3) Measured with device junction in thermal equilibrium
www.vishay.com
2
Document Number 88305
22-Aug-02
1N5225B thru 1N5267B
Vishay Semiconductors
formerly General Semiconductor
Ratings and
Characteristic Curves
(T
A
= 25°C unless otherwise noted)
D
Document Number 88305
22-Aug-02
www.vishay.com
3
