REVISION AG
DO NOT
SCALE FROM
THIS PRINT
01
C
L
(No OF POS x .050[1.27])
+ .015[0.38] REF
N-1 (SEE TABLE 2)
FEP CABLE OPTION
-T: FEP (LEAVE BLANK FOR
STANDARD PVC INSULATION)
SFSDX-XX-XXX-XX-XX.XX-XX-XXX
AG
.250 6.35
REF
02
.050 1.27
REF
.080 2.03 REF
"A"
C
.440 11.18
REF
No OF POSITIONS
-02, -04, -05, -07, -10, -15, -20, -25,
-30 -35 -40, -45, & -50 (PER ROW)
.120 3.05 REF .145 3.68 REF
AVAILABLE AS STANDARD
-02 THRU -50 AVAILABLE AS ASO
WIRE GAUGE (AWG)
N (SEE TABLE 2)
-28, -30
COLOR CODE:
FIG 1
LEAVE BLANK FOR ALL BLACK WIRE
-S: SINGLE END
C: COLOR CODED WIRE, SEE COLOR
(SFSD-10-28-XX-XX.XX-S SHOWN)
SEQUENCE TABLE, SHEET 3
(NOT AVAILABLE WITH FEP OPTION)
ISDF-XX-D
PLATING SPECIFICATION
.050 1.27 REF
-H: 30µ" HEAVY GOLD IN CONTACT AREA,
3µ" GOLD ON TAIL
-G: 10µ" LIGHT GOLD IN CONTACT AREA,
3µ" GOLD ON TAIL
-F: 3µ" FLASH GOLD IN CONTACT AREA,
3µ" GOLD ON TAIL
-GF: 3µ" FLASH SELECTIVE IN CONTACT AREA,
3µ" GOLD ON TAIL
(ONLY AVAILABLE TO EXISTING
.249 6.32
CUSTOMERS; SEE -F PLATING)
REF
(SEE TABLE 3, SHEET 1)
ASSEMBLED LENGTH
SPECIFY IN INCHES
(SINGLE END: 03.00 INCH [76.2mm]
MINIMUM,
DOUBLE END: 03.25 INCH [82.6mm]
MINIMUM)
-NXX OPTION (END 2)
(ONLY AVAILABLE WITH -D, -DL, -DR, -DS & -SS)
-NUS: NOTCH UP, STRAIGHT
(PIN 1 TO PIN N-1)
-NDS: NOTCH DOWN, STRAIGHT
(PIN 1 TO PIN 2)
-NUX: NOTCH UP, CROSSED
(PIN 1 TO PIN N)
-NDX: NOTCH DOWN, CROSSED
(PIN 1 TO PIN 1)
END OPTION
(END OPTION COMBINATIONS NOT AVAILABLE)
ASSEMBLED LENGTH:
(SEE NOTE 8)
C
-S: SINGLE END
-D: DOUBLE END
(MUST CHOOSE FROM -NXX OPTIONS)
-SL: SINGLE ENDED WITH FRICTION LOCK
(SEE SHEET 2, FIG 3)(ONLY AVAILABLE ON
*5,*7, 10 THRU 50 POSITION)
-DL: DOUBLE ENDED WITH FRICTION LOCK
(SEE SHEET 2, FIG 4) (ONLY AVAILABLE
ON *5,*7, 10 THRU 50 POSITION)
(MUST CHOOSE FROM -NXX OPTIONS)
-SR: SINGLE ENDED WITH RETENTION LATCH
(SEE SHEET 3, FIG 5)(USE SUB-IM-LTC-07-01-N)
(ONLY AVAILABLE ON -02 THRU -50 POS)
-DR: DOUBLE ENDED WITH RETENTION LATCH
(SEE SHEET 3, FIG 6)(USE SUB-IM-LTC-07-01-N)
(ONLY AVAILABLE ON -02 THRU -50 POS)
(MUST CHOOSE FROM -NXX OPTIONS)
-SS: DUAL SCREW DOWN, SINGLE ENDED CABLE
(SEE SHT 4, FIG 7)
(ONLY AVAILABLE ON 02 THRU 40 POSITIONS)
(NOT AVAILABLE WITH OPTIONS SL, DL, SR & DR
USES ISDF-XX-D-DS, CPS-RR-XX-XX-X & ACCRT-01,
MUST CHOOSE FROM NXXX OPTIONS)
-DS: DUAL SCREW DOWN, DOUBLE ENDED CABLE
(SEE SHT 4, FIG 8)
(ONLY AVAILABLE ON 02 THRU 40 POSITIONS)
(NOT AVAILABLE WITH OPTIONS SL, DL, SR & DR
USES ISDF-XX-D-DS, CPS-RR-XX-XX-X & ACCRT-01,
MUST CHOOSE FROM NXXX OPTIONS)
(* = NOT AVAILABLE WITH POLARIZATION KEY)
DWCX-XX-XX-300
AG
AG
POLARIZATION KEY
C
ASSEMBLED LENGTH:
XX.XX .125[3.18]
"A"
AG NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. MINIMUM PULLOUT FORCE: 3.0 LBS [13.3 N].
