Pin strip |
Spacing 3.81 mm
STLZ1570/..F-3.81-V-GREEN
Technical Data
Wire Sizes
Solid min
solid max
Stranded (flexible)
min
Stranded (flexible)
max
-
-
-
-
Insulating Material
Material
Flammability Class
Temperatures
Operating Temperature
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Reflow Process
Soldering Temperature,
recommended
1.2 mm
Brass
Copper Alloy
Peak Soldering Time,
recommended
Leere Zeile
-
-
265 °C
3-4 s
-30 °C - 105 °C
PBT
UL 94 V-0
Order Data (Spacing mm)
Poles
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Width (mm)
18.01
21.82
25.63
29.44
33.25
37.06
40.87
44.68
48.49
52.30
56.11
59.92
63.73
67.54
71.35
75.16
78.97
82.78
86.59
Article Designation
STLZ1570/2F-3.81-V-GREEN
STLZ1570/3F-3.81-V-GREEN
STLZ1570/4F-3.81-V-GREEN
STLZ1570/5F-3.81-V-GREEN
STLZ1570/6F-3.81-V-GREEN
STLZ1570/7F-3.81-V-GREEN
STLZ1570/8F-3.81-V-GREEN
STLZ1570/9F-3.81-V-GREEN
STLZ1570/10F-3.81-V-GREEN
STLZ1570/11F-3.81-V-GREEN
STLZ1570/12F-3.81-V-GREEN
STLZ1570/13F-3.81-V-GREEN
STLZ1570/14F-3.81-V-GREEN
STLZ1570/15F-3.81-V-GREEN
STLZ1570/16F-3.81-V-GREEN
STLZ1570/17F-3.81-V-GREEN
STLZ1570/18F-3.81-V-GREEN
STLZ1570/19F-3.81-V-GREEN
STLZ1570/20F-3.81-V-GREEN
Article Number
51570026121D
51570036121D
51570046121D
51570056121D
51570066121D
51570076121D
51570086121D
51570096121D
51570106121D
51570116121D
51570126121D
51570136121D
51570146121D
51570156121D
51570166121D
51570176121D
51570186121D
51570196121D
51570206121D
PU
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
Stranded with Ferrule -
min
Stranded with Ferrule -
max
Dimensions
Stripped Length
PCB Hole Diameter
Materials
Flansch
Gewindeeinsatz
Contact Pin
Colours
GREEN
LIGHT GREEN
RAL6018
similar RAL 6018
RAL6018
similar RAL 6018
Accessories
Figure
Designation
Coding star CS1-3.5/3.81-RED
Article Number
50000000023
Colours according to RAL, there may be variations on colour due to production conditions.
Special colours on request.
Counterparts (Spacing 3.81 mm)
Pin Strip/Terminal Blocks
AKZ1550
AKZ4551
AKZ1710
AKZ1700
Ratings
Usegroup
Rated Voltage
Rated Current
Overvoltage Category
Test Voltage
Pollution Degree
B
300 V
8A
1.6 kV
C
-
-
-
D
300 V
8A
1.6 kV
160 V
9A
III
2.5 kV
3
