5962-01-175-0301 Overview

5962-01-175-0301

5962-01-175-0301 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	ADI
Reach Compliance Code	compliant
Is Samacsys	N
JESD-30 code	O-MBCY-W8
Number of terminals	8
Maximum operating temperature	70 °C
Minimum operating temperature
Nominal output voltage	10 V
Package body material	METAL
Encapsulate equivalent code	CAN8,.2
Package shape	ROUND
Package form	CYLINDRICAL
Certification status	Not Qualified
technology	BIPOLAR
Maximum voltage temperature coefficient	15 ppm/°C
Temperature level	COMMERCIAL
Terminal form	WIRE
Terminal location	BOTTOM
Maximum voltage tolerance	0.14%
Base Number Matches	1

Preview

Download Datasheet

View All

FEATURES

Four Programmable Output Voltages:

10.000 V, 7.500 V, 5.000 V, 2.500 V

Laser-Trimmed to High Accuracies

No External Components Required

Trimmed Temperature Coefficient:

5 ppm/ C Max, 0 C to 70 C (AD584L)

15 ppm/ C Max, –55 C to +125 C (AD584T)

Zero Output Strobe Terminal Provided

Two Terminal Negative Reference

Capability (5 V and above)

Output Sources or Sinks Current

Low Quiescent Current: 1.0 mA Max

10 mA Current Output Capability

MIL-STD-883 Compliant Versions Available

Pin Programmable

Precision Voltage Reference

AD584*

PIN CONFIGURATIONS

8-Lead TO-99

TAB

10.0V

5.0V

V+

CAP

AD584

TOP VIEW

(Not to Scale)

2.5V

COMMON

STROBE

8-Lead DIP

10.0V

5.0V

CAP

TOP VIEW

2.5V

(Not to Scale)

AD584

GENERAL DESCRIPTION

COMMON

STROBE

The AD584 is an eight-terminal precision voltage reference offer-

ing pin-programmable selection of four popular output voltages:

10.000 V, 7.500 V, 5.000 V and 2.500 V. Other output voltages,

above, below or between the four standard outputs, are available

by the addition of external resistors. Input voltage may vary between

4.5 V and 30 V.

Laser Wafer Trimming (LWT) is used to adjust the pin-

programmable output levels and temperature coefficients,

resulting in the most flexible high precision voltage reference

available in monolithic form.

In addition to the programmable output voltages, the AD584 offers

a unique strobe terminal which permits the device to be turned

on or off. When the AD584 is used as a power supply reference,

the supply can be switched off with a single, low-power signal.

In the “off” state the current drain by the AD584 is reduced to

about 100

µA.

In the “on” state the total supply current is typi-

cally 750

µA

including the output buffer amplifier.

The AD584 is recommended for use as a reference for 8-, 10-,

or 12-bit D/A converters which require an external precision

reference. The device is also ideal for all types of A/D convert-

ers of up to 14-bit accuracy, either successive approximation or

integrating designs, and in general can offer better performance

than that provided by standard self-contained references.

The AD584J, K, and L are specified for operation from 0°C to

70°C; the AD584S and T are specified for the –55°C to +125°C

range. All grades are packaged in a hermetically sealed eight-

terminal TO-99 metal can; the AD584 J and K are also available

in an 8-lead plastic DIP.

*Protected

by U.S. Patent No. 3,887,863; RE 30,586.

PRODUCT HIGHLIGHTS

1. The flexibility of the AD584 eliminates the need to design-in

and inventory several different voltage references. Further

more one AD584 can serve as several references simultaneously

when buffered properly.

2. Laser trimming of both initial accuracy and temperature coeffi-

cient results in very low errors over temperature without the

use of external components. The AD584LH has a maximum

deviation from 10.000 V of

7.25 mV from 0°C to 70°C.

3. The AD584 can be operated in a two-terminal “Zener” mode

at 5 V output and above. By connecting the input and the

output, the AD584 can be used in this “Zener” configuration

as a negative reference.

4. The output of the AD584 is configured to sink or source

currents. This means that small reverse currents can be toler-

ated in circuits using the AD584 without damage to the refer-

ence and without disturbing the output voltage (10 V, 7.5 V,

and 5 V outputs).

5. The AD584 is available in versions compliant with MIL-STD-

883. Refer to the Analog Devices Military Products Databook

or current AD584/883B data sheet for detailed specifications.

REV. B

Information furnished by Analog Devices is believed to be accurate and

reliable. However, no responsibility is assumed by Analog Devices for its

use, nor for any infringements of patents or other rights of third parties that

may result from its use. No license is granted by implication or otherwise

under any patent or patent rights of Analog Devices.

One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A.

Tel: 781/329-4700

www.analog.com

Fax: 781/326-8703