C
3. CONTACT MUST BE INSERTED UNTIL RETENTION FEATURE LOCKS INTO PLACE.
C
4. ALL FINISHED GOODS ARE TO BE ELECTICAL TESTED INCLUDING HI-POT TEST
AT 1000 VOLTS DC. AFTER FINAL ELECTRICAL TEST, LABEL EACH ASSEMBLY
WITH 1 LABEL-ET.
5. TINNED COPPER WIRE IS RoHS COMPLIANT.
6. PARTS TO BE LAYER PACKAGED.
7. END OF DISCRETE WIRE MUST BE IN THE RANGE AFTER CRIMP.
8. FOR LENGTHS LESS THAN 12 in, TOLERANCE SHALL BE +/-.125.
FOR OTHER LENGTHS, TOLERANCE SHALL BE +/-2%.
9. NOTE DELETED.
C
10. REFER TO CRIMP SPECIFICATIONS PRINT FOR CRIMP AND STRIP
DIMENSIONS, TOLERANCES, TOOLING AND ITS REQUIREMENTS.
11. 3LB MIN WIRE CRIMP STRENGTH FOR -30 AWG AND 4.5LB MIN
WIRE CRIMP STRENGTH FOR -28 AWG.
12. NOTE DELETED.
F:\DWG\MISC\MKTG\SFSDX-XX-XXX-XX-XX.XX-XX-XXX-MKT.SLDDRW
SECTION "A"-"A"
-D: DOUBLE END
(SFSD-10-28-XX-XX.XX-D-NUS SHOWN)
(SAME AS FIG 1, UNLESS OTHERWISE STATED)
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
FIG 2
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
.XX: .01 [.3]
2
.XXX: .005 [.13]
.XXXX: .0020 [.051]
ANGLES
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
MATERIAL:
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
INSULATOR: LCP, COLOR: BLACK
CONTACT: BeCu
CABLE INSULATION: PVC OR FEP, SEE CALLOUT
WIRE: DWC: TINNED COPPER. DWCT: SILVER
PLATED COPPER
(SEE TABLE 1)
.050[1.27] SOCKET DISCRETE CABLE ASSEMBLY
SFSDX-XX-XXX-XX-XX.XX-XX-XXX
SHEET
1
OF
4
BY:
BRATCHER 5/5/2005
REVISION AG
(SEE TABLE 2)
N-1
N
02
01
(SEE TABLE 2)
N-1
N
(SEE TABLE 2)
N
N-1
01
01
02
02
NOTCH END 1
NOTCH END 2
NOTCH END 1
01
02
N
N-1
(SEE TABLE 2)
(END 2 NOTCH UP, CABLE STRAIGHT)
(PIN 1 TO PIN N-1)
(SEE TABLE 2)
N-1
N
02
01
-NUS
(END 2 NOTCH DOWN, CABLE CROSSED)
(PIN 1 TO PIN 1)
ISDF-XX-D-L
ISDF-XX-D-L
-NDX
NOTCH END 2
01
02
NOTCH END 1
NOTCH END 2
N
N-1
(SEE TABLE 2)
(END 2 NOTCH UP, CABLE CROSSED)
(PIN 1 TO PIN N)
(SEE TABLE 2)
N-1
N
(SEE TABLE 2)
N-1
N
-NUX
01
02
01
02
-SL: SINGLE END FRICTION LOCK
(SFSDX-10-28-XX-XX.XX-SL SHOWN)
(SAME AS FIG 1, UNLESS OTHERWISE STATED)
FIG 3
NOTCH END 1
-DL: DOUBLE END FRICTION LOCK
(SFSDX-10-28-XX-XX.XX-DL-NUS SHOWN)
(SAME AS FIG 1, UNLESS OTHERWISE STATED)
FIG 4
