1N4130UR-1 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> 1N4130UR-1

1N4130UR-1: DescriptionZener Diode, 68V V(Z), 1.5W, Silicon, Unidirectional,; CategoryDiscrete semiconductor diode; File Size75KB，3 Pages; ManufacturerSENSITRON; Websitehttp://www.sensitron.com/

Download Datasheet Parametric View All

1N4130UR-1 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	1N4130UR-1	-	-	View	Buy Now

1N4130UR-1 Overview

Zener Diode, 68V V(Z), 1.5W, Silicon, Unidirectional,

1N4130UR-1 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	SENSITRON
package instruction	O-XALF-W2
Reach Compliance Code	compliant
ECCN code	EAR99
Is Samacsys	N
Other features	METALLURGICALLY BONDED
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
JESD-30 code	O-XALF-W2
Number of components	1
Number of terminals	2
Package body material	UNSPECIFIED
Package shape	ROUND
Package form	LONG FORM
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
polarity	UNIDIRECTIONAL
Maximum power dissipation	1.5 W
Certification status	Not Qualified
Nominal reference voltage	68 V
surface mount	NO
technology	ZENER
Terminal form	WIRE
Terminal location	AXIAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Base Number Matches	1

Preview

Download Datasheet

View All

1N4106-1/UR-1 to 1N4135-1/UR-1

SENSITRON

SEMICONDUCTOR

TECHNICAL DATA

DATASHEET 5095, Rev A

Zener 1.5W DIODE

•

Zener voltage available from 12V to 100V

•

Sharp Zener knee

•

Metallurgically bonded

Type

Number

1N4106-1/UR -1

1N4107-1/UR -1

1N4108-1/UR -1

1N4109-1/UR -1

1N4110-1/UR -1

1N4111-1/UR -1

1N4112-1/UR -1

1N4113-1/UR -1

1N4114-1/UR -1

1N4115-1/UR -1

1N4116-1/UR -1

1N4117-1/UR -1

1N4118-1/UR -1

1N4119-1/UR -1

1N4120-1/UR -1

1N4121-1/UR -1

1N4122-1/UR -1

1N4123-1/UR -1

1N4124-1/UR -1

1N4125-1/UR -1

1N4126-1/UR -1

1N4127-1/UR -1

1N4128-1/UR- 1

1N4129-1/UR -1

1N4130-1/UR -1

1N4131-1/UR -1

1N4132-1/UR -1

1N4133-1/UR -1

1N4134-1/UR -1

1N4135-1/UR -1

Nominal

Zener

Voltage

Vz Nominal

Volts

12.0

13.0

14.0

15.0

16.0

17.0

18.0

19.0

20.0

22.0

24.0

25.0

27.0

28.0

30.0

33.0

36.0

39.0

43.0

47.0

51.0

56.0

60.0

62.0

68.0

75.0

82.0

87.0

91.0

100.0

Zener

Test

Current

μA

5.0

2.5

4.0

5.0

7.0

8.0

10.0

Max Zener

Impedance

Zzt

ohms

200

100

150

200

250

300

400

500

700

800

1,000

1,200

1,600

Max Zener

Current

Izsm

540

500

464

433

406

382

361

342

325

295

271

260

240

232

216

197

180

166

151

138

127

116

108

105

Max Reverse

Leakage Current

μA

0.05

0.01

Volts

9.2

9.9

10.7

11.4

12.2

13.0

13.7

14.5

15.2

16.8

18.3

19.0

20.5

21.3

22.8

25.1

27.4

29.7

32.7

35.8

38.8

42.6

45.6

47.1

51.7

57.0

62.4

66.2

69.2

76.0

•

221 WEST INDUSTRY COURT

•

DEER PARK, NY 11729-4681

•

PHONE (631) 586-7600

•

FAX (631) 242-9798

•

World Wide Web - http://www.sensitron.com

•

E-mail Address - sales@sensitron.com

•

1N4106-1/UR-1 to 1N4135-1/UR-1

SENSITRON

SEMICONDUCTOR

TECHNICAL DATA

DATASHEET 5095, Rev A

DISCLAIMER:

1- The information given herein, including the specifications and dimensions, is subject to change without prior notice to improve

product characteristics. Before ordering, purchasers are advised to contact the Sensitron Semiconductor sales department for the

latest version of the datasheet(s).

2- In cases where extremely high reliability is required (such as use in nuclear power control, aerospace and aviation, traffic

equipment, medical equipment , and safety equipment) , safety should be ensured by using semiconductor devices that feature

assured safety or by means of users’ fail-safe precautions or other arrangement .

3- In no event shall Sensitron Semiconductor be liable for any damages that may result from an accident or any other cause during

operation of the user’s units according to the datasheet(s). Sensitron Semiconductor assumes no responsibility for any intellectual

property claims or any other problems that may result from applications of information, products or circuits described in the

datasheets.

4- In no event shall Sensitron Semiconductor be liable for any failure in a semiconductor device or any secondary damage

resulting from use at a value exceeding the absolute maximum rating.

5- No license is granted by the datasheet(s) under any patents or other rights of any third party or Sensitron Semiconductor.

6- The datasheet(s) may not be reproduced or duplicated, in any form, in whole or part, without the expressed written permission

of Sensitron Semiconductor.

7- The products (technologies) described in the datasheet(s) are not to be provided to any party whose purpose in their application

will hinder maintenance of international peace and safety nor are they to be applied to that purpose by their direct purchasers or

any third party. When exporting these products (technologies), the necessary procedures are to be taken in accordance with

related laws and regulations.

•

221 WEST INDUSTRY COURT

•

DEER PARK, NY 11729-4681

•

PHONE (631) 586-7600

•

FAX (631) 242-9798

•

World Wide Web - http://www.sensitron.com

•

E-mail Address - sales@sensitron.com

•
