RAST 5
Fully integrated in the heating and
home appliance industries
With their connector systems and connectors such as
RAST 5,
the Wieland Group is among the leading
suppliers in numerous sectors, especially the heating
industry.
Electrical appliances in the home are subject to strict
standards regarding fire protection and fire resistance. This
”more stringent glow-wire test” is defined in the standard
EN 60335-1 and is valid for new designs in this area. In
order to fulfill these high fire-protection requirements,
highly flame-resistant plastics must be used for certain
products.
Wieland Electric addressed this problem early on and
provides corresponding customer solutions in their
product range. In particular the PC board connectors of
the
RAST 5
series fulfill the requirements of the heating
industry and are available in a variety of defined color and
fixed codings.
PC board connectors in the RAST 5 system
The
RAST 5
system consists of two parts:
pluggable parts on the wiring side as well as solderable
parts, also called pin connectors, on the PC board side.
In addition to touch protection of the live side, this has the
advantage of a variety of coding possibilities with latches
and colors. Mismating is virtually impossible.
Along with the coding cams and locking positions, the
RAST 5
system also has a standardized connector face
that is defined by the
RAST 5
standard.
2
RAST 5
Combination possibilities
¬
= combinable
MS 9411 to
MS 9401 to
MS 9406, MS 9481 MS 9415 *
)
(SMD) *
)
MS 9421 to
MS 9424 *
)
MF 9431 to
MF 9434 *
)
MSF 9441 to
MSF 9444 *
)
¬
Fig. MS 9401
Fig. MS 9412
Fig. MS 9421
Fig. MF 9431
Fig. MSF 9441
¬
8105 B
¬
¬
¬
¬
¬
¬
¬
¬
¬
¬
¬
¬
¬
¬
¬
¬
¬
¬
¬
¬
¬
¬
¬
¬
8105 B VL
¬
8105 B VR
¬
8105 B VL A
¬
8105 B VR A
8105 FU
¬
8105 FU VL
¬
8105 FU VR
¬
8105 FU VL A
¬
8105 FU VR A
¬
8105 FUE VR
¬
8105 FUE VL
*
)
Customer-specific pin connectors, for details please contact the STOCKO Contact company
www.stocko-contact.com
E-mail: info@stocko-contact.com
Phone: +49 202 9733-0