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
(END 2 NOTCH DOWN, CABLE STRAIGHT)
(PIN 1 TO PIN 2)
F:\DWG\MISC\MKTG\SFSDX-XX-XXX-XX-XX.XX-XX-XXX-MKT.SLDDRW
-NDS
NOTCH END 2
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 1:0.571429
.050[1.27] SOCKET DISCRETE CABLE ASSEMBLY
SFSDX-XX-XXX-XX-XX.XX-XX-XXX
SHEET
2
OF
4
BY:
BRATCHER 5/5/2005
REVISION AG
-SR: SINGLE END WITH RETENTION LATCH
(SFSDX-10-28-XX-XX.XX-SR SHOWN)
(ONLY AVAILABLE ON -02 THRU -50 POS)
(SAME AS FIG 1, UNLESS OTHERWISE STATED)
C
FIG 5
C
C
.083 2.11 (TYP)
ISDF-XX-D-R
-DR: DOUBLE END WITH RETENTION LATCH
(SFSDX-10-28-XX-XX.XX-DR SHOWN)
(ONLY AVAILABLE ON -02 THRU -50 POS)
(SAME AS FIG 1, UNLESS OTHERWISE STATED)
.080 2.03 REF
SUB-IM-LTC-07-01-N
FIG 6
.113 2.86
.083 2.11 (TYP)
ISDF-XX-D-R
.113 2.86
C
.080 2.03
REF
(No OF POS x .050[1.27])
+ .145[3.68] REF (TYP)
(No OF POS x .050[1.27])
+ .145[3.68] REF
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 4:1
.050[1.27] SOCKET DISCRETE CABLE ASSEMBLY
SFSDX-XX-XXX-XX-XX.XX-XX-XXX
SHEET
3
OF
4
F:\DWG\MISC\MKTG\SFSDX-XX-XXX-XX-XX.XX-XX-XXX-MKT.SLDDRW
BY:
BRATCHER 5/5/2005
REVISION AG
-SS: SINGLE END WITH SCREW DOWN
(SFSDX-10-XXX-XX-01.60-SS-NDS SHOWN)
(ONLY AVAILABLE ON -02 THRU -40 POS
MUST CHOOSE FROM -NXXX OPTIONS)
(SAME AS FIG 1, UNLESS OTHERWISE STATED)
(No OF POS X .050[1.27]) + .360 [9.14]
CPS-RR-M2-01-X
.079 2.00
REF
.145 3.68
C
C
FIG 7
-DS: DOUBLE END WITH SCREW DOWN
(SFSDX-10-XXX-XX-01.60-DS-NDS SHOWN)
(ONLY AVAILABLE ON -02 THRU -40 POS
MUST CHOOSE FROM -NXXX OPTIONS)
(SAME AS FIG 1, UNLESS OTHERWISE STATED)
FIG 8
C
(No OF POS X .050[1.27]) + .360 [9.14] (TYP)
CPS-RR-M2-01-X
ACCRT-01
C
.079 2.00
REF
.145 3.68
'A'
ISDF-XX-D-DS
ISDF-XX-D-DS
(No OF POS x .050[1.27])
+.015[0.38] REF
(No OF POS x .050[1.27])
+.015[0.38] REF
"B"
DETAIL 'A'
SCALE 4 : 1
"B"
ACCRT-01
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
R.057 1.45 REF
SECTION "B"-"B"
SCALE 4 : 1
F:\DWG\MISC\MKTG\SFSDX-XX-XXX-XX-XX.XX-XX-XXX-MKT.SLDDRW
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
.050[1.27] SOCKET DISCRETE CABLE ASSEMBLY
SFSDX-XX-XXX-XX-XX.XX-XX-XXX
SHEET
4
OF
4
BY:
BRATCHER 5/5/2005
